For important information on the safe use of your device and battery, read "For your safety" and "Product Safety" info in the printed user guide, or at www.nokia.com/support before you take the device into use. To find out how to get started with your new device, read the printed user guide.
Your phone software
Keep your phone up to date and accept available software updates to get new and enhanced features for your phone. Updating the software may also improve your phone's performance.
Your phone
This user guide applies to the following models: TA-1437, N151DL.
Some of the accessories mentioned in this user guide, such as charger, headset, or data cable, may be sold separately.
Parts and connectors, magnetism
Do not connect to products that create an output signal, as this may damage the device. Do not connect any voltage source to the audio connector. If you connect an external device or headset, other than those approved for use with this device, to the audio connector, pay special attention to the volume levels.
Parts of the device are magnetic. Metallic materials may be attracted to the device. Do not place credit cards or other magnetic stripe cards near the device for extended periods of time, since the cards may be damaged.
Insert the cards
Charge the battery
Switch on your phone
When you switch your phone on for the first time, your phone guides you to set up your network connections and phone settings.
Transfer data from your previous phone
You can transfer data from an old phone to your new phone using your Google account.
To back up data on your old phone to your Google account, refer to your old phone's user guide.
Restore app settings from your previous Android™ phone
If your previous phone was an Android and you had set it to back up data to your Google account, you can restore your app settings and passwords.
Switch off your phone
To switch off your phone, press the power key and the volume up key at the same time, and select Power off.
Tip: If you want to switch off your phone by pressing and holding the power key, tap Settings > System > Gestures > Press and hold power button and switch off Hold for Assistant.
Avoid scratching the touch screen. Never use an actual pen, pencil, or other sharp object on the touch screen.
Tap and hold to drag an item
Place your finger on the item for a couple of seconds and slide your finger across the screen.
Swipe
Place your finger on the screen and slide your finger in the direction you want.
Scroll through a long list or menu
Slide your finger quickly in a flicking motion up or down the screen and lift your finger. To stop the scrolling, tap the screen.
Zoom in or out
Place 2 fingers on an item, such as a map, photo, or web page, and slide your fingers apart or together.
Lock the screen orientation
The screen rotates automatically when you turn the phone 90°.
To lock the screen in portrait mode, swipe down from the top of the screen and tap Auto-rotate > Off.
Navigate with gestures
To switch on using gesture navigation, tap Settings > System > Gestures > System navigation > Gesture navigation.
Navigate with keys
To switch on the navigation keys, tap Settings > System > Gestures > System navigation > 3-button navigation.
Lock your phone
If you want to avoid accidentally making a call when your phone is in your pocket or bag, you can lock your keys and screen.
To lock your keys and screen, press the power key.
Unlock the keys and screen
Press the power key and swipe up across the screen. If asked, provide additional credentials.
You can set your phone to require authentication when unlocking the screen.
Set a screen lock
Set up face authentication
Unlock your phone with your face
To unlock your phone, just turn your screen on and look at the front camera.
If there is a facial recognition error and you cannot use alternative sign-in methods to recover or reset the phone in any way, your phone will require service. Additional charges may apply and all the personal data on your phone may be deleted. For more info, contact the nearest authorised service facility for your phone, or your phone dealer.
Locate or lock your phone
If you lose your phone, you may be able to find, lock or erase it remotely if you have signed in to a Google Account. Find My Device is on by default for phones associated with a Google Account.
To use Find My Device, your lost phone must be:
When Find My Device connects with your phone, you see the phone's location and the phone gets a notification.
Change your wallpaper
Tap Settings > Wallpaper.
Change your phone ringtone
Tap Settings > Sound > Phone ringtone, and select the tone.
Change your message notification sound
Tap Settings > Sound > Default notification sound.
Use the notification panel
When you receive new notifications, such as messages or missed calls, icons appear at the top of the screen.
To see more information about the notifications, swipe down from the top of the screen. To close the view, swipe up on the screen.
To change the notification settings of an app, tap Settings > Notifications > App settings > Most recent > All apps and switch the app's notifications on or off.
