- Page 1 Regulator Owner’s Manual DOC/0258/US ISSUE 9...
- Page 2 Regulator Owner’s Manual .................... Copyright Notice This owner’s manual is copyrighted, all rights reserved. It may not, in whole or in part, be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine readable form without prior consent in writing from Apeks. ©2012 Apeks Regulator Owner’s Manual Please read the instructions in this manual carefully before using your...
-
Page 3: Table Of Contents
Regulator Owner’s Manual .................... Contents: General Precautions & Warnings....................4 Introduction..........................5 Enriched Air Nitrox Use (EAN)....................7 Enriched Air Nitrox Use – Outside EEC (European Economic Community) Countries...7 Enriched Air Nitrox Use – Inside EEC (European Economic Community countries EN 1443-3 and EN13949.................8 Overview of Features......................10 Second Stage Hose Configuration.................10 Diver Changeable Exhaust System (DCE)..............11... -
Page 4: General Precautions & Warnings
Regulator Owner’s Manual .................... General Precautions & Warnings • B efore using this regulator, you must receive instruction and certification in SCUBA diving from a recognised training agency. Use of SCUBA equipment by uncertified or untrained persons is dangerous and can result in injury or death. • T his regulator is not configured for commercial use with surface supplied air. • A lways pressurise the regulator gradually by opening the cylinder valve SLOWLY. • U nless instructed, NEVER apply any type of lubricant to any part of the regulator or cylinder valve. -
Page 5: Introduction
Regulator Owner’s Manual .................... INTRODUCTION Congratulations—and thank you—for choosing Apeks. All Apeks regulators have been designed and manufactured with pride in the U.K. as part of the Aqualung group of companies, according to standards which meet or surpass all requirements for the BS EN ISO 9001:2000 quality control system. Your Apeks regulator is covered by Apeks’ Limited Lifetime Warranty against defects in materials or workmanship. - Page 6 NOTE: EN250:2000 Respiratory equipment – Open Circuit Self Contained Compressed Air Diving Apparatus – Requirements, Testing and Marking is a European normative standard that was published in the year 2000, and Regulators must be independently tested to ensure it meets these minimum requirements.
-
Page 7: Enriched Air Nitrox Use (Ean)
Regulator Owner’s Manual .................... ENRICHED AIR NITROX USE (EAN) WARNING : This chapter contains important information concerning use with oxygen-enriched air (Nitrox/EAN). Do not attempt to use this product with enriched air without having entirely read and understood this chapter. If you do not do this, you risk serious injury or death. WARNING : Obtain Nitrox Diving Certification. -
Page 8: Enriched Air Nitrox Use - Inside Eec
Regulator Owner’s Manual .................... Standard compressed breathing air meeting the EN 12021 standard, often referred to as Grade E in the United States, does not necessarily meet this criterion. Grade E or EN 12021 breathing air may contain a certain level of hydrocarbons, including traces of compressor oils that while not considered harmful to breathe, can pose a risk in the presence of elevated oxygen content. - Page 9 Regulator Owner’s Manual .................... WARNING : These regulators fitted with special connections should be used only with complementary equipment (tank valves, tanks, pressure gauges, etc.) designed and prepared for use with an oxygen-enriched mixture. These items are marked Nitrox/O2. WARNING: If the regulator that you use is fitted with a yoke or DIN connection, it is designed for use only with compressed breathing air (21% oxygen and 79% nitrogen) which meets the EN 12021 standard.
-
Page 10: Overview Of Features
Regulator Owner’s Manual .................... OVERVIEW OF FEATURES The Apeks family of regulators consists of different models which satisfy a wide range of diving interests; from entry level sport diving, to advanced diving in more demanding and extreme conditions. By now, your authorised dealer has already explained to you the specific features that your particular model offers, and you have made your purchase after comparing the benefits of these features to your personal diving needs and interests. -
Page 11: Diver Changeable Exhaust System (Dce)
Regulator Owner’s Manual .................... Diver Changeable Exhaust system (DCE) The Diver Changeable Exhaust (DCE) offers the choice of either a compact lightweight system or a longer exhaust diffuser. DCE can be configured to prevent virtually any bubble interference from obscuring the diver’s view. - Page 12 Regulator Owner’s Manual .................... CAUTION! Ensure location grooves are free from dirt and debris. 3. Refitting the exhaust diffusers is carried out by sliding ONE diffuser at a time onto the case, once both diffusers are located on the LOCATE case, squeeze the two diffusers together until you hear an audible...
-
Page 13: External Second Stage Adjustments
Regulator Owner’s Manual .................... External Second Stage Adjustments External adjustment features offer many advantages, including the ability to adjust your second stage regulator’s sensitivity as your diving conditions change. This allows you to maintain peak performance throughout every dive, or to desensitise your regulator’s opening effort at times when you are not breathing from it. -
Page 14: Inhalation Resistance Control Knob
Regulator Owner’s Manual .................... Inhalation Resistance Control Knob Some second stage models are equipped with an additional adjustment, which controls inhalation resistance. This control knob, located beside the IVS/RVS switch, adjusts the amount of effort required to start the air flow at the beginning of the inhalation cycle. -
Page 15: Egress Second Stage
Regulator Owner’s Manual .................... Egress Second Stage The Egress is a low profile second stage suitable for use in all diving conditions, and can be used either way up due to its side exhaust and hose layout. Therefore the diver can use the second stage with the hose routed from either the left... -
Page 16: Status
Regulator Owner’s Manual .................... STATUS STATUS..REASSURANCE THAT YOUR REGULATOR IS AT ITS OPTIMUM Safety first Safety is of paramount importance to Apeks. The Status electronic first stage gives divers the option, for the first time ever, to visually check the condition of the first stage of the regulator using an integrated LCD display before actually commencing a dive. -
Page 17: Servicing
Regulator Owner’s Manual .................... Servicing Another unique safety feature of the Status regulator is that it monitors the usage, in hours and calendar months, from when the regulator is first used or last serviced. The diver is informed that the first stage requires servicing by a flashing “SVC”... -
Page 18: Status Condition Display Guide
Regulator Owner’s Manual .................... Status Condition Display Guide Medium pressure too high “DO NOT DIVE!” LO - Medium pressure too Low “DO NOT DIVE!” SVC - Regulator requires servicing Complete dive, & ensure the status regulator is inspected / serviced by an Authorised Apeks service technician. -
Page 19: Cold Water Diving
Regulator Owner’s Manual .................... Cold Water Diving Note: During low temperatures & cold water diving the Status LCD display will slowly appear faint, then become much brighter. It is advised that you check your Status first stage regulator in more ambient temperatures. If The Status fails to display Note: To re-check the Status, the regulator must be de- pressurised by closing the cylinder valve and purging the second... -
Page 20: Warranty Restriction
Regulator Owner’s Manual .................... WARNING: Obtain service for your regulator at least once a year, from an authorised dealer. Your personal safety and the mechanical integrity of your regulator may depend on it. CAUTION: if the Status displays sequence “SVC” C,D or E as above DO NOT continue to dive until your regulatorhas been inspected/serviced by an authorised Apeks service technician.
