- Page 1 AutomAtic control system for AirVents S37 (KVENT Medium) S38 (KVENT Medium, TH-TUNE) S39 (KVENT Medium, PGDE) S49 (KVENT, Touch Screen pGDX 4,3) USER'S MANUAL...
-
Page 2: Table Of Contents
Control ......................................... 41 This user’s manual is a main operating document intended for technical, maintenance, and operating staff. The manual contains information about purpose, technical details, operating principle, design, and installation of the S37, S38, S39, S49 unit and all its modifications. -
Page 3: Purpose
THE PRODUCT MUST BE DISPOSED SEPARATELY AT THE END OF ITS SERVICE LIFE. DO NOT DISPOSE THE UNIT AS UNSORTED DOMESTIC WASTE. PURPOSE The automatic control system is designed to control a range of different ventilation system configurations. -
Page 4: S37 (Kvent Medium) Control Unit
S37 (KVENT MEDIUM) CONTROL UNIT Control unit for single-phase units connectible with RNS-5.1... - Page 5 Designation Control panel Function Value Supply fan's power supply protection 1.6A Exhaust fan's power supply protection 1.6A Circulation pump and temperature controller’s power supply protection 2.5A Controller, sensors' and actuators' 24 VAC power supply protection 3.15A...
- Page 6 Control unit for single-phase units connectible with RNS-12 Q1 Q2...
- Page 7 Designation Control panel Function Value Supply fan's power supply protection 1.6A Exhaust fan's power supply protection 1.6A Circulation pump and temperature controller’s power supply protection 2.5A S37-1/3P-.170/.170 Controller, sensors' and actuators' 24 VAC power supply protection 3.15A...
- Page 8 Control unit for three-phase units connectible with RNS-12...
-
Page 9: Control Unit
Designation Control unit Function Value Power supply protection of the supply and exhaust fans S37-3P-1.32/1.32 Controller, sensors' and actuators' 24 VAC power supply protection 3.15A Power supply protection of the 230 VAC digital outputs and actuators Power supply protection of the supply and exhaust fans S37-3P-3.60/3.60... - Page 10 Table of single-phase units connectible with RNS-5.1 Type of ventilation unit Motor type Electr. parameters Control unit BL-B190B-EC03 230 VAC, 170 W, 1.3 A CF 500 BL-B190B-EC03 230 VAC, 170 W, 1.3 A BL-B190B-EC03 230 VAC, 170 W, 1.3 A...
- Page 11 Table of single-phase units connectible with RNS-12 Type of ventilation unit Motor type Electr. parameters Control unit BL-B190B-EC03 230 VAC, 170 W, 1.3 A CF 500 BL-B190B-EC03 230 VAC, 170 W, 1.3 A BL-B190B-EC03 230 VAC, 170 W, 1.3 A...
- Page 12 Replacement table of fuses and their analogs for single-phase fan power supply Rated current [A] Manufacturing factory LITTELFUSE EATON/BUSSMANN ESKA Equipment code 0218002.MXP BK1-S506-2-R 522.520 Breaking current Circuit breaker size 5x20mm Circ. breaker characteristic Slow Rated current [A] 3.15...
- Page 13 Replacement table of fuses and their analogs for three-phase fan power supply Rated current [A] Manufacturing factory DF ELECTRIC Equipment code 2610005 420506 Breaking current 50 kA 20 kA Circuit breaker size 8x31 mm Circ. breaker characteristic...
-
Page 14: S37 (Kvent Medium) Control Unit With Reverse Positioning Of Terminals
S37 (KVENT MEDIUM) CONTROL UNIT WITH REVERSE POSITIONING OF TERMINALS Control unit for suspended single-phase units connectible with RNS-5.1... - Page 15 Designation Control panel Function Value Supply fan's power supply protection 3.15A Exhaust fan's power supply protection 3.15A Circulation pump and temperature controller’s power supply protection 2.5A S37-1P-.532/.532-R Controller, sensors' and actuators' 24 VAC power supply protection 3.15A...
- Page 16 Control unit for suspended single-phase units connectible with RNS-12...
- Page 17 Designation Control panel Function Value Supply fan's power supply protection 3.15A Exhaust fan's power supply protection 3.15A Circulation pump and temperature controller’s power supply protection 2.5A S37-1/3P-.532/.532-R Controller, sensors' and actuators' 24 VAC power supply protection 3.15A...
- Page 18 Control unit for suspended three-phase units connectible with RNS-12...
- Page 19 Designation Control unit Function Value Power supply protection of the supply and exhaust fans S37-3P-1.32/1.32-R Controller, sensors' and actuators' 24 VAC power supply protection 3.15A Power supply protection of the 230 VAC digital outputs and actuators Table of single-phase units connectible with RNS-5.1...
