  • Page 2 Instruction, if any. We hope that you are going to enjoy your new accessory. This accessory is intended to be used with a Permobil wheelchair. For more information regarding indoor and outdoor use, and for further information about your wheelchair, please see the wheelchair’s User’s...

  • Page 3: Table Of Contents

    Omni2 Corpus Contents Contents Important information ..................4 Safety information ....................5 Preparation.....................6 Installing the electronics box ................7 Installing the display and display arm..............23 Adjusting the display arm ................. 37 Adjusting the display ..................39 User and service information ................40 Safety instructions ...................

  • Page 4: Important Information

    Please refer to the wheelchair’s User’s Manual for information about service and repairs. Reporting an incident Please contact Permobil or your dealer if you want to report an incident. The accessory does not have a serial number. However, if the accessory is attached to the wheelchair, we will ask for the wheelchair’s serial number.

  • Page 5: Safety Information

    Omni2 Corpus Safety information Safety information The following safety labels are used throughout this manual to draw attention to items of significant importance to safety: Labels Crushing Risk of crushing hands or other body parts. Notice Signal word used to indicate informative remarks.

  • Page 6: Preparation

    Omni2 Corpus Preparation Preparation Necessary tools Assembly kit...

  • Page 7: Installing The Electronics Box

    Installing the electronics box...
  • Page 9 d= 280 mm / 11”...
  • Page 11 Ƭ = 5.7 N m / 4.2 lb. ft. Ƭ = 1.2 N m / 0.9 lb. ft.
  • Page 13 d ≈ 5 mm / 0.2”...
  • Page 14 Armrest height 1–3 for Corpus: d = 45 mm / 1.77” Armrest height 4–5 for Corpus: d = 20 mm / 0.79” Corpus HD: d = 0–60 mm / 2.36”...
  • Page 15 Ƭ = 9.8 N m / 7.2 lb. ft.
  • Page 16 Ƭ = 1.2 N m / 0.9 lb. ft.
  • Page 17 d ≈ 4 mm / 0.16” Ƭ = 2.9 N m / 2.14 lb. ft.
  • Page 19 Ƭ =2.9 N m / 2.14 lb. ft.
  • Page 21 Ƭ =1.2 N m / 0.9 lb. ft.

  • Page 23: Installing The Display And Display Arm

    Installing the display and display arm ① Notice This manual only shows the assembly instructions for one side. page 41...
  • Page 24 Ƭ = 9.8 N m / 7.2 lb. ft.
  • Page 26 Ƭ = 9.8 N m / 7.2 lb. ft. Ƭ = 2.9 N m / 2.14 lb. ft.
  • Page 27 Ƭ = 2.9 N m / 2.14 lb. ft.
  • Page 30 d= 90 mm / 3.5”...
  • Page 32 Ƭ = 0.6 N m / 0.44 lb. ft.
  • Page 36 ① Crushing Risk of pinching or crushing hands and other body parts. page 41...

  • Page 37: Adjusting The Display Arm

    Adjusting the display arm Ƭ = 12.7 N m / 9.4 lb. ft. Ƭ = 12.7 N m / 9.4 lb. ft.
  • Page 38 Ƭ = 12.7 N m / 9.4 lb. ft.

  • Page 39: Adjusting The Display

    Adjusting the display Ƭ = 12.7 N m / 9.4 lb. ft. Ƭ = 12.7 N m / 9.4 lb. ft.

  • Page 40: User And Service Information

    Omni2 Corpus User and service information User and service information http://support.pgdt.com/Home/omni2-manual-pdf...

  • Page 41: Safety Instructions

    Omni2 Corpus Safety instructions Safety instructions Notice ① Notice U U S S : : This manual only shows the assembly I I T T : : Questo manuale illustra le istruzioni per instructions for one side. l'assemblaggio solamente per un lato.
  • Page 42 Omni2 Corpus Safety instructions S S L L : : S S V V : : Risk att klämma eller krossa händer och Nevarnost ukleščenja ali zmečkanja rok in drugih delov telesa andra kroppsdelar. E E S S : : Riesgo de pellizcarse o aplastarse las...

  • Page 43: Contact Us

    Omni2 Corpus Contact us Contact us Permobil AB Box 120 861 23 Timrå Sweden +46 60 59 59 00 Tel.: Fax: +46 60 57 52 50 E-mail: info@permobil.com Web: www.permobil.com Permobil Inc. 300 Duke Drive Lebanon, TN 37090 800.736.0925 Tel.: Fax: 800.231.3256...
  • Page 44 Produced and published by Permobil Edition: 3 Date: 2019-06-11 Order no: 335495 7 330818 355256...
