- Page 1 INSTALLATION & MAINTENANCE MANUAL LEDM07B / LEDM07W...
-
Page 2: General Instructions
These instructions should be read carefully and retained after installation by the end user for future reference and maintenance. These instructions should be used to aid installation of the following products: LEDM07B / LEDM07W SAFETY • This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS7671) and current Building Regulations. - Page 3 Fig. 1 Cut-out with sleeve Cut-out without sleeve 60mm 50mm • We recommend not installing in areas where there is a high risk of flooding or areas where water may sit on top of the fitting (see Fig. 2) • Ensure a minimum of 300mm of drainage is put below the luminaire (see Fig. 2) Fig.
- Page 4 • Fig. 3 • Connect the luminaire to the mains supply ensuring the correct polarity is observed L - Live (brown), E - Earth (green/yellow), N - Neutral (blue). • Switch on and check for correct operation • WARNING • This product must be disconnected from the circuit if subjected to any high voltage or insulation resistance testing.
-
Page 5: Warranty
If this product should fail within its warranty period, it should be returned to the place of purchase for a free of charge replacement. ML Accessories does not accept responsibility for any installation costs associated with the replacement product. Your statutory rights are not affected. ML Accessories reserve... - Page 6 SUPPLIED BY: (UK) MANUFACTURER ML ACCESSORIES LTD, UNIT E CHILTERN PARK, BOSCOMBE ROAD, DUNSTABLE LU5 4LT, WWW.MLACCESSORIES.CO.UK (EU) AUTHORISED REPRESENTATIVE SLV LIGHTING GROUP, DAIMLERSTRASSE 21-23, 52531 ÜBACH-PALENBERG, GERMANY EMAIL: EPREL@GROUP.SLV.COM MADE IN CHINA 230V 35°C IP65 50Hz ML Accessories Limited LU5 4LT www.mlaccessories.co.uk...
