V460 Series WinCE User's Manual
Fourth Edition, April 2009
www.moxa.com/product
© 2009 Moxa Inc. All rights reserved.
Reproduction without permission is prohibited.

Advertisement

loading
Need help?

Need help?

Do you have a question about the V460 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Moxa Technologies V460 Series

Summary of Contents for Moxa Technologies V460 Series

  • Page 1 V460 Series WinCE User’s Manual Fourth Edition, April 2009 www.moxa.com/product © 2009 Moxa Inc. All rights reserved. Reproduction without permission is prohibited.
  • Page 2 V460 Series WinCE User’s Manual The software described in this manual is furnished under a license agreement and may be used only in accordance with the terms of that agreement. Copyright Notice Copyright © 2009 Moxa Inc. All rights reserved.
  • Page 3 Table of Contents Chapter 1 Introduction ....................1-1 Overview..........................1-2 Package Checklist ........................1-2 Product Features ........................1-4 Software Features ........................1-4 Applications Development Environment ..............1-4 Networking and Communications Capabilities ............1-5 Supporting Servers and Daemons ................1-5 Graphics and Multimedia Tools ................. 1-6 Learning Firmware Build Versions ..................
  • Page 4 Appendix A Firmware Upgrade Procedure..............A-1...
  • Page 5 HMI, advertisement appliances, and interactive panels. Moxa pays attention to the requirements of Windows® developers to provide the Windows® CE solution for the Moxa V460 Series series ready-to-run embedded computer, including IA261-CE, and IA262-CE. The Moxa professional kernel development experience on embedded small footprint communication devices provides the intense technological skills required while porting the Windows®...
  • Page 6 VGA interface. The V460 series offers a variety of I/O options for use in a variety of applications and vertical markets. The on-board CompactFlash and DDR SDRAM provide ample storage capacity, and the Windows-based operating system comes pre-installed and ready-to-run, providing a Windows-like environment for easy software development.
  • Page 7 V460 Series WinCE User’s Manual Introduction V462-T-XPE x86 Ready-to-Run Embedded Computer with AMD LX 800, VGA, Dual LANs, 4 Serial Ports, CompactFlash, PCMCIA, USB, Audio, WinXP embedded, Wide Temperature. V464-XPE x86 Ready-to-Run Embedded Computer with AMD LX 800, VGA, Quad LANs, 4 Serial Ports,...
  • Page 8 C Libraries and Run-times - Compared to the C libraries and run-times used on a desktop PC running Windows®, the C libraries and run-times on a V460 Series is a subset of the WIN32 APIs. It supports full ANSI C run time, standard input/output library, standard input/output ASCII library and standard ASCII string functions.
  • Page 9 Supporting Servers and Daemons In addition to the development and communication capability, the services and daemons listed below are also embedded in the V460 series. These common and easy-to-use application services help users migrate industrial communication applications to the V460 series embedded computer easily and conveniently.
  • Page 10 Graphics and Multimedia Tools The V460 embeds high-performance multimedia technologies found on desktop computers. These technologies provide the V460 series with a friendly graphical user interface, and support waveform audio playback and capture. Graphics Device Interface (GDI) - Provides information about the fundamental graphics architecture for Windows CE.
  • Page 11 V460 Series WinCE User’s Manual Introduction Learning Firmware Build Versions There are two ways to determine the firmware version of the V460 embedded computer. This information is important for identifying which features are supported. Examine the welcome message after you logon the computer.
  • Page 12 V460 Series WinCE User’s Manual Introduction Inserting a CompactFlash Card The V460 has a type II CompactFlash slot that supports cards of both types I and II. A mass storage card is considered to be secondary storage for the computer. When a mass storage card is inserted, the V460 creates a directory named “HardDisk”...
  • Page 13 V460 Series WinCE User’s Manual Introduction PCMCIA (V462 Only) The PCMCIA slot supports the CardBus (Card-32) Card standard and 16-bit (PCMCIA 2.1/JEIDA 4.2) Card standard. It supports +3.3V, +5V, and +12V at a working voltage of 120 mA. Wireless LAN card expansion is optional.
  • Page 14 Getting Started Chapter 2 In this chapter, we explain how to operate a V460 computer from a PC. For clarity, the PC will be referred to as a “development workstation,” and the V460 embedded computer will be called a “target computer.” In addition, we give steps for facilitating operations such as system time adjustment, troubleshooting network connectivity, etc.
  • Page 15 V460 Series WinCE User’s Manual Getting Start Starting your V460 Computer Connect the CRT monitor or LCD monitor to the target computer, and then power it on by connecting it to the power adaptor. It takes about 15 to 20 seconds for the system to boot up.
  • Page 16 V460 Series WinCE User’s Manual Getting Start Step1: Scan Disk (Automatically) The system will scan the disk automatically when you start the reset procedure. Step2: Reset to Default? (Y/N) After the disk scan is complete, the system will ask you to confirm that you want to reset to defaults.
  • Page 17 V460 Series WinCE User’s Manual Getting Start 2. Right-Click the LAN interface that you would like to configure and then click [property]. A configuration window will pop up. 3. Input the new IP address and netmask and then click OK.
