Car Interior LED Strip Light
Art.no 36-9992  Model LS520B-RGB-2M
Read the entire instruction manual before use and save it for
future reference. We apologise for any text and picture errors and
any changes of technical data. If you have any questions concer-
ning technical problems please contact our Customer Services.
Safety
Warning:
Never use the product if it is in any way damaged or malfun-
ctioning. Unplug the product immediately if it is damaged.
Do not use the product in environments where explosive or
flammable gases are stored or used.
The product must not be installed on a wet or electrically
conductive surface.
Make sure that the cable is not damaged whilst the product
is being installed.
Do not carry the product using the mains lead and do not
use it for other unsuitable purposes.
Never let children play with the product.
The product may be used by persons with reduced physical,
sensory or mental capabilities or persons with a lack of
experience or knowledge which could jeopardise their safety,
provided they have been instructed in the safe operation of
the product and understand the hazards involved.
Important
The LEDs cannot be replaced. When the LEDs have reached
the end of their service life, the entire product must be discar-
ded.
This product is intended only for private use.
Risk of eye damage. Do not look directly at
the light source.
The product is intended for indoor use only.
Class III strip light
Installation
Information
The LED strip light can be mounted using the double-sided
adhesive tape (mounted). For best adhesion, ensure that
the surface is clean, dry and free of grease.
The length of the light strip can be adjusted by cutting it at one of
the soldering points which are spaced every 4 cm along its length.
1
1. Strip light: Remove the protective film from the tape on the back
of the light strip and attach it to a clean, grease-free surface.
2. Connection cable USB-A: Connect the connection cable to a
USB adaptor.
3. IR Receiver. Note: Make sure there are no obstacles between
the IR receiver on the LED control unit and the remote control.
Remote control
4. [
] Increase light intensity
[
] Decrease light intensity
5. [ OFF ] Turn the strip light off
[ ON ] Turn the strip light on
6. [ R ] Red light, [ G ] Green light
[ B ] Blue light, [ W ] White light
12 colour tones within
the RGB spectrum
7. [ FLASH ] Change slowly
between all the colours
8. [ STROBE ] Change quickly
between all the colours
9. [ FADE ] Change between all
the colours, the colours fade
into one another
10. [ SMOOTH ] Change between all colours with no visible transition
Care and maintenance
Unplug the mains lead from the wall socket before cleaning.
The product should be cleaned using a dry cloth or vacuum
cleaner.
Responsible disposal
This symbol indicates that the product should not be
disposed of with general household waste. This applies
throughout the entire EU. In order to prevent any harm
2
to the environment or health hazards caused by incor-
rect waste disposal, the product must be handed in
for recycling so that the material can be disposed of
in a responsible manner. When recycling your product, take it
to your local collection facility or contact the place of purchase.
3
They will ensure that the product is disposed of in an environme-
ntally sound manner.
Specifications
5 V DC, max 2,5 W (sold separately)
USB-adaptor
Size
2000 × 10 mm
Light source
48 × LED
Cable length
1 m
Battery (remote) 1 × CR2025 (included)
