- Page 1 PH700-PW Benchtop pH Meter for Pure Water and Low Ionic Strength Solutions User Manual 9001 : 2015 © 2024 APERA INSTRUMENTS, LLC v4.0 aperainst.com - 1 -...
- Page 2 Table of Contents 1. Brief Introduction ....................3 2. Installation ......................4 3. Instrument Description ..................6 3.1 LCD Display .......................6 3.2 Keypad ......................7 3.3 Connection .......................8 3.4 Stable Reading Display Mode ................8 3.5 Data Logging ......................8 3.6 Data Recalling ......................8 3.7 Delete Storage ......................
- Page 3 1. Brief Introduction This meter is a combination of advanced electronics design and sensor technology. Please read this manual carefully to properly use and maintain the product. Main Features Intelligent functions such as automatic calibration, self-diagnosis, automatic tem- perature compensation, data logging, max/min reading display, etc. Simple electrode holder for easy operation and workbench space saving Swiss LabSen pH electrode designed for pure water &...
- Page 4 2. Installation 2.1 Install the electrode holder The electrode holder is composed of a metal stand base, a supporting bar, and an electrode clip. First, screw on the metal stand base to the meter on either side (Pic-1). Then install the supporting bar on the metal stand base (Pic-2). Lastly, install the elec- trode clip on the supporting bar (Pic-3).
- Page 5 2.4 pH Electrode ® The meter comes with Apera LabSen 803 pH/temp. electrode designed for accurate measurement in pure water e.g. distilled/deionized/RO/drinking/well water and low ionic strength water solutions as well as general water solutions. 2.5 Technical Specifications of LabSen 803 pH/temp. Electrode Measurement Range 1 - 11 pH, 0 - 80˚C (32 –...
- Page 6 2.6.4 Perform at least a 2-point calibration before first-time use. For calibration de- tails, refer to Section 4. 3. Instrument Description 3.1 LCD Display 1) Measurement value 2) Calibration icons and numberings 3) Measurement unit 4) Temperature and reminder icons 5) The pH unit displayed during calibration 6) The pH value displayed during calibration, numberings for storage and recall, and reminder icons...
- Page 7 3.2 Keypad 3.2.1 Keypad Operation Short Press: 0.5 seconds Long Press: 2 seconds 3.2.2 For keypad functions, refer to the following table. Keypad Operation Functions Short Press Power on/off Short Press Select measuring mode: pH → mV Long Press Enter parameter setting：P1 → P2 →…P4 •...
- Page 8 3.3 Connection Symbol Connector Name Connector Type Socket for reference electrode Φ2 banana type pH/mV Socket for pH and ORP electrode TEMP Socket for temperature sensor DC9V DC9V power socket Φ2.5 direct type 3.4 Stable Reading Display Mode When the measuring value is stable, appears on LCD, see Pic-7.
- Page 9 3.7 Delete Storage The meter can store up to 50 sets of data. Once the stor- age is full, if you press again, the FUL icon will be dis- played on LCD (see Pic-10). The storage needs to be deleted in parameter setting P4 to save new data.
- Page 10 Calibration USA Series NIST Series Icon When to use Error Tolerance > ±0.1 1-point 7.00 pH 6.86 pH 1st pt: 7.00 pH 1st pt: 6.86 pH Option A 2nd pt: 4.00 Option A 2nd pt: 4.01 pH Range < 7.00 pH pH or 1.68 pH or 1.68 pH 2-point...
- Page 11 4.4.2 Screw off the electrode storage vial and use pure water to rinse off electrode; Blot dry the electrode with Kimwipe/filter paper/clean tissue to remove excess wa- Pic-11 ter (NEVER rub the glass membrane). Then dip electrode into pH 7.00 buffer at least 1 inch deep (see Pic-11), stir it for a few seconds and let it stand.
- Page 12 5. pH Measurement 5.1 How to Take pH Measurement 5.1.1 Power on the meter to enter measurement mode. 5.1.2 Rinse the electrode with pure water for a few seconds. Blot dry the electrode with Kimwipe/filter paper/clean tissue. 5.1.3 Submerge the electrode into your sample solution at least 1 inch deep (see Pic-12).
- Page 13 5.5 Manual Temperature Compensation The default pH electrode has a built-in temperature sensor so the temperature compensa- tion will be automatic (ATC on screen). When you use a pH electrode without a tempera- ture sensor, you would want to use the manual temperature compensation function to lower the pH measurement error.
- Page 14 6.1 How to do the parameter setting In measurement mode, long press to enter parameter setting P1. Then press to change menu from P1 to P2…P5. For details, please see the following table. P1 — Select pH buffer series (USA— NIS) 1.
- Page 15 7. Electrode Cleaning The meter is only as accurate as the electrode is clean. Always thoroughly rinse off the electrode before and after each measurement with distilled water or deionized water in a container or with a wash bottle. To remove excessive water, just shake them off or blot dry with Kimwipe/filter paper/ clean tissue.
- Page 16 8. Electrode Maintenance 8.1 Add 3M KCL soaking solution to the electrode storage vial and store the electrode in it. Twist on the vial locking ring tightly. If the 3M KCL soaking solution is contaminated, re- place it with fresh solution. As a rule of thumb, replace the soaking solution on a monthly basis.
- Page 17 10. Ideal pH Electrodes for Various Applications Applications Ideal Apera pH Electrodes to Use General water solutions 201T-F, LabSen 211/213 Dirty liquids such as wastewater,emulsions, LabSen 331/333, LabSen 231 suspensions, slurries, etc. Biotechnology and pharmaceuticals LabSen 821/823, LabSen 241-3SP High-Temperature solutions LabSen 861/863 Low-temperature liquid LabSen 881...
- Page 18 11. Troubleshooting Guide Trouble Potential Causes How to Fix Incorrect calibration Always calibrate pH 7 first, then pH 4 or order (Er1) pH 10. Refer to Section 4.4. Calibration solutions Make sure your calibration standard are in poor condition solutions are fresh and clean, and made (Er1) by a legitimate manufacturer.
- Page 19 Trouble Potential Causes How to Fix Make sure the storage vial is taken off Electrode is not in full and the electrode is fully immersed in contact with solutions the solution (above the junction). Air bubbles around Make a quick stir in the solution to re- Jumping Read- the sensor move air bubbles.
- Page 20 12. Limited Warranty We warrant this instrument to be free from defects in material and workmanship and agree to repair or replace free of charge, at option of APERA INSTRUMENTS, LLC, any malfunctioned or damaged product attributable to responsibility of APERA INSTRU- MENTS, LLC for a period of TWO YEARS (SIX MONTHS for the electrode) from the deliv- ery.