  • Page 18 V460 Series WinCE User’s Manual Getting Start Ethernet Adapter [PCI\RTL81392]: IP Address: 192.168.4.127 SubNet Mask: 255.255.255.0 Operating Your V460 Computer via Telnet Client Before operating your V460 computer from a Telnet client, we suggest that you change the network settings of the computer (see the previous section) so that at least one of the two network ports are on the same LAN as your development workstation.
  • Page 19 V460 Series WinCE User’s Manual Getting Start User/Group Management User Group: You should assign specific services, such as ftp and telnet, to define user groups such that these services are accessible only by the users within the permissible user group. Three user groups, namely “ftpd,”...
  • Page 20 V460 Series WinCE User’s Manual Getting Start Adjusting Time Zone Setting the System Time Manually: Use the date, and time commands to query the current system date/time or to set a new system date/time. The system time is save in RTC. Stopping the system won’t affect the system time.
  • Page 21 V460 Series WinCE User’s Manual Getting Start Adapter Index: 2 Address: 80 86 33 33 34 12 DHCP Enabled: NO Ethernet adapter Local Area Connection: IP Address: 192.168.14.202 Subnet Mask: 255.255.248.0 Default Gateway: 192.168.15.254 Adapter Name: PCI\RTCENIC1 Description: PCI\RTCENIC1 Adapter Index: 3...
  • Page 22 V460 Series WinCE User’s Manual Getting Start Simple Network Management Protocol (SNMP) SNMP is the Internet Standard protocol for network management and part of the TCP/IP protocol suite. SNMP was developed to monitor and manage networks. It uses a distributed architecture...
  • Page 23 Management Tools Chapter 3 The V460 of ready-to-run embedded computers are network-centric platforms designed to serve as front-end computers for data acquisition and industrial control. Due to the distributed characteristics of the devices that these computers control, they are often located near the devices in harsh environments, and are usually far away from system administrators.
  • Page 24 V460 Series WinCE User’s Manual Management Tools System Information The first page displays the system information of the V460 computer, including the firmware version of the computer, .Net CF version, the system time, and system resources including main memory and file system usage.
  • Page 25 V460 Series WinCE User’s Manual Management Tools Process (Thread) Monitoring/Control At runtime, the V460 computer manages up to 32k applications. You can use the management system to monitor and control them. To view current processes, please click the Processes item on the tab bar.
  • Page 26 V460 Series WinCE User’s Manual Management Tools You can also adjust the time automatically by using SNTP. Click on the check box to enable the service and click the button to activate. Some listed services cannot be stopped in order to maintain normal operation of the computer.
  • Page 27 V460 Series WinCE User’s Manual Management Tools Display The V460 VGA output works through a CRT connector to display the Windows CE desktop on an LCD monitor or CRT monitor. The default setting is 800x600, 16-bit, and 60 Hz. For general purposes, you should tune the setting to match your LCD or CRT specifications.
  • Page 28 V460 Series WinCE User’s Manual Management Tools...
  • Page 29 V460 Series WinCE User’s Manual Management Tools Auto Launch Configuration You can specify programs to execute automatically after booting up. Click the Add button to add the program and restart the V460 to execute these programs. Web Server Configuration You will need Windows 2000 or Windows XP for Web administration. Try to open an IE window and then navigate to http://192.168.3.127/WebAdmin (e.g,.
  • Page 30 V460 Series WinCE User’s Manual Management Tools On this administration page, you can create a new web site or create a virtual web path for your web application.
  • Page 31 System Recovery Chapter 4 The V460 series of ready-to-run embedded computers are Windows CE 6.0 OS platforms, and the internal file systems support FAT. Although it happens rarely, you may find on occasion that operating system files become damaged. In this chapter, we explain how to revert to the original OS configuration.
  • Page 32 V460 Series WinCE User’s Manual System Recovery Recovery Environment The environment includes the hardware and recovery programs for conducting preliminary tests. Hardware The hardware used for system recovery includes a V460 computer and a bootable USB disk that contains the recovery programs.
  • Page 33 V460 Series WinCE User’s Manual System Recovery 2. Bios setup on the V460. a. Insert the USB disk into the V460 computer. b. Power on and press DEL to enter the bios setup menu. c. Select [Advanced] [hard Disk Boot Priority] and then press Enter.
  • Page 34 V460 Series WinCE User’s Manual System Recovery 3. System recovery a. If the bios setup is correct, the computer will restart and boot from the USB disk. b. Under command prompt, type cd ceboot c. In the c:\ directory type mkdisk to initiate the recovery procedure.
  • Page 35 Firmware Upgrade Procedure Appendix A To upgrade the V460 firmware, you must download the firmware upgrade installation file. This firmware installation file is on the software CD. You may also download the latest file from the Moxa Download Center. The URL link of Moxa Download Center: http://web4.moxa.com/support/download_center.asp Use the following step-by-step procedure to update the firmware: 1.
  • Page 36 V460 Series WinCE User’s Manual Firmware Upgrade Procedure 6. Please allow at least one minute to complete the upgrade process. After the firmware has been upgraded successfully, press Y to keep the current network settings. Press N to reset to factory default values.
