Summary of Contents for Midland X-TALKER 51VP3
- Page 1 MIDLAND X-TALKER Two-Way Radios Owner’s Manual...
- Page 2 ● Privacy Codes: Take your communication to a new level of privacy and customization with the Midland X-TALKER Walkie-Talkies. You can enjoy confidential and uninterrupted conversations with 38 CTCSS Privacy Codes. The Continuous Tone-Coded Squelch System gives you up to 836 channel options to block other conversations. Choose the code that suits your needs, ensuring your conversations remain private and interference-free.
- Page 3 ● NOAA Weather Scan + Alert: NOAA Weather Scan will automatically scan through 10 available weather (WX) band channels and locks onto the strongest weather channel to alert you of severe weather updates. NOAA Weather Alert will sound an alarm indicating that there is a risk of severe weather in your area.
- Page 4 Features ● 36 FRS Channels ● Roger Beep Tone ● 121 Privacy Codes (38 CTCSS / 83 DCS) ● Silent Operation ● ● Key Pad Lock ● 5 Selectable Call Alerts (5 additional Animal Sounds on T65) ● Vibrate Alert (T65 only) ●...
- Page 5 To maintain compliance with FCC’s RF exposure guidelines, for body-worn operation, this radio has been tested and meets the FCC RF exposure guidelines when used with Midland Radio Corp. accessories supplied or designated for this product. The use of other accessories may not ensure...
- Page 6 DESCRIPTION ● NOAA WEATHER (WX) BAND ICON – Indicates when the radio is in Weather Band mode. ● KEY LOCK ICON – Indicates KEY LOCK mode is on. ● VOX ICON – Indicates when VOX mode is active. ● CHANNEL NUMBER – Changes from 1~36 on FRS band (1~10 on WX band). ●...
- Page 7 ● VIBRATE ALERT ICON – Indicates when the Vibrate-Alert feature is on (Model T65 only). ● BATTERY METER – Indicates the battery level. ● RECEIVE (RX) ICON – Indicates radio is receiving a transmission. ● TRANSMIT (TX) ICON – Indicates radio is transmitting a signal.
- Page 8 ● POWER/VOLUME KNOB – Turn clockwise to turn the power on and increase the volume level. Turn counter-clockwise to decrease the volume level and turn the power off. ● PTT Button – Press and hold to transmit voice communication. ● 14.
- Page 9 ● MENU Button – Press momentarily to access Menu mode. ● MONITOR/SCAN Button – Press to enter SCAN mode. Press and hold to enter MONITOR mode. ● UP/WX SCAN holding the s button and DOWN DOWNButtons – Make adjustments in MENU mode. Press and hold the UP button for 5 seconds to activate the NOAA Weather Scan function.
-
Page 10: Battery Installation
BATTERY INSTALLATION Your radio operates with either a NiMH battery pack or optional 3 AAA alkaline batteries. The belt clip should be removed (see below) to ease the installation or removal of the batteries. To install the batteries: With the back of the radio facing you, remove the belt clip (see diagram below) for easy access, then remove the Battery Cover by pressing down on the top center and sliding it down from the radio. - Page 11 INSTALLING THE BELT CLIP To install the BELT CLIP, slide the clip down into the slot on the back of the radio until the BELT CLIP LATCH clicks. To remove the BELT CLIP, pull the LOCK TAB away from the radio, then gently pull the belt clip up toward the top of the radio.
-
Page 12: Charging The Battery Pack
Meter will flash from 1 to 3 bars. The LCD display will show FULL when charging is complete. For maximum battery life, Midland recommends charging the battery pack when the low battery icon comes on. Remove the radios from the charger when the... -
Page 13: Specifications
SPECIFICATIONS ● Channels: 36 FRS Channels +121 Privacy Codes 10 NOAA Weather (WX) Band Channels ● Operating Frequency: UHF 462.5500 ~ 467.7125 MHz ● Power Source: 3 AAA Alkaline or 3.6V Rechargeable NiMH battery pack... - Page 14 51VP3 X-TALKER Walkie Talkie Clear reception, clear transmission, and clear sound quality The X-Talker T51VP3 two-way radio offers you the ability to communicate license-free with up to a 28-mile range and features 22 Channels, 38 Privacy Codes, Channel Scan, and our legendary Weather Alert technology.
- Page 15 22 FRS Channels Clear, crisp communications with easy button access 38 Privacy Codes Gives you up to 836 channel options to help you block other conversations Hands-Free Operation Easy Voice and Sound Activated Transmission (eVOX) for hands-free operation...
- Page 16 Cross Compatible Compatible with all Midland FRS Walkie Talkies and accessories NOAA Weather Alert Sounds an alarm indicating that there is a risk of severe weather in your area Longer Range Longer range communication in open areas with little or no obstruction...
- Page 17 Manuals.plus ● Q: How do I turn on the radio? A: Rotate the POWER/VOLUME knob clockwise to turn on the radio. The LCD display will show all icons for 1 second, indicating that the radio is powered on. ● Q: How do I turn off the radio? A: Rotate the POWER/VOLUME knob counterclockwise to reduce the volume level and turn off the radio.
- Page 18 Manuals.plus ● Q: How do I transmit a call? A: Set your radio to the desired channel and/or Privacy Code. Press and hold the PTT button and speak into the microphone in a normal voice. The TX icon will appear continuously on the LCD display while transmitting.
- Page 19 Manuals.plus Like And Subscribe us for more Videos Manuals.plus...