Use the quick access items
To activate features, tap the corresponding quick access item on the notification panel. To see more items, drag the menu down. To rearrange or add new items, tap , tap and hold an item, then drag it to another location.
Change the volume
If you have trouble hearing your phone ringing in noisy environments or calls are too loud, you can change the volume to your liking by using the volume keys on the side of your phone.
Do not connect to products that create an output signal, as this may damage the device. Do not connect any voltage source to the audio connector. If you connect an external device or headset, other than those approved for use with this device, to the audio connector, pay special attention to the volume levels.
Change the volume for media and apps
Set the phone to silent
Use keyboard word suggestions
Your phone suggests words as you write, to help you write quickly and more accurately. Word suggestions may not be available in all languages.
When you start writing a word, your phone suggests possible words. When the word you want is shown in the suggestion bar, select the word. To see more suggestions, tap and hold the suggestion.
Tip: If the suggested word is marked in bold, your phone will automatically use it to replace the word you wrote. If the word is wrong, tap and hold it to see a few other suggestions. If you do not want the keyboard to suggest words while typing, switch off the text corrections. Tap Settings > System > Languages & input > On-screen keyboard. Select the keyboard you normally use. Tap Text correction and switch off the text correction methods you do not want to use.
Correct a word
If you notice that you have misspelled a word, tap it to see suggestions for correcting the word.
Switch spell checker off
Tap Settings > System > Languages and input > Spell checker, then switch
Use spell checker off.
Extend battery life
To save power:
Make the text on the screen larger
Make the items on the screen larger
Make a call
Answer a call
If your phone rings when the screen is unlocked, tap ANSWER. If your phone rings when the screen is locked, swipe up to answer.
Reject a call
If your phone rings when the screen is unlocked, tap REJECT. If your phone rings when the screen is locked, swipe down to reject the call.
Add a contact
Save a contact from call history
Send a message
You can send mail with your phone when you're on the go.
Add an email account
When you use the Gmail app for the first time, you are asked to set up your email account.
Send email
Take a photo
Shoot sharp, vibrant photos – capture the best moments in your photo album.
Take a selfie
Record a video
View photos and videos on your phone
Tap Photos.
Share your photos and videos
Copy your photos and videos to your computer
Connect your phone to your computer with a compatible USB cable. Use your computer's file manager to copy or move your photos and videos to the computer.
Switch on Wi-Fi
Your Wi-Fi connection is active when is shown at the top of the screen. If both Wi-Fi and mobile data connections are available, your phone uses the Wi-Fi connection.
Use encryption to increase the security of your Wi-Fi connection. Using encryption reduces the risk of others accessing your data.
Search the web
Tip: If your network service provider doesn't charge you a fixed fee for data transfer, to save on data costs, use a Wi-Fi network to connect to the internet.
Use your phone to connect your computer to the web
Use your mobile data connection to access the internet with your laptop or other device.
The other device uses data from your data plan, which may result in data traffic costs. For info on availability and costs, contact your network service provider.
Connect to a Bluetooth device
Since devices with Bluetooth wireless technology communicate using radio waves, they do not need to be in direct line-of-sight. Bluetooth devices must, however, be within 10 metres (33 feet) of each other, although the connection may be subject to interference from obstructions such as walls or from other electronic devices.
Paired devices can connect to your phone when Bluetooth is switched on. Other devices can detect your phone only if the Bluetooth settings view is open.
Do not pair with or accept connection requests from unknown devices. This helps to protect your phone from harmful content.
Share your content using Bluetooth
If you want to share your photos or other content with a friend, send them to your friend's phone using Bluetooth.
You can use more than one Bluetooth connection at a time. For example, while using a Bluetooth headset, you can still send things to another phone.
The passcode is only used when you connect to something for the first time.
Remove a pairing
If you no longer have the device that you paired your phone with, you can remove the pairing.
You may need a Virtual Private Network (VPN) connection to access your company resources, such as intranet or corporate mail, or you may use a VPN service for personal purposes.
Contact your company IT administrator for details of your VPN configuration or check your VPN service's website for additional information.
