- Page 1 POSITIVE PRESSURE INLET FAN (PPF) Product Manual www.ves-artex.com 1.888.622.2999 SAVE THIS MANUAL FOR FUTURE REFERENCE...
-
Page 2: Table Of Contents
NSTALLATION ELECTRICAL INSTALLATION ........................15 ............................... 15 OTOR ABEL PPFV36 (101296) Motor Label ........................15 PPFV36 (105309) Motor Label ........................15 PPFD55 (118013) Motor Label ........................16 PPFD55 (118015) Motor Label ........................16 PPFS55 (101284) Motor Label ........................16 PPFV72 (118001) Motor Label ........................17 PPFS72 (104346) Motor Label ........................ - Page 3 REPLACEMENT PARTS ..........................25 ..........................25 CTUATED HUTTER ............................. 25 UTLET UARD ............................. 26 OUND UARD ..............................26 UARD TROUBLESHOOTING ..........................27 GLOSSARY ..............................27 WARRANTY ............................... 28 1313 Lakeland Drive, Chippewa Falls, WI 54729, United States | 715.720.0800 www.ves-artex.com...
-
Page 4: Product Numbers
PPFS72 Belt Drive FAN HIGHLIGHTS VES-Artex Positive Pressure (PPF) fans are designed to inject fresh air into barns, parlors, or holding areas. They are also great additions to facilities where other inlets are not enough. PPF fans help reduce static pressure by forcing air into the barn, providing more air to circulate directly to the herd. -
Page 5: Attachments
Positive Pressure Inlet (PPFS) ATTACHMENTS Note: The renderings shown below may not match your attachment, but the information is the same. Actuated Shutter Kit (ASK) Outlet Guard Round Guard • PPFV36 (101296) • PPFV36 (101296) • PPFV36 (101296) • PPFV36 (105309) •... -
Page 6: Target Audience
Read and understand this manual before installing or servicing your VES-Artex product. For the safe handling of VES-Artex products, you will find the following safety words: DANGER, WARNING, CAUTION, and NOTICE throughout this manual. These will identify safety levels as described below. -
Page 7: General Safety
5. Falling damage. Mount fans with 5. Ensure all fan parts are VES-Artex-approved hardware. accounted for before 6. Always wear personal protective installation. equipment when installing and servicing VES-Artex products. 1313 Lakeland Drive, Chippewa Falls, WI 54729, United States | 715.720.0800 www.ves-artex.com... -
Page 8: Unpacking
Positive Pressure Inlet (PPFS) UNPACKING GENERAL AUTION OTICE 1. Use extreme care when 1. Once a VES-Artex product is unpacking the fan. received, inspect the product 2. Do not remove zip ties (if for any damage. It is present) during transportation... -
Page 9: Handling
OTICE 1. Be sure to follow all dimensions listed in the manual or the warranty will be void. Contact VES-Artex if you are unsure of the dimensions listed. 2. The hoisting chain must be rated to hold the fan. 1313 Lakeland Drive, Chippewa Falls, WI 54729, United States | 715.720.0800... -
Page 10: Fan Framing
Width Height Frame Side to Side to Top to Width Rough Rough Rough Opening Opening Opening PPFV36 101296 40 (101.5) 40 (101.5) 7 (17.78) 5.5 (14) 6 (15.2) 2.75 (7) PPFV36 105309 40 (101.5) 40 (101.5) 7 (17.78) 5.5 (14) 6 (15.2) -
Page 11: Cross Section Width
A – Min. Wall B – Actuated Weight lb Weight Number Thickness Shutter Kit (kg) (includes (ASK) Opened ASK) lb (kg) PPFV36 101296 8.5 (22) 21 (53) 125 (56.7) 225 (102) PPFV36 105309 8.5 (22) 21 (53) 125 (56.7) 225 (102) -
Page 12: Fan Assemblies
-Center Outer Spacing Center- Outer Fans Distance Distance Between to-Center Distance Beams Distance PPFV36 101296 10.5 (27) 48 (121.9) 84 (213.3) 12 (30) 48 (121.9) 84 (213.3) PPFV36 105309 10.5 (27) 48 (121.9) 84 (213.3) 12 (30) 48 (121.9) 84 (213.3) -
Page 13: Attachment Assemblies
4. Place the square guard on the face of the fan with the motor cut-out orientated to go over the portion of the motor sticking out. 5. Secure the guard using the hardware supplied. 1313 Lakeland Drive, Chippewa Falls, WI 54729, United States | 715.720.0800 www.ves-artex.com... - Page 14 The outer edge of the flange should be marked at 3.25” from the inside edge of the rough opening to ensure that the unit is centered in opening secure using the 24- lags and washer. 1313 Lakeland Drive, Chippewa Falls, WI 54729, United States | 715.720.0800 www.ves-artex.com...
