- Page 2 A small and portable modular system to exploit the full potential of Oneiroi. BEFORE YOU START If you want to add more modules to your Oneiroi Pod Unplug barrel cables and power brick cables from the Pod. Attach your module’s power ribbon cable to a 16-pin power header on the Pod.3. Place the module into the Pod so that all screw holes on the module’s faceplate line up with the screw holes on the Pod.
- Page 3 Size: 42HP Power input: Two barrel jacks for daisy-chaining, 15V-20VDC, 2.1mm positive tip Depth: 40mm Designed in collaboration with 4MS and the Befaco Team in Barcelona 2025. +12v: 140 mA For more information, please refer to the 4MS user manual...