Use a secure VPN connection
Edit a VPN profile
Delete a VPN profile
Set date and time
Tap Settings > System > Date & time.
Update the time and date automatically
You can set your phone to update the time, date, and time zone automatically. Automatic update is a network service and may not be available depending on your region or service provider.
Change the clock to the 24-hour format
Tap Settings > System > Date & time, and switch Use 24-hour format on.
Set an alarm
Switch an alarm off
When the alarm sounds, swipe the alarm right.
Select the calendar type
Tap Calendar > and select what type of calendar you want to see.
If you have signed into an account, such as your Google account, your calendar is shown on the phone.
Add an event
Tip: To edit an event, tap the event and and edit the details.
Delete an appointment
1. Tap the event.
2. Tap > Delete.
Find a spot
Google Maps helps you find specific locations and businesses.
See your current location
Tap Maps > .
Get directions to a place
Add a payment method
To use Google Play services, you need to have a Google account added to your phone. Charges may apply to some of the content available in Google Play. To add a payment method, tap Play Store, tap your Google logo in the search field, then tap Payments and subscriptions. Always make sure that you have permission from the payment method owner when buying content from Google Play.
Download apps
Install available updates
Tap Settings > System > System update > Check for update to check if updates are available.
When your phone notifies you that an update is available, just follow the instructions shown on the screen. If your phone is low on memory, you may need to move your photos and other things to the memory card.
Before starting the update, connect a charger or make sure that the device battery has enough power, then connect to Wi-Fi, as the update packages may use up a lot of mobile data.
To ensure your data is safe, use the backup feature in your phone. Your device data (such as Wi-Fi passwords and call history) and app data (such as settings and files stored by apps) will be backed up remotely.
Switch on automatic backup
Tap Settings > System > Backup, and switch backup on.
Reset your phone
Read these simple guidelines. Not following them may be dangerous or against local laws and regulations. For further information, read the complete user guide.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when mobile device use is not allowed or when it may cause interference or danger, for example, in aircraft, in hospitals or near medical equipment, fuel, chemicals or blasting areas. Obey all instructions in restricted areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect performance.
AUTHORISED SERVICE
Only authorised personnel may install or repair this product.
BATTERIES, CHARGERS, AND OTHER ACCESSORIES
Use only batteries, chargers, and other accessories approved by HMD Global Oy for use with this device. Do not connect incompatible products.
KEEP YOUR DEVICE DRY
If your device is water-resistant, see its IP rating in the device's technical specifications for more detailed guidance.
GLASS PARTS
The device and/or its screen is made of glass. This glass can break if the device is dropped on a hard surface or receives a substantial impact. If the glass breaks, do not touch the glass parts of the device or attempt to remove the broken glass from the device. Stop using the device until the glass is replaced by authorised service personnel.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use.
Using some features and services, or downloading content, including free items, requires a network connection. This may cause the transfer of large amounts of data, which may result in data costs. You may also need to subscribe to some features.
4G/LTE might not be supported by your network service provider or by the service provider you are using when travelling. In these cases, you may not be able to make or receive calls, send or receive messages, or use mobile data connections. To make sure your device works seamlessly when full 4G/LTE service is not available, it is recommended that you change the highest connection speed from 4G to 3G. To do this, on the home screen, tap > Network & Internet > Mobile network and switch Preferred network type to 3G.
Note: Using Wi-Fi may be restricted in some countries. For example, in the EU, you are only allowed to use 5150‑5350 MHz Wi-Fi indoors, and in the USA and Canada, you are only allowed to use 5.15‑5.25 GHz Wi-Fi indoors. For more information, contact your local authorities. For more information, contact your network service provider.
Connections cannot be guaranteed in all conditions. Never rely solely on any wireless phone for essential communications like medical emergencies.
Before making the call:
To place an emergency call on any screen, press the power key quickly 3 times.
On the home screen, tap
You may also need to do the following:
Handle your device, battery, charger, and accessories with care. The following suggestions help you keep your device operational.