- Page 20 Replacement table of fuses and their analogs for single-phase fan power supply Rated current [A] 3.15 Manufacturing factory LITTELFUSE EATON/BUSSMANN ESKA Equipment code 02183.15MXP BK1-S506-3-15-R 522.522 Breaking current Circuit breaker size 5x20mm Circ. breaker characteristic...
- Page 21 Replacement table of fuses and their analogs for 24 VAC controller, sensors and actuators power supply Rated current [A] 3.15 Manufacturing factory LITTELFUSE EATON/BUSSMANN ESKA Equipment code 02183.15MXP BK1-S506-3-15-R 522.522 Breaking current Circuit breaker size 5x20mm Circ.
-
Page 22: S37 (Kvent Medium) Control Unit In A Modular Panel
S37 (KVENT MEDIUM) CONTROL UNIT IN A MODULAR PANEL Control unit in a modular panel for single-phase units connectible with RNS-5.1 Q1 Q2 Q3 Q4... - Page 23 Designation Control unit Function Value Power supply protection of the supply fan Power supply protection of the extract fan Controller, sensors' and actuators' 24 VAC power supply protection 3.15A Power supply protection of the heating temperature control panel S37-1P-.170/.170-SN...
- Page 24 Control unit in a modular panel for single-phase units connectible in the with RNS-12 Q1 Q2 Q3 Q4...
- Page 25 Designation Control panel Function Value Power supply protection of the supply fan Power supply protection of the extract fan Controller, sensors' and actuators' 24 VAC power supply protection 3.15A Power supply protection of the heating temperature control panel S37-1/3P-.170/.170-SN...
- Page 26 Control unit in a modular panel for single-phase units connectible in the with RNS-30 Q3 Q4 Q5 Q6...
- Page 27 Table of circuit breakers for 400 V AC Designation Control panel Function Value Controller, sensors' and actuators' 24 VAC power supply 3.15A protection Power supply protection of the electric heating section Supply fan's power supply protection Exhaust fan's power supply protection S37-3P-1.32/1.32-SN...
-
Page 28: Motor Type
Table of single-phase units in a modular panel connectible with RNS-5.1 Type of ventilation unit Motor type Electr. parameters Control unit BL-B190B-EC03 230 VAC, 170 W, 1.3 A CF 500 BL-B190B-EC03 230 VAC, 170 W, 1.3 A BL-B190B-EC03 230 VAC, 170 W, 1.3 A... - Page 29 Table of single-phase units in a modular panel connectible with RNS-12 Type of ventilation unit Motor type Electr. parameters Control unit BL-B190B-EC03 230 VAC, 170 W, 1.3 A CF 500 BL-B190B-EC03 230 VAC, 170 W, 1.3 A BL-B190B-EC03 230 VAC, 170 W, 1.3 A...
- Page 30 Replacement table of fuses and their analogs for single-phase fan power supply protection Rated current [A] Manufacturing factory LITTELFUSE EATON/BUSSMANN ESKA Equipment code 0218002.MXP BK1-S506-2-R 522.520 Breaking current Circuit breaker size 5x20mm Circ. breaker characteristic...
- Page 31 Display FieldBus2 FieldBus1 port/BMS /BMS Display port Ethernet Field bus +Vdc NO10 NO11 NO12 EEV2 EEV1 ID10 Item Description Item Description Digital inputs Micro USB to update applications, import and export settings and error log...
-
Page 32: Wiring
WIRING DISCONNECT THE POWER SUPPLY PRIOR TO ANY OPERATIONS WITH THE UNIT. THE UNIT MUST BE CONNECTED TO POWER MAINS BY A QUALIFIED ELECTRICIAN. ANY TAMPERING WITH THE INTERNAL CONNECTIONS IS PROHIBITED AND WILL VOID THE WARRANTY. - Page 33 External wiring diagram for single-phase units connectible with RNS-5.1 for the standard and suspended panel modifications ~230V Reserve AI 4..20mA N L L1 N L L1 -t° -t° -t° POWER **M1 **M2 SM1(2) FCP1 DPT1 ~230V 6х0.5...
- Page 34 External wiring diagram for three-phase units connectible with RNS-12 for the standard and suspended panel modification for R1 units ~400V Reserve AI 4..20mA N L L1 N L L1 -t° -t° -t° POWER **M1 **M2...
- Page 35 External wiring diagram for single-phase units in a modular panel connectible with RNS-12 ~400V Reserve AI 4..20mA N L L1 N L L1 -t° -t° -t° POWER **M1 **M2 SM1(2) FCP1 DPT1 N PE N PE...
