Legacy C1930032 Assembly Instructions Manual

2-drawer desk
Hide thumbs

Advertisement

Quick Links

Download this manual
L
H
EGACY
OME
F
D
URNISHINGS &
ECOR
Assembly Instructions
Instrucciones de Ensamblaje
120mns
SAVE THESE INSTRUCTIONS
GUARDE ESTAS INSTRUCCIONES
Do Not Return!
No Vuelvas!
Email or call customer service for help first.
Envie correo electrónico o llame al servicio para
obtener ayuda primero.
1-214-758-1098/Toll free: 1-883-907-1099
Monday-Friday 9am - 4pm CST
customer@legacyhfd.com
2-Drawer Desk
Escritorio con dos cajones
C1930032

Advertisement

loading

Related Manuals for Legacy C1930032

Summary of Contents for Legacy C1930032

  • Page 1 Instrucciones de Ensamblaje 120mns 2-Drawer Desk SAVE THESE INSTRUCTIONS Escritorio con dos cajones GUARDE ESTAS INSTRUCCIONES C1930032 Email or call customer service for help first. Envie correo electrónico o llame al servicio para Do Not Return! obtener ayuda primero. No Vuelvas!

  • Page 2: Helpful Advice

    EGACY URNISHINGS & ECOR Helpful advice Consejos útiles 1. Follow the assembly instructions carefully. 1. Siga a tentamente las instrucciones de montaje. 2. Check to ensure all parts, fasteners and hardware 2. Asegúrese de que la caja contiene todas las piezas, are present.
  • Page 3 EGACY URNISHINGS & ECOR Parts list/Lista de piezas...
  • Page 4 EGACY URNISHINGS & ECOR Hardware/Lista de materiales ITEM IMAGE DESCRIPTION DESCRIPCIÓN QUANTITY Wood dowel Perno Madera Cam bolt Perno Metálico Bloqueo metálico Cam lock Φ3.5×12 mm Screw Φ3.5×12 mm Tornillo Left glide Planeador izquierdo Right glide Planeador derecho Drawer connector Conector de plástico Φ3.5×12 mm Screw Φ3.5×12 mm Tornillo...
  • Page 5 EGACY URNISHINGS & ECOR Hardware/Lista de materiales ITEM IMAGE DESCRIPTION DESCRIPCIÓN QUANTITY Plastic file hanger Perchero de plástico Note/Nota El uso del tornillo incorrecto puede Using the wrong screw will cause provocar daños al producto. damage. Antes de iniciar la operación de Before you begin assembly check to ensure all parts are present.
  • Page 6 EGACY URNISHINGS & ECOR WARNING This product can expose you to chemicals including Formaldehyde, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov/furniture ADVERTENCIA Este producto puede exponerlo a sustancias quím icas, incluyendo el formaldehído, el cual es conocido en el estado de California como causante de cáncer, defectos de nacimiento u otros daños reproductivos.
  • Page 7 EGACY URNISHINGS & ECOR Necessary tools/Herramientas necesarias Glue not enclosed (We recommend to apply some glue into holes before inserting wood dowels.) Colle non fournie (Nous vous recommandons d’appliquer quelques gouttes de colle dans les trous avant Glue not included ( We recommend to apply some glue into holes before inserting wood dowels .) d’y introduire les chevilles de bois.) Cola, no incluida (Le recomendamos colocarunas gotas de cola en los ori cios antes de insertar las clavijas de madera.) madera.)
  • Page 8 EGACY URNISHINGS & ECOR Attention: In order to help your assembly, do not lock the screw tightly until you have assembled all the other parts. Atención: Con el fin de facilitar su montaje, no apretar el tornillo firmemente hasta que haya ensamblad o todas las otras partes.
  • Page 9 EGACY URNISHINGS & ECOR Step 3/Paso 3 Insert 2 wood dowels (A) and 4 cam bolts (B) into gable left (2). Attach left glide (E) to gable left (2) with 3 screws (D). Inserte 2 Pernos maderas (A) y 4 Pernos metálicos (B) en el Marco izquierdo (2). Bloquee el Planeador izquierdo (E) al Marco izquierdo (2) con 3 Tornillos (D).
