Summary of Contents for Global Bridges II Power Beam
- Page 1 Bridges II Power Beam Effective Aug 2024 Canada...
-
Page 2: Required Installation Tools
• Watch for the sharp ends of staples when removing the packaging from around panels. Please contact your Global Contract Service Representative at 416-739-5000 for any questions or concerns. NOTE: Any alterations to listed components will void the manufacturer’s warranty. The turer’s specifications. - Page 3 POWER BEAM INSTALLATION Introduction The Bridges II Power Beam run typically consists of a Starter Beam (self supporting, characterized by two feet) and an Add-on Beam (characterized by a single foot, where the “foot-less” leg is connected to the leg of a Starter Beam).
- Page 4 POWER BEAM INSTALLATION Beam - Feet Begin by inserting feet into the beam vertical extrusion. STEP 1: Insert the foot into the bottom of vertical extrusion. STEP 2: Secure leg with supplied #6 screws Round foot attaches in the same manner for post application (90/45/60) or alternate layouts.
- Page 5 POWER BEAM INSTALLATION Beams - Levelling STEP 1: Identify the highest floor elevation in the room (usually next to a wall or column). Adjust vertical level of the 1st leg and tighten two set screws locking the foot’ s angle and height in place.
- Page 6 POWER BEAM INSTALLATION Embedded PET Felt and Glass STEP 1: Align the Top trim end with the Bridges II Power Beam vertical extrusion. STEP 2: Secure the trim extrusion to the Bridges II Power Beam with supplied selfdrill- ing screws.
- Page 7 POWER BEAM INSTALLATION Embedded PET felt and Glass Embedded Glass STEP 3: Place supplied translucent gaskets across the gap, evenly spaced as il- lustrated. STEP 4: Press the glass into the extrusion groove while ensuring that the translucent gaskets remain in place, filling the gap and making the glass snug. CANADA globalfurnituregroup.com...
- Page 8 POWER BEAM INSTALLATION Overpanel and Tiles Over Panels STEP 1: Remove the top cover trim from the power beam. STEP 2: Insert brackets on both sides of the over panel into the exposed vertcal extru- sions and push down. (Attach side by side with capture strips as necessary). STEP 3: Attach top cover trim to the top of the over panel.
- Page 9 POWER BEAM INSTALLATION Overpanel and Tiles Tile Installation: Glazed Tiles STEP 1: Snap in side covers. STEP 2: Place glazed tile bottom retaining extrusion so that groove A faces the “glaazed” panel side. STEP 3: Insert tile’s upper lip into groove in over panel’s top horizontal member. STEP 4: Swing tile down with one hand, as you do so, angle the bottom retaining extrusion with the other had so that retaining groove A captures glass bottom edge B.
- Page 10 POWER BEAM INSTALLATION End of Run Trim STEP 1: Align Vertical end trim end with the Bridges II Power Beams horizontal extru- sion. STEP 2: Secure the end trim with supplied capture strips. CANADA globalfurnituregroup.com...
- Page 11 POWER BEAM INSTALLATION Electrical Connection to the Power Supply Once you have all the electrical components in the power beams, it is recommend- After the connection has been completed, close metal junction boxes and ed that you check the entire installation against the electrical plans, ensuring that activate the power.
-
Page 12: Duplex Receptacle
POWER BEAM INSTALLATION Duplex Receptacle BE8D1/BE8D2/BE8D3/BE8DA Duplex Receptacle After cables, jumpers, power feeds and power distribution housings are connected and installed in the Power Beams. Install duplex receptacles at the specified locations (do not connect power feed to building power supply yet). Note: It is important to follow your electrical plans exactly since these were created based on maximum current capacity of each circuit. -
Page 13: Ceiling Feed
POWER BEAM INSTALLATION Ceiling Feed STEP 1: Remove post top cap. STEP 2: Identify proper length of Post Extension (BEPE). Cut to desired length (if necessary). Ensure that Post Extension will protrude 6” above ceiling tile. STEP 3: Locate Post Extension over selected Post. Use a level to position Post Extension accurately and trace outline on ceiling tile. - Page 14 POWER BEAM INSTALLATION Base Feed Power STEP 1: Hook the top Base feed bracket over the upper hole edge. STEP 2: Align the bracket with the extrusion and secure it with two supplied self-drilling screws. STEP 3: Insert the pin in the bottom Base feed bracket into the upper hole. STEP 4: Align the bracket with the extrusion and secure it with two supplied self-drilling screws.
- Page 15 STEP 8: Align 4 oblong holes in the shroud with threaded holes in top and bottom brackets. Secure the shroud with 4 machine screws. All three Bridges II Power Beam heights (18” 26” and 34”) utilize one Base feed har- ness housed inside of three heights of Base Feed shrouds.
- Page 16 POWER BEAM INSTALLATION Power Beam Tube STEP 1: Screw bottom of tube to bracket. (Zipper stops are at this end.) BR00565002 No.8 x 3/8” Thread Forming Screw QTY: 2 CANADA globalfurnituregroup.com...
- Page 17 STEP 1: Using the wood screws attach the Boulevard Aluminum Flat End Trim into provided pilot holes on the Gallery panel. STEP 2: Engage a Bridges II Power Beam with the Gallery panel so that the vertical knuckles interlock with the grooves on the Flat End Trim.
- Page 18 Global offices in Canada Head Office Toronto Sales Office Moncton 560 Supertest Road 1350 Flint Road 268 Coverdale Road Toronto, Ontario Toronto, Ontario Riverview, New Brunswick M3J 2M6 M3J 2J7 E1B 3J2 T (416) 650-6500 T (416) 661-3660 T (506) 858-8383...
