SERVICE MANUAL

PARTS LIST

BURNISHER
MODELS:
B-1500 P
B-1500 DC
KOBLENZ ELECTRICA S.A. DE C.V.
October-06
LP-B1500-200610
E-mail:
thorne_scsm@koblenz-electric.com
1/10
October
/ 2006

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B-1500 DC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Koblenz B-1500 DC

  • Page 1: Parts List

    SERVICE MANUAL PARTS LIST BURNISHER MODELS: B-1500 P B-1500 DC KOBLENZ ELECTRICA S.A. DE C.V. October-06 LP-B1500-200610 E-mail: thorne_scsm@koblenz-electric.com 1/10 October / 2006...
  • Page 2 INDEX PAGE I.- FINAL TEST PRODUCT SAFETY II.- REPLACEMENT PROCEDURES ASSEMBLY III.- TROUBLE SHOOTING CHART IV.- ELECTRICAL RATING V.- WIRING DIAGRAM VI.- PART LIST VII.- ASSEMBLY 2/10 October / 2006...
  • Page 3: Ii.- Replacement Procedures Assembly

    I. FINAL TEST FOR PRODUCT SAFETY AT THE COMPLETION OF ANY REPAIR THE PRODUCT SHOULD BE ELECTRICALLY TESTED FOR OPERATING AND ELECTRIC TEST AS FOLLOWS ELECTRIC TEST A). - Set hi-pot meter at 1500 V B): -Place Switch Lock to on position. c).
  • Page 4 2..-TO REPLACED BELT ( 77 ) 2.1,- Follow steps indicated on point 1-2,1-3 and 1-4 2.2.- Replace belt and reassemble alignments from pulleys 3..- PULLEY AXLE REPLACEMENT ( 87 ) 3.1.- Follow steps 1-2,1-3, and 1-4. 3.2.- Remove the elastic bolt ( 94 ) pressure washer ( 95 ) and flat washer ( 93 ) 3.3.- Remove the pulley flex disc ( 90 ) which is assembled with two bearings ( 91 ) the bearing separator ( 92 ) and clamp ( 89 ) 3.4.- Remove the four bolts ( 88 ) pressure washer ( 79 ) remove the pulley axle and reassemble.
  • Page 5: Iii.- Trouble Shooting Chart

    9.- LINE CORD REPLACEMENT ( 40 ) 9.1.-Follow steps 5-1,5-2 and 5-3. 9.2.- Disconnect ground (green ) as well as connection micro switch ( 27 ) and the connect to thermal protector ( 16 ) 9.3.-Remove the nut from the effort relief assembly ( 38 ) 9.4.- Replace line cord ,connect and reassemble as initially placed WHEN ORDERING ,DO NOT FORGET TO SPECIFY : PART NUMBER...
  • Page 6: Iv.- Electrical Rating

    IV. ELECTRICAL RATING / 120 V ~ 60 Hz 15 A V .-WIRING DIAGRAM 6/10 October / 2006...
  • Page 7: Vi.- Part List

    Connector of pressure 2 x 14 28-1078-6 Line Cord Assembly 17-3036-5 Motor Cover 1.5 H.P. Insert 12-0414-8 Grommet Heyco 0.062 05-3765-4 Cover Motor 17-3025-8 Koblenz Insert 12-0692-9 Molding Motor Cover 28-0671-9 Motor Cable / Contac Assembly 28-0957-2 Motor Cable Assembly C.D. 01-1626-9 Screw 01-1745-7 Screw Cab.
  • Page 8 PART. No. DESCRIPTION B-1550-P B-1500-DC 23-0605-8 Cover Motor C.D. 23-0615-7 Cover Motor Assembly 15-0678-1 Capacitor 40 MFD 08-0979-8 Insulator Capacitor 15-0013-1 Capacitor 590-708 MFD 05-3567-4 Capacitor Cover 01-1093-2 Screw Hexagonal 8 x 3/8 " 04-0366-7 Flat Washer 3/8 01-1774-7 Screw Hex 3/8-16 x 1 1/4 " 46-2422-7 Lever Tube Adjustment Assy 64-A...
  • Page 9 X.- ASSEMBLY 9/10 October / 2006...
  • Page 10 610 Lanark Suite 205 San Antonio TX ,78218 Tel (210) 590-1226 Fax (210) 590-1258 1-800-548-5741 FACTORY Koblenz Electrica ,S.A. de C.V. Av. . Ciencia No 28 Cuautitlán Izcalli Edo. de México ,C.P. 54730 Tel : 5864-0300 Web site : http://www.koblenz.electric.com KOBLENZ ELECTRICA S.A.

This manual is also suitable for:

B-1500 p
