- Page 1 · The Perfect Partner of Your Life · PREV PAUSE NEXT F.FWD FM 88 92 96 100 104 108 AM 53 75 100 130 150 171 SW 5.9 7.6 10.2 13.0 16.0 18.0 VOL- VOL+ MUSIC...
-
Page 2: Table Of Contents
Ⅰ PRECAUTIONS Ⅱ PRODUCT INTRODUCTION 1. Functional Components 2. Product Specifications Ⅲ POWER SUPPLY 1. USB Charging 2.Solar Charging 3.D Cell(UM-1 1.5V Battery) Ⅳ RADIO RECEPTION 10-11 How to Get Better Reception Ⅴ MUSIC PLAYBACK 12-14 1.Play via Bluetooth TWS Function 2.Played by USB Drive/TF Card Ⅵ... - Page 3 PRUNUS J-150 BTS Solar Radio/BT Speaker/MP3 Player User Manual PREFACE Thank you for purchasing PRUNUS J-150 BTS Solar Radio/BT Speaker/MP3 Player. In order to get the best from the radio, please read this manual carefully before using it and take...
-
Page 4: Precautions
Ⅰ PRECAUTIONS 1. Please fully charge the radio to activate it before the first use or after a long period of non-use. 2. Please remove the batteries if you do not plan to use the radio for a long time. 3. -
Page 5: Product Introduction
Ⅱ PRODUCT INTRODUCTION 1. Functional Components ④ ⑤ ⑥ ①Volume/Power Knob ②Mode Button: MUSIC/FM/AM/SW PREV PAUSE NEXT F.FWD ③Tuning Knob FM 88 92 96 100 104 108 AM 53 75 100 130 150 171 SW 5.9 7.6 10.2 13.0 16.0 18.0 ④Previous/Rewind ⑤Play/Pause/TWS VOL-... -
Page 6: Product Specifications
2. Product Specifications 1) Model: J-150 BTS 2) Band: FM: 88-108 MHz; AM: 530-1710KHz; SW: 5.9-18.0MHz 3) MP3 Playing: Bluetooth / TF Card / USB Drive 4) Battery: 3.7V/ 1200mAh LI-ION 5) Speaker Power: 3W 6) Charging Standard: DC5V/0.5-2A 7) Solar Panel: 5V/0.7W; 105 x 60 x 2.5mm... -
Page 7: Power Supply
Ⅲ POWER SUPPLY 1. USB Charging Use the supplied USB charging cable to charge the built-in battery. The <⑩Charging Indicator> will light up when it's charging, and goes off when fully charged. Takes 4-6 hours to full charge. ⑩Charging Indicator USB-C cable Tips: 1. -
Page 8: Solar Charging
2.Solar Charging 1) Unfold the solar panel on the back of the radio, 2) Put the radio in sunlight. The <⑩Charging Indicator> will light up when it's charging, and goes off when fully charged. ⑮Solar Panel Tips: Takes about 12-15 hours to fully charge in full sunlight. The charging efficiency depends on the intensity of sunlight. - Page 9 3.D Cell(UM-1 1.5V Battery) *2 (not included) 1) Open the battery compartment. 2) Follow the electrode marks inside to install the batteries. 3) Cover the battery compartment. LI-ION ⑯Battery Compartment Note: a. Don't use a new battery and old battery together. b.
-
Page 10: Radio Reception
Ⅳ RADIO RECEPTION 1. Turn <①Volume/Power Knob> to turn on radio. 2. Move <②Mode Button> to choose “FM”, “AM”, or “SW”. 3. Turn <③Tuning Knob> to choose the station. 4. Turn <①Volume/Power Knob> to adjust the volume. PREV PAUSE NEXT F.FWD FM 88 92 96 100 104 108 AM 53 75 100 130 150 171... -
Page 11: How To Get Better Reception
◆ How to Get Better Reception? 1. Adjust the telescopic antenna while listening to FM/SW, but reposition the radio while listening to AM. 2. When you're indoors, approach it to the window and try to keep it away from the electronic devices, such as computers, TVs, refrigerators and mobile phones. -
Page 12: Music Playback
Bluetooth mode and ready to pair. 2) Turn on the Bluetooth on your device, such as mobile phone, to search and connect the device named “J-150 BTS”. A "con nected" sound indicates that the device is successfully connected. -
Page 13: Tws Function
TWS Function: Note: This function is available only if you have two radios of the same model. Two speakers connected wirelessly, provide the stereo effect of a 2.0 speaker system. 1) Follow the steps of “1. Play via Bluetooth”. PREV PAUSE NEXT F.FWD... -
Page 14: Played By Usb Drive/Tf Card
2.Played by USB Drive/TF Card 1) Move <②Mode Button> to “Music”. 2) Insert the USB drive/TF card loaded with MP3 files into <⑧TF Card Slot> or <⑦USB Drive Port>. Once the MP3 files are detected, the radio will play automatically. ⑦USB Drive Port ⑧TF Card Slot Song... -
Page 15: Faq
Ⅵ Q1: Why is the sound fuzzy? A1: It’s possible that your surrounding signal maybe weak, please refer to“◆ How to Get Better Reception?” in IV RADIO RECEPTION. Q2: Why can't the TF card/USB drive be read? A2: Please make sure they’re in FAT or FAT32 Format, as the radio can’t read TF card/USB drive in NTFS Format. -
Page 16: After-Sale Service
If the radio fails, please scan this QR code. Then click “Ask a question” and log into Amazon to contact us. We will provide you with the best service. You can also send your messages to our customer service e-mail: prunus-technik@hotmail.com America Local Customer Support Number: (805) 712-2661...
