Koblenz B-1500-C Service Manual And Parts List
Koblenz B-1500-C Service Manual And Parts List

Koblenz B-1500-C Service Manual And Parts List

Hide thumbs Also See for B-1500-C:

Advertisement

Error: No se encuentra la fuente de referencia
SERVICE MANUAL
PARTS LIST
BURNISHER
MODELS:
B-1500-C
317 N. Main Street
Piqua, Ohio 45356
937-778-2275
www.procarejanitorsupply.com
KOBLENZ ELECTRICA S.A. DE C.V.
E-mail:
thorne_scsm@koblenz-electric.com
1/12
September-09
LP-BUR-200909
September
/ 2009

Advertisement

loading
Need help?

Need help?

Do you have a question about the B-1500-C and is the answer not in the manual?

Questions and answers

Summary of Contents for Koblenz B-1500-C

  • Page 1 Error: No se encuentra la fuente de referencia SERVICE MANUAL PARTS LIST BURNISHER MODELS: B-1500-C 317 N. Main Street Piqua, Ohio 45356 937-778-2275 www.procarejanitorsupply.com KOBLENZ ELECTRICA S.A. DE C.V. September-09 LP-BUR-200909 E-mail: thorne_scsm@koblenz-electric.com 1/12 September / 2009...
  • Page 2: Table Of Contents

    INDEX PAGE I.- FINAL TEST PRODUCT SAFETY II.- REPLACEMENT PROCEDURES ASSEMBLY III.- TROUBLE SHOOTING CHART IV.- ELECTRICAL RATING V.- WIRING DIAGRAM VI.- PARTS LIST VII.- ASSEMBLY 2/12 September / 2009...
  • Page 3: Ii.- Replacement Procedures Assembly

    I. FINAL TEST FOR PRODUCT SAFETY AT THE COMPLETION OF ANY REPAIR THE PRODUCT SHOULD BE ELECTRICALLY TESTED FOR OPERATING AND ELECTRIC TEST AS FOLLOWS ELECTRIC TEST A). - Set hi-pot meter at 1500 V B): -Place Switch Lock to on position. c).
  • Page 4 2.- BELT REPLACEMENT (36) 2.1. - Follow steps indicated on point 1.2, 1.3 and 1.4 2.2. - Replace belt (36) and reassemble make sure that the pulleys aligned 3. - PULLEY AXLE REPLACEMENT (26) 3.1. - Follow steps 1.2, 1.3, and 1.4 3.2.
  • Page 5: Follow Steps Indicated On Point 1.2, 1.3 And

    9. - LINE CORD REPLACEMENT (105) 9.1.-Follow steps 5.1, 5.2 and 5.3. 9.2. - Disconnect ground (green) as well as connection micro switch (85) and the connect to thermal protector (77) 9.3.-Remove the nut from the effort relief assembly (103) 9.4.
  • Page 6: Iii.- Trouble Shooting Chart

    III. - TROUBLE SHOOTING CHART 1. MOTOR DOES NOT START POSSIBLE CAUSE SOLUTION NOT PLUGGED IN PROPERLY CHECK CONNECTION LINE CORD DAMAGED REPLACE MICRO SWITCH DAMAGED REPLACE MICRO SWITCH CIRCUIT BREAKER OFF RESET BREAKER CAPACITOR DAMAGED REPLACE CAPACITOR MOTOR LINE CORD DAMAGED REPLACE MOTOR LINE CORD MOTOR ASSEMBLY DAMAGED REPLACE MOTOR ASSEMBLY...
  • Page 7: Iv.- Electrical Rating

    IV. ELECTRICAL RATING / 120 V ~ 60 Hz 15 A V.-WIRING DIAGRAM 7/12 September / 2009...
  • Page 8: Vi.- Parts List

    PART No. DESCRIPTION 17-3036-5 Motor Cover Label 12-0414-8 Grommet Heyco 0.062 28-0671-9 Motor Cable / Contact Assembly 05-3765-4 Motor Cover 17-3025-8 Koblenz Label 12-0692-9 Motor Cover 01-1683-0 Screw 8-32 x ¼ 00-1736-8 Induction Motor 15-0675-7 Capacitor 40 MFD 08-0979-8 Insulator Capacitor...
  • Page 9: Starting Lever

    ITEM PART No. DESCRIPTION 45-0534-3 Security Assy Spare Part 73-A 01-0272-3 Screw # 6 x 1/2 73-B 13-2209-8 Security Button 73-C 13-2205-6 Piston of the Insurance 73-D 13-2206-4 Sucure 73-E 13-2208-0 Cover Box 73-F 01-1732-5 Screw # 8-32 x 1/2 " 73-G 37-0225-5 Dust Cover...
  • Page 10 Assembly control dust 46 - 3572 - 8 ITEM PART No DESCRIPTION 45-0768-7 Quick connector 01-1374-6 Screw 6-32x3/8 04-0493-9 Washer Star int. 02-0126-9 Nut elastic 13-3694-0 Cover 45-0760-4 Hinge 45-0767-9 KIT Bag Filter (3 PZ) 56-A 45-0761-2 Filter Bag ( single ) 01-2157-4 Screw Flat-Head 6-32x3/8 13-3695-7...
  • Page 11: Vii.- Assembly

    VII.- ASSEMBLY 11/12 September / 2009...
  • Page 12 610 Lanark Suite 205 San Antonio TX ,78218 Tel (210) 590-1226 Fax (210) 590-1258 01-800-548-5741 FACTORY Koblenz Eléctrica, S. A. de C. V. Av. Ciencia No 28 Cuautitlán Izcalli Edo. de México ,C.P. 54730 Tel : 01-55-5864-0300 Web site : http://www.koblenz-electric.com KOBLENZ ELECTRICA S.A.
