- Page 1 Mamibot iGLASSBOT W120-P Robot Window Cleaner Dual Self-Water-Spraying Type USER MANUAL V.20231229.
- Page 2 Mamibot Thanks for purchasing Mamibot Robot Window cleaner W120-P featured with dual self-water-spraying type. We hope W120-P will bring you a smarter and more convenient lifestyle. If you encounter any problem not mentioned herein, please contact info@mamibot.com. For more details, please visit our official website: http://www.mamibot.com.
-
Page 3: Table Of Contents
Mamibot Table of Contents Safety Instructions and Warning Specification What’s in the package Product Description Main Unit Remote Self-Water-Spraying System Cleaning Modes “Z” Cleaning Mode “N” Cleaning Mode “Z|N” Cleaning Mode 9-10 Installation Charging Cleaning Pad Attaching Fill Up the Water Tank... -
Page 4: Safety Instructions And Warning
Do not unplug the plug by pulling the power cord. ▲ Do not attempt to service the adapter and battery. Replace the whole unit if it is damaged or exposed to high moisture. Contact Mamibot dealer for help and maintenance. - Page 5 Mamibot ▲ Manufacturer can not take any responsibilities for any damges or injuries caused by improper use. Warning ▲ Check if the safety rope and extension cable are broken or not before use. ▲ Fasten the safety rope and tie it to indoor fixtures before using W120-P.
- Page 6 Spraying Drive Type Motor Drive ※ The datas come from the lab of Mamibot Manufacturing USA Inc. It may be slightly different from the users’ data, please subject to the actual products. For continous products improvment, we reserve the right to any technical and design...
-
Page 7: What's In The Package
Mamibot What’s in the package W120-P Robot Window Cleaner W120-P x 1pc Cleaning Pads x 2pcs Remote x 1pc with Safety Rope AC Plug x 1pc Extension Cable x 1pc Adapter x 1pc (with power cord) USER MANUAL Measuring Cup x 1pc... -
Page 8: Product Description
Mamibot Product Description Main Unit Water Tank Lid Switch LED Indicator Short Press: Blinking Red: Alarm - to start/resume Blue: Normal/ Fully Charged Long Press: Solid Red: Charging - to switch W120-P on / off Hand Grip W120-P Robot Window Cleaner... -
Page 9: Self-Water-Spraying System
Mamibot Auto/Manual Water Spraying Switch Manual Spraying Button Manual Move Up Manual Move Left Manual Move Right Manual Move Down Start Cleaning Button Auto “Z” Cleaning Type Auto “N” Cleaning Type Auto “Z” and “N” Cleaning Type Stop Cleaning Pause/Resume... -
Page 10: Cleaning Modes
Mamibot Cleaning Modes ※ Please make sure the edge of W120-P is 8cm or more away from window frames or corners before cleaning (as in fig. Page 11). “Z” Cleaning Mode: Start W120-P in the center of the W120-P Robot Window Cleaner glass. -
Page 11: Installation
Mamibot Installation Charging Plug in the adapter to W120-P as below, connect the adapter, AC plug and extension cable properly as in below image: Charging Indicator: Solid Red: Charging Blue: Fully charged after 1-2 hrs charging. Extension Cable Mamibot AC Plug... -
Page 12: Safety Rope Fixing
Mamibot Safety rope fixing The safety rope must be tied on the indoor fixtures tightly before use. Make sure the length of the safety rope is appropriate for cleaning. W120-P Robot Window Cleaner Note: 1). Please check the safety rope, make sure the rope is not damaged and the knot is not loose. -
Page 13: To Use W120-P
Mamibot To use W120-P * Please charge the W120-P fully before use. Switch on/off Plug W120-P in power supply, hold and press the switch on W120-P for about 2 seconds to turn W120-P on, then put W120-P on the window glass. -
Page 14: Maintenance
Mamibot Fig. 1 Fig. 2 Fig. 3 Fig. 4 Android System: Requires Android 4.3 or later. 1. Open the App “iGLASSBOT” as Fig. 1. 2. Turn the switch on of W120-P and put it onto glass. 3. Use the App to search W120-P, it will get the hotspot of W120-P. -
Page 15: Disclaimer
• The W120-P has a 1 year limited warranty against original defects in workmanship or material. • The warranty only applies to the authorized distributors of Mamibot. • Improper usage or not in accordance with the user manual will void the warranty. -
Page 16: Troubleshooting
Mamibot Troubleshooting Malfunction Solutions Possible Causes W120-P gets 1. Glass is too dirty or too wet. 1. Change cleaning pad. slippery or works 2. Cleaning pad is too dirty 2. Cleaning the driving wheels. in irregular pattern. or too wet. -
Page 17: Recycling Of W120-P
Mamibot It’s normal if it is cleaning frameless glass. The red indicators Edge sensor detects Not recommend for use on frameless blink twice when use. frameless glass. glass. 1.Spray a little water on the cleaning Glass is too dry or edge Squeaky sound pads before use. - Page 18 Manufacturer: Mamibot Manufacturing (Shanghai) Co.,Ltd. North 21th, No.1 Building, LN1040 Caoyang Rd, Shanghai, P.R.C Supervised by Mamibot Manufacturing USA Inc. One Commerce Center, 1201 Orange St, Wilmington, DE 19899 USA Tel: 001 302-428-9888 sales@mamibot.com www.mamibot.com...
