Acme Furniture 36120T Assembly Instructions

Download this manual

*** Thank you for purchasing this quality product. Be sure to check all packing materials carefully

for small parts which may have come loose inside the carton during shipment. Identify and count

all parts and compare with parts list below.

*** Assemble product on a flat, soft surface such as a carpet or cloth to prevent scratching the

finish. Read all instruction and study the drawings carefully before starting the assembly process.

IMPORTANT: Do not tighten bolts completely until all

bolts are completely lined up and inserted into holes

ASSEMBLY INSTRUCTIONS

Item No: #36120T & 36125F

PAGE 1 OF 5

Need help?

Do you have a question about the 36120T and is the answer not in the manual?

Page 1 ASSEMBLY INSTRUCTIONS Item No: #36120T & 36125F *** Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts which may have come loose inside the carton during shipment. Identify and count all parts and compare with parts list below.
Page 2: Parts List
PARTS LIST HARDWARE LIST DIAGRAM PART NAME Q'Ty DIAGRAM PART NAME Q'Ty 1 pc Headboard Bolt 7.8 x 90 (mm) 8 pcs 1 pc Footboard Flat Washer: 7.8 x 29 x 8 (mm) 8 pcs Side Rails 2 pcs Hex Nut: 7.8 x 13 x 10 (mm) 8 pcs 1 Set Slat...
Page 3 #36120T & 36125F is packed in 3 cases Disignation Part Hardware Carton Item: Headboard #36120T-HB #36125F-HB x 1pc Footboard Item: x 1pc #36121T-FB #36126F-FB Slats x 13pcs A :Bolt x 8pcs Item: B :Flat Washer x 8pcs Side Rails #36122T-R...
Page 4 STEP 1: HEADBOARD - FOOTBOAD - SIDE RAIL ASSEMBLY 8 pcs 8 pcs 8 pcs 1 pc 4 PLACES PAGE 4 OF 5...
Page 5 STEP 2: SLAT ASSEMBLY 26 pcs 26 PLACES STEP 3: ASSEMBLY IS COMPLETED PAGE 5 OF 5...