-
Page 15: Electrical Installation
Failure to comply with instructions could result in fire, electric shock, injury to persons, and/or damage to equipment. MOTOR LABEL PPFV36 (101296) Motor Label PPFV36 (105309) Motor Label 1313 Lakeland Drive, Chippewa Falls, WI 54729, United States | 715.720.0800 www.ves-artex.com... -
Page 16: Ppfd55 (118013) Motor Label
Positive Pressure Inlet (PPFS) PPFD55 (118013) Motor Label PPFD55 (118015) Motor Label PPFS55 (101284) Motor Label 1313 Lakeland Drive, Chippewa Falls, WI 54729, United States | 715.720.0800 www.ves-artex.com... -
Page 17: Ppfv72 (118001) Motor Label
PPFV72 (118001) Motor Label PPFS72 (104346) Motor Label MOTOR WIRING VES-Artex does not supply the motor-to-control interconnecting wires. These must be supplied by the installer. All Electrical work must be completed by a licensed electrician in accordance with all Local and National electrical and safety codes, as well as the National Fire Protection Agency (NFPA) where applicable. - Page 18 SMV terminal 2 to Protec GND o SMV terminal 5 to Protec AI1 o SMV terminal 1 to Protec DI1 o SMV terminal 4 to Protec 24V (one VFD per group) 1313 Lakeland Drive, Chippewa Falls, WI 54729, United States | 715.720.0800 www.ves-artex.com...
-
Page 19: Controlling Multiple Vfds: Wiring Diagram
(rigid or flexible) liquid-tight conduit that is properly grounded to prevent interference from the connecting harness. KEYPAD FUNCTIONS 1313 Lakeland Drive, Chippewa Falls, WI 54729, United States | 715.720.0800 www.ves-artex.com... -
Page 20: Parameters
Positive Pressure Inlet (PPFS) PARAMETERS SET THESE PARAMETERS FOR STANDARD VES-ARTEX APPLICATIONS: 1313 Lakeland Drive, Chippewa Falls, WI 54729, United States | 715.720.0800 www.ves-artex.com... -
Page 21: Shutter Powered Actuator Wiring
“open” or “close” the circuit, outputting a group of fully open or close passive signals. NOTICE The internal circuit of the actuator is shown in the dotted frame. 1313 Lakeland Drive, Chippewa Falls, WI 54729, United States | 715.720.0800 www.ves-artex.com... -
Page 22: Maintenance Schedule
6 Months General cleaning: Wipe blade surfaces. ARNING To avoid shock injury or catastrophic electrical damage to VES-Artex products, do not use pressurized water on the motor or control. Introducing pressurized water will void the warranty. Inspect blades for any irregularities. -
Page 23: Maintenance Guidelines
Control 6 Months Remove dust from the heat sink. WARNING To avoid shock injury or catastrophic electrical damage to VES-Artex products, do not use pressurized water on the motor or control. Introducing pressurized water will void the warranty. Wiring 12 Months Check the integrity of the electrical wiring. -
Page 24: Routine Maintenance
High temperatures are harmful to motor performance. For this reason, avoid tight-fitting mounting and safety guards that may obstruct the ventilation openings. • Prevent obstructions from fan inlets and outlets that haven’t been designed by VES-Artex. REPAIR GUIDELINES Fan Model Description... -
Page 25: Replacement Parts
Positive Pressure Inlet (PPFS) REPLACEMENT PARTS ACTUATED SHUTTER KIT Part Number Description 101772 PPFV36, Actuated Shutter Kit 101757 PPFD55, Actuated Shutter Kit 101623 PPFS55, Actuated Shutter Kit 101765 PPFV72, Actuated Shutter Kit 101645 PPFS72, Actuated Shutter Kit OUTLET GUARD Part Number... -
Page 26: Round Guard
Positive Pressure Inlet (PPFS) ROUND GUARD Part Number Description 100586 PPFV36 (101296), Round Guard 105275 PPV36 (10530), Round Guard 100597 PPFS55, Round Guard 116327 PPFV72, Round Guard 104955 PPFS72, Round Guard FLAT GUARD Part Number Description 105277 PPFD55, Flat Guard 1313 Lakeland Drive, Chippewa Falls, WI 54729, United States | 715.720.0800... -
Page 27: Troubleshooting
Error acknowledgment (“Acknowledge in Error”) Actuated Shutter Kit. Box with deflectors on the inlet side of a PPF that opens by a mechanical actuator (72 and 55 PPFs and PPFD) 1313 Lakeland Drive, Chippewa Falls, WI 54729, United States | 715.720.0800 www.ves-artex.com... -
Page 28: Warranty
LIMITED WARRANTY & RETURN POLICY THERE ARE NO WARRANTIES THAT EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF. See any updated warranty and policy information on the VES-Artex website: www.ves- artex.com/ves-artex-warranty/. 1313 Lakeland Drive, Chippewa Falls, WI 54729, United States | 715.720.0800...
