  • Page 1 Conshelf XIV Conshelf XIV Supreme User's Manual Rev 11/10...

  • Page 2: Copyright Notice

    Aqua Lung America, Inc. ©2010 Aqua Lung International CoNSheLF XIV User’s Manual p/N 108102 you can contact a technical Advisor via e-mail at: rbedard@aqualung.com...

  • Page 3: Table Of Contents

    CONSHELF XIV USER'S MANUAL Contents 1. general precautions & Warnings ......4 2. Introduction ............... 5 2.1 Product Description ..........5 3. preparation and Setup ..........6 3.1 Mounting the 1st Stage onto the Cylinder Valve ..6 3.1.1 Yoke Connector ..........6 3.1.2 DIN Connector ............7...

  • Page 4: General Precautions & Warnings

    Aqua Lung Service Technician. Repair, service, disassembly or first stage adjustment must not be attempted by persons who are not factory trained and authorized by Aqua Lung America Inc. WArNINg: DO NOT use the regulator first stage as a carry handle when lifting or transporting the cylinder as this can damage the regulator or the cylinder valve.

  • Page 5: Introduction

    Its performance will be guaranteed through annual inspection/ servicing by an Authorized Aqua Lung Technician. Before diving with your new Aqua Lung regulator it is important that you read this manual in its entirety so that you can familiarize yourself with its features and the rules for using the regulator before, during and after the dive so as to retain optimum performance for the years to come.

  • Page 6: Preparation And Setup

    CONSHELF XIV USER'S MANUAL 3. prepArAtIoN ANd Set Up Aqua Lung America, Inc. recommends that you bring your regulator to an Authorized Aqua Lung Technician for the installation of any accessory items, including instrumentation, LP quick disconnect hoses and alternate air sources.

  • Page 7: Din Connector

    DO NOT use tools to tighten (Fig 2). NOTE: The Conshelf XIV does not come standard with a DIN Connector. A DIN Adapter Kit , PN 107455, is available and can be installed by a Trained Technician.

  • Page 8: Pre-Dive Checks

    CONSHELF XIV USER'S MANUAL 3.2 pre-dive Checks Carefully inspect all hoses at their fittings to ensure they are secur connected onto their respective ports on the first stage. Inspect the length of each hose to ensure that the hoses are not blistered, cut or otherwise damaged.

  • Page 9: Regulator Mouthpiece

    Conshelf XIV Octopus Regulator (PN 108520) with a yellow hose or (PN 108525) with a black hose. It is recommended that the mouthpiece be covered to prevent the intrusion of foreign objects into the Conshelf XIV second stage octopus.

  • Page 10: After The Dive

    CONSHELF XIV USER'S MANUAL 5. AFter the dIVe 5.1 removal of the 1st Stage from the Cylinder Valve NOTE: If fresh water is available, rinse your regulator completely before depressurizing it. This will help to prevent contaminants from entering the sealing surfaces inside the regulator.

  • Page 11: Cleaning

    6. USer CAre ANd MAINteNANCe It is important to provide the proper preventative maintenance in order to ensure the best possible performance and maximum life of your Aqua Lung Regulator. The following maintenance procedures should be performed routinely after each use to ensure that the regulator is cleaned, inspected and prepared for the next use or for storage.

  • Page 12: Inspection And Service

    You must obtain factory prescribed service for your regulator at least once a year from an Authorized Aqua Lung Technician, regardless of the amount of use it has received. Your regulator may require this service more frequently, depending on the amount of use it receives and the environmental conditions in which it is used.

  • Page 13: Scheduled Service Exceptions

    CONSHELF XIV USER'S MANUAL 7.1 Scheduled Service exceptions If the regulator is subjected to less than 50 dives per year, it is permissible to overhaul it every other year with an inspection procedure being performed on the “off” years. For example: •...

  • Page 14: Annual Inspection & Service Record

    CONSHELF XIV USER'S MANUAL 8. ANNUAL INSPECTION & SERVICE RECORD Date Dealer Name Technician Name Observations Stamp...

  • Page 15: First Stage Exploded View

    Description ------107700 First Stage, Conshelf XIV 29 ----845097 Washer, Main Spring (non-supreme only) ------108810 First Stage, Conshelf XIV Supreme 30 ----101549 Adjustment Screw (coarse thread) ------108195 overhaul parts kit, Military (1st & 2nd Stage) ----- 106023 Adjustment Screw (fine thread)

  • Page 16: Second Stage Exploded View

    ------ 108530 Conshelf XIV Second Stage w/o hose ---- 108535 Box Bottom Kit (includes 16, 17 & 18) ------ 108538 Conshelf XIV Supreme Second Stage w/o hose 17---- 957025P O-ring (10 pk) ------ 108195 Overhaul Parts Kit, Military (1st & 2nd Stage)

  • Page 17: Notes

    CONSHELF XIV USER'S MANUAL NoteS...
  • Page 18 Conshelf XIV User's Manual 2340 Cousteau Court • Vista, CA 92081 Phone (760) 597-5000 • Fax (760) 597-4900 www.aqualung.com/militaryandprofessional ©2010 Aqua Lung International PN 108102 Rev 11/10...
