- Page 1 SERVICE MANUAL PARTS LIST SHAMPOO POLISHER MODELS: P-1800 P-2500 A P-2600 KOBLENZ ELECTRICA S.A. DE C.V. NOVEMBER-06 LP-P1800-200611 E-mail: thorne_scsm@koblenz-electric.com 1/14 November / 2006...
- Page 2 INDEX PAGE I.- FINAL TEST FOR PRODUCT SAFETY II.- REPLACEMENT PROCEDURES III.- TROUBLE SHOOTING CHART IV.- ELECTRICAL RATING V.- WIRING DIAGRAM VI.- SCHEMATIC EXTERNAL MACHINE PARTS VII.- EXTERNAL MACHINE PARTS LIST VIII.- SCHEMATIC INTERNAL PARTS IX .- INTERNAL MACHINE PARTS LIST 2/14 November / 2006...
-
Page 3: Electric Test
I. - FINAL TEST FOR PRODUCT SAFETY AT THE COMPLETION OF ANY REPAIR THE PRODUCT SHOULD BE ELECTRICALLY TESTED FOR RUNNING AND ELECTRIC STRENGTH AS FOLLOWS ELECTRIC TEST A). - Set hi-pot meter at 1500 V B). -Product Switch to on position. C). - Page 4 II. - REPLACEMENT PROCEDURES ASSEMBLY 1.TO REPLACED A FIELD ( 67 ) OR ARMATURE ( 63 ) 1.1.-Disconnected elbow hose connector ( 51 ) from tray assembly ( 95 ) 1.2.- Remove cover ( 35 ) by removing four cover screws ( 93 ) 1.3.-Pull open the connector on the motor cable ( 24) 1.4.- Remove the connector support ( 87 ) with the connector block ( 75 ) 1.5.-Remove gear cover plate screws ( 61 ) from both sides along with cover plates and gaskets ( 84-85-86 )
- Page 5 3.17.-The gear boxes should be regressed with the grease provided in the bag together with the gears ,making sure all the grease is used ,the most of it applied in the contact zone of the gears 3.18.-Reassembly cover plates ,cover plate gaskets (84-85-86),motor cover ( 60 ) and screws ( 61-92) on reverse order used for disassembly .
- Page 6 9 .-TO REPLACE A FAULTY BRUSH SPINDLE INSULATOR ( 96 A ) ( ONLY MODELS WITH DRIVE PINS ) 9.1.-Remove the spindle drive pin ( 96 D ) by driving it out with a cylindrical punch of suitable diameter and remove the pin insulator ( 96 E ) 9.2.-Remove the spindle cap insulator ( 96 A ) by pressing the tab ( 96 C ) and pulling the cap insulator out .
-
Page 7: Troubleshooting Chart
III.- TROUBLE SHOOTING CHART PROBLEM POSSIBLE CAUSE SOLUTlON A) Defective Switch. Replace switch . B) Defective power cord. Replace power cord. Check wire connection at switch ,check 1) Shampooed / Polisher does not C) Defective internal wiring. motor cord check armature and held and D) Motor failure. -
Page 8: Electrical Rating
IV.- ELECTRICAL RATING 50/60 V .- WIRING DIAGRAM 8/14 November / 2006... - Page 9 VI.- SCHEMATIC EXTERNAL PARTS LIST 9/14 November / 2006...
- Page 10 VII.- EXTERNAL MACHINE PARTS LIST P-1800 P-2500-A P-2600 PART. No. DESCRIPTION 13-0947-5 HANDLE GRIP 23-0391-5 UPPER HANDLE TUBE CHROMED 23-0257-8 UPPER HANDLE TUBE 23-0705-6 UPPER HANDLE TUBE BLUE 05-3040-2 LOWER HANDLE TUBE (CHROME) 05-2710-1 LOWER HANDLE TUBE CHROMED 05-3686-2 LOWER HANDLE TUBE BLUE 01-0536-1 SELF-TAPPING SCREW #6-20 13-0950-9...
- Page 11 PART. No. DESCRIPTION P-1800 P-2500-A P-2600 26-D 05-3190-5 SOCKET 26-E 05-0420-2 CONCAVE WASHER 26-F 02-0092-3 SECURITY NUT 01-0883-7 HEX SCREW 1/4-20 05-3297-8 YOKE SPRING COVER CHROMED 05-3298-6 YOKE SPRING COVER, GREY 25-1072-5 YOKE SPACER 24-0258-4 EXTERIOR YOKE SPRING 06-0700-2 POLISHER COVER 06-0701-0 DIE CAST COVER, PAINTED 01-1483-5...
- Page 12 VIII .- SCHEMATIC MACHINE INTERNAL PARTS 12/14 November / 2006...
- Page 13 IX,- INTERNAL MACHINE PARTS LIST PART. No. DESCRIPTION P-1800 P-2500 P-2600 13-1418-6 MOTOR COVER 01-1483-5 SELF-TAPPING SCREW #6 X 3/8 28-0324-5 BRUSH HOLDER ASS 62-A 46-0104-3 CARBON BRUSH & SPRING 62-B 46-0590-3 BRUSH HOLDER 28-0263-5 ARMATURE 01-1489-2 SCREW #8 X 1 1/2 05-2862-0 FIELD SUPPORT 05-2864-6...
- Page 14 610 Lanark Suite 205 San Antonio TX ,78218 Tel (210) 590-1226 Fax (210) 590-1258 1-800-548-5741 FACTORY Koblenz Electrica ,S.A. de C.V. Av. . Ciencia No 28 Cuautitlán Izcalli Edo. de México ,C.P. 54730 Tel : 5864-0300 Web site : http://www.koblenz.electric.com KOBLENZ ELECTRICA S.A.
