PONY VCF V1- ASSEMBLY GUIDE – Rev. Mar. 2024
THANKS FOR CHOOSING ONE OF OUR KITS!
This manual has been written taking into account the common issues that we often find people experience in our
workshops. The order in which the components are placed on the board is meant to make assembly as easy as possible.
Some steps are not obvious, so even if you're an experienced DIYer please read the steps thoroughly before starting.
If this is your first project, please read this article before you start assembling the kit:
www.befaco.org/howto/
You will be soldering both boards at the same time. Keeping them in the panel together might help you through the build.
Check last pages of the Build for PCB pics to help you identify components.
HAVE FUN!
RESISTORS
Color code can be difficult to identify, we strongly recommend to use a multimeter.
Qty
Value
Code
25
100k
Brown, black, black, orange, brown
7
10k
Brown, black, black, red, brown
4
1k
Brown, black, black, brown, brown
3
18k
Brown, gray, black, red, brown
2
820k
Gray, red, black, orange, brown
2
20k
Red, black, black, red, brown
2
6k2
Blue, red, black, brown, brown
2
1k5
Brown, green, black, brown, brown
2
220 R
Red, red, black, black, brown
1
191k
Brown, white, brown, orange, brown R33 (place this resistor standing in order to fit in the PCB
1
160k
Brown, blue, black, orange, brown
1
56k
Green, blue, black, red, brown
1
43k
Yellow, orange, black, red, brown
1
13k
Brown, orange, black, red, brown
1
3k3
Orange, orange, black, brown, brown R100
1
100 R
Brown, black, black, black, brown
DIODES
Solder the diodes observing their polarity. The black or white line on the diode must match with the white line on the
diode symbol on the PCB silkscreen.
Qty
Value
5
1N4148
2
1N5817 (black)
Name on PCB
D3, D4, D5, D6, D100
D1, D2
Name on PCB
R1, R2, R5, R6, R7, R8, R9, R10, R11, R12, R17, R24, R28, R29, R31,
R32, R40, R41, R42, R43, R44, R45, R105, R109, R110
R18, R22, R23, R34, R36, R38, R39
R13, R104, R106, R111
R3, R4, R103
R19, R107
R101, R108
R15, R16
R35, R37
R25, R26
silkscreen)
R27
R102
R14
R30
R21
1
