Befaco KICKALL V1C Assembly Manual

KICKALL V1C - ASSEMBLY GUIDE – Apr 2019
THANKS FOR CHOOSING ONE OF OUR KITS!
This manual has been written taking into account the common issues that we often find people
experience in our workshops. The order in which the components are placed on the board is
meant to make assembly as easy as possible.
Some steps are not obvious, so even if you're an experienced DIYer please read the steps
thoroughly before starting.
If this is your first project, please read this article before you start assembling the kit:
www.befaco.org/howto/
Or Take a look to our youtube channel:
https://www.youtube.com/user/Befacosynth/videos
HAVE FUN!
BAG A
RESISTORS
Qty Value Code
16
10k Brown, black, black, red, brown
12
100k Brown, black, black, orange, brown
8
470 Ohm Yellow, violet, black, black, brown
6
1k Brown, black, black, brown, brown
3 47k Yellow, violet, black, red, Brown
3 43k Yellow, orange, black, red, brown
2 Blue, gray, black, black, brown
680 Ohm
2
15k Brown, green, black, red, brown
2
22k Red, red, black, red, brown
2
120k Brown, red, black, orange, brown
3 1M Brown, black, black, yellow, brown
1 4.7M Yellow, violet, black, yellow, brown
1 Orange, white, black, black, brown
390 Ohm
1
1.8k Brown, gray, black, brown, brown
1
3k Orange, black, black, brown, brown
1
3k3 Orange, orange, black, brown, brown
1 4.3k Yellow, orange, black, brown, brown
1 4.7k Yellow, violet, black, brown, brown
1 5.6k Green, blue, black, brown, brown
1 20k Red, black, black, red, brown
1
27k Red, violet, black, red, brown
1
33k Orange, orange, black, red, brown
1
68k Blue, gray, black, red, brown
1 82k Gray, red, black, red, brown.
1 240k Red, yellow, black, orange, brown
1 330k Orange, orange, black, orange, brown
1 Blue, gray, black, orange, brown
680k
Name on PCB
R4, R15, R27, R28, R30, R31, R33, R35, R41, R43,
R101, R104, R107, R115, R120, R122
R3, R7, R14, R22, R29, R39, R100, R109, R110,
R112, R125, R126
R1, R5, R10, R17, R34, R37, R38, R40
R6, R8, R102, R117, R121, R123
R9, R45, R118
R26, R36, R42
R20, R116
R13, R129
R23, R113
R119, R128
R11, R19, R106
R103
R32
R12
R108
R105
R24
R44
R21
R111
R127
R25
R2
R124
R16
R114
R18
1