-
Page 36: General Equipment
External wiring diagram designation key General equipment Designation Name Control terminal Inline CO2 sensor DPT1 Supply air flow sensor FCP1 Fire alarm (customer’s equipment) Supply air fan Extract air fan POWER Power supply from the customer's feeder... -
Page 37: Technical Data
TECHNICAL DATA Technical parameters pGDE Parameter pGDx Touch 4.3” th-Tune Storage temperature [°C] -30...+70 -20...+70 -20...+70 Storage humidity [%] 10…85 @ 40 (no condensation) 10…90 (no condensation) 10…90 (no condensation) Operation temperature [°C] 0...+50 -10...+60 -20...+60... -
Page 38: Installation And Set-Up
INSTALLATION AND SET-UP INSTALLATION OF THE PGDX CONTROL PANEL To mount the control panel in a wall partition, prepare the cutout and openings as shown in the picture below. Ø 4 Mounting template 127x69 mm Use screws to secure the control panel in the partition and install the frame. - Page 39 Installation of the th-Tune control panel Use a mounting box of at least 65 mm in diameter and at least 31 mm deep to install the back side of the panel. 1. Use a screwdriver to separate the front and back sides of the 2.
- Page 40 Installation of the pGDE control panel Connect the pGDE control panel to the controller using the 6P6C phone connector (PLUG-6P6C-P-C2). The maximum telephone cable length is 50 m. Route the telephone cable to the installation site to install the control panel on the wall.
-
Page 41: Control
CONTROL pGDx CONTROL PANEL The starting screen of the ventilation system control system The transition to the information menu about the ventilation system and temperature graphs. Transition to operation schedule setting menu Transition to the ventilation system's operation... - Page 42 Transition to temperature/humidity setpoint settings Transition to enabling the Boost function Transition to current alarms’ menu Transition to information and emulator menu of the PGDe controller. By default the password is 0000. Displays the current status of the ventilation system.
-
Page 43: Display Symbols
Th-Tune control Panel BUTTON FUNCTIONS Standby/auto mode. Disables the Boost functions. (MODE) Unit change: ECO, PRECOMFORT, COMFORT, STOP. (FAN) To turn the schedule mode on/off: hit the button. To access the schedule menu, press and hold the button for 2 seconds. Use (CLOCK) the rotating handle to select options. - Page 44 The description of unit operation modes STOP – the fans are off, the protective functions are operating (the field 3 shows no indication). – the fan speed is low, reduced power consumption and temperature. PRECOMFORT —...
-
Page 45: Running The Unit
The panel has 6 buttons: (ALARM) — to manually reset alarm signals. (PRG) — to change the operating mode. (ESC) — to return to the previous menu screen. (UP, DOWN) — to switch between the display screens or increase / decrease values. - Page 46 5. Current temperature in the supply air duct. 6. The preset indoor or supply duct temperature setpoint (based on the settings). 7. Indicates access to user menu by means of UP, DOWN and ENTER buttons for confirmation.
- Page 47 ALARMS In case of an alarm, the alarm signal screen is displayed. Item Description Alarm No. / Alarms total Date and time of alarm Alarm code Alarm description Alarm-triggered sensor value. Alarms can be reset manually, automatically, or automatically on a regular basis.
- Page 48 Alarms Alarm Alarm description Reset Action code A000 Supply temperature probe not working Auto reset Stop unit A001 Cooling device alarm User reset Stop cooling A002 Antifreeze alarm by DIN Auto reset until counter (3 in 3600s) Stop unit, force heating at 100%...
- Page 49 A036 Supply humidity probe not working Auto reset Stop humidifier A037 Unit configuration not allowed Auto reset Stop unit A038 Supply fan - Offline Auto reset Stop unit A039 Supply fan - Line Fault Auto reset...
- Page 50 A083 Extract fan - UZK low User reset Stop unit A084 Extract fan - UZK high User reset Stop unit A085 Extract fan - IGBT fault User reset Stop unit A086 Extract fan - Earth-GND fault...
-
Page 51: Password Control
A429 Heat exchanger clogged Auto reset Stopping heat recovery A430 Door switch Auto reset Stop unit A431 HEPA 1 filter's sensor fault Auto reset None A432 HEPA 2 filter's sensor fault Auto reset None A433... - Page 52 Standard configuration names For configurations equipped with a plate heat exchanger For configurations equipped with a rotary heat exchanger Configuration Filename Configuration Filename RX-0-0 EXPORT_30 CFX-0-0 EXPORT_20 RX-0-CW EXPORT_31 CFX-0-CW EXPORT_21 RX-0-RDX EXPORT_32 CFX-0-RDX EXPORT_22...
- Page 53 The automated system can also operate autonomously with no remote controller. The control unit has an in-built WEB interface, and supports Modbus and Bacnet protocols through RS485 and Ethernet interfaces. The information on protocol settings is specified in the controller’s user manual.
- Page 54 www.blaubergventilatoren.de...
- Page 55 www.blaubergventilatoren.de...
- Page 56 www.blaubergventilatoren.de B280EN-03...