During extended operation, the device may feel warm. In most cases, this is normal. To avoid getting too warm, the device may automatically slow down, dim display during a video call, close apps, switch off charging, and if necessary, switch itself off. If the device is not working properly, take it to the nearest authorised service facility.
Battery and charger information
To check if your phone has a removable or non-removable battery, see the Get started guide.
Devices with a removable battery
Only use your device with its original rechargeable battery.
The battery can be charged and discharged hundreds of times, but it will eventually wear out. When the talk and standby times are noticeably shorter than normal, replace the battery.
Devices with a non-removable battery
Do not attempt to remove the battery, as you may damage the device. The battery can be charged and discharged hundreds of times, but it will eventually wear out. When the talk and standby times are noticeably shorter than normal, take the device to the nearest authorised service facility to have the battery replaced.
Charge your device with a compatible charger. Charger plug type may vary. Charging time can vary depending on device capability.
Battery and charger safety information
Once your device is fully charged, unplug the charger from the device and electrical outlet. Please note that continuous charging should not exceed 12 hours. If left unused, a fully charged battery will lose its charge over time.
Extreme temperatures reduce the capacity and lifetime of the battery. Always keep the battery between 15°C and 25°C (59°F and 77°F) for optimal performance. A device with a hot or cold battery may not work temporarily. Note that the battery may drain quickly in cold temperatures and lose enough power to switch off the phone within minutes. When you are outdoors in cold temperatures, keep your phone warm.
Obey local regulations. Recycle when possible. Do not dispose as household waste.
Do not expose the battery to extremely low air pressure or extremely high temperature, such as disposing of it in a fire, as that may cause the battery to explode or leak flammable liquid or gas.
Do not dismantle, cut, crush, bend, puncture, or otherwise damage the battery in any way. If a battery leaks, do not let liquid touch skin or eyes. If this happens, immediately flush the affected areas with water or seek medical help. Do not modify, attempt to insert foreign objects into the battery, or immerse or expose it to water or other liquids. Batteries may explode if damaged.
Use the battery and charger for their intended purposes only. Improper use of, or use of unapproved or incompatible, batteries or chargers may present a risk of fire, explosion, or other hazards, and may invalidate any approval or warranty. If you believe the battery or charger is damaged, take it to a service centre or your local phone shop before continuing to use it. Never use a damaged battery or charger. Only use the charger indoors. Do not charge your device during a lightning storm. When charger is not included in the sales pack, charge your device using the data cable (included) and a USB power adaptor (may be sold separately). You can charge your device with third-party cables and power adaptors that are compliant with USB 2.0 or later and with applicable country regulations and international and regional safety standards. Other adaptors may not meet applicable safety standards, and charging with such adaptors could pose a risk of property loss or personal injury.
To unplug a charger or an accessory, hold and pull the plug, not the cord.
Additionally, the following applies if your device has a removable battery:
Your device and its accessories are not toys. They may contain small parts. Keep them out of the reach of small children.
Operation of radio transmitting equipment, including wireless phones, may interfere with the function of inadequately shielded medical devices. Consult a physician or the medical device's manufacturer to determine if it is adequately shielded from external radio energy.
To avoid potential interference, manufacturers of implanted medical devices (such as cardiac pacemakers, insulin pumps and neurostimulators) recommend a minimum separation of 15.3 centimetres (6 inches) between a wireless device and the medical device. Persons who have such devices should:
If you have any questions about using your wireless device with an implanted medical device, consult your health care provider.
When you use the headset, your ability to hear outside sounds may be affected. Do not use the headset where it can endanger your safety.
Some wireless devices may interfere with some hearing aids.
Your device may be exposed to viruses and other harmful content. Take the following precautions:
Radio signals may affect improperly installed or inadequately shielded electronic systems in vehicles. For more information, check with the manufacturer of your vehicle or its equipment. Only authorised personnel should install the device in a vehicle. Faulty installation may be dangerous and invalidate your warranty. Check regularly that all wireless device equipment in your vehicle is mounted and operating properly. Do not store or carry flammable or explosive materials in the same compartment as the device, its parts, or accessories. Do not place your device or accessories in the air bag deployment area.