  • Page 10 EGACY URNISHINGS & ECOR Step 5/Paso 5 Insert 2 wood dowels (A) and 4 cam bolts (B) into left divider (3). Attach right glide (F) to left divider (3) with 3 screws (D). Inserte 2 Pernos maderas (A) y 4 Pernos metálicos (B) en el Tablero vertical (3). Bloquee el Planeador derecho (F) al Tablero vertical (3) con 3 Tornillos (D).
  • Page 11 EGACY URNISHINGS & ECOR Step 7/Paso 7 Insert 2 cam bolts (B) into left divider (3). Inserte 2 Pernos metálicos (B) en el Tablero vertical (3). B x 2 Step 8/Paso 8 Insert 2 wood dowels (A) and 4 cam bolts (B) into right divider (8). Attach left glide (E) to right divider (8) with 3 screws (D).
  • Page 12 EGACY URNISHINGS & ECOR Step 9/Paso 9 Insert 4 cam locks (C) into front rail (4),back rail (5) and bottom (6) to combine with right divider (8). Conecte el Tablero inferior (6),las Barras (4)(5) al Tablero vertical (8) con 4 Bloqueos metálicos (C). C x 4 Step 10/Paso 10 Insert 2 wood dowels (A) and 4 cam bolts (B) into gable right (9).
  • Page 13 EGACY URNISHINGS & ECOR Step 11/Paso 11 Insert 4 cam locks (C) into the assembly part to combine with gable right (9). Conecte el ensamblaje al Marco derecho (9) con 4 Bloqueos metálicos (C). C x 4 Step 12/Paso 12 Insert 2 cam bolts (B) into right divider (8).
  • Page 14 EGACY URNISHINGS & ECOR Step 13/Paso 13 Insert 6 wood dowels (A) into the holes on the edge of middle back panel (10). Inserte 6 Pernos maderas (A) en el Tablero posterior (10). A x 6 Step 14 /Paso 14 Insert 4 cam locks (C) into middle back panel (10) to combine with right divider (8) and left divider (3).
  • Page 15 EGACY URNISHINGS & ECOR Step 15/Paso 15 Slide back panel (7) into the stand assembly. Inserte los Tableros posteriores (7) en el ensamblaje. Step 16/Paso 16 Insert 10 cam bolts (B) into top (1). Inserte 10 Pernos metálicos (B) en el Panel superior (1). B x 10...
  • Page 16 EGACY URNISHINGS & ECOR Step 17/Paso 17 Combine top (1) with base, use 10 cam locks (C). Conecte Panel superior (1) al ensamblaje con 10 Bloqueos metálicos (C). C x 10 Step 18 /Paso 18 Attach left glide (E) to drawer side left (11) with 3 screws (D). Attach right glide (F) to drawer side right (12) with 3 screws (D).
  • Page 17 EGACY URNISHINGS & ECOR Step 19/Paso 19 Insert 2 drawer connectors (G) to the drawer sides (11) (12) with 4 screws (H). Connect drawer sides (11) (12) with drawer back (13) with 4 screws (J). Repeat twice. Inserte 2 Conectores de plástico (G) en los Tableros laterales de cajón(11) (12) con 4 Tornillos (H), Conecte los dos Tableros laterales de cajón (11) (12) al Tablero posterior de cajón (13) con 4 Tornillos (J).
  • Page 18 EGACY URNISHINGS & ECOR Step 21/Paso 21 Align handle (K) with the holes on the drawer front (15), secure with 2 bolts (L). Insert drawer front (15) into assembly part with 4 screws (I). Put 2 plastic le hangers (M) into the drawer sides. Repeat twice. Inserte el Tirador (K) en el Tablero frontal de cajón (15) con 2 Tornillos (L).
  • Page 19 EGACY URNISHINGS & ECOR Maximum weight capacities/Capacidades de carga máxima 50 kg 110 lbs. 10 kg 22 lbs. 10 kg 22 lbs. WARNING Please use your furniture correctly and safely. Improper use can cause safety hazards, or damage to your furniture or household items.

  • Page 20: Year Warranty

    EGACY URNISHINGS & ECOR 1 YEAR WARRANTY BASIC WARRANTY: Homestar® furniture is warranted by Homestar Corporation (Homestar) to the original purchaser for a period of one year from the date of purchase, subject to the following conditions and limitations. 1. Install and operate this item in accordance with the Installation and 6.
