Summary of Contents for BLAUBERG SE1 Vento Eco
- Page 1 Control panel Se1 Vento eco USER'S MANUAL...
-
Page 2: Table Of Contents
Warranty card ....................................11 This user’s manual is a main operating document intended for technical, maintenance, and operating staff. The manual contains information about purpose, technical details, operating principle, design, and installation of the SE1 Vento Eco unit and all its modifications. - Page 3 www.blaubergventilatoren.de While mounting the unit, avoid compression of the casing! Misuse of the unit and any unauthorised modifications are not allowed. Do not expose the unit to adverse atmospheric agents (rain, sun, etc.). Do not use the unit in a hazardous or explosive environment containing spirits, gasoline, insecticides, etc.
-
Page 4: Purpose
SE1 Vento Eco www.blaubergventilatoren.de PURPOSE Vento Eco The wall-mounted sensor control panel is designed to be used as a part of the domestic air handling unit control system. The control panel is a component part and is not designed for independent operation. The unit is rated for continuous operation. -
Page 5: Installation And Connection
DO NOT LAY THE CABLE IN CLOSE PROXIMITY TO THE CONTROL PANEL CABLE! WHILE ROUTING THE CONTROL PANEL CABLE DO NOT COIL THE EXTRA LENGTH. The SE1 Vento Eco control panel is positioned based on the general project draft of the Vento Eco ventilator control system for a specific facility. - Page 6 SE1 Vento Eco www.blaubergventilatoren.de Connect the cable to the terminal on the back side of the casing following the label on the panel casing. Use the holes to attach the casing to the mounting box by means of screws. The screws that connect the control panel to the mounting box are included in the delivery set.
-
Page 7: Control
www.blaubergventilatoren.de CONTROL Setting up the control panel via a DIP switch Switches 1, 2 are used to select the control zone 1 2 3 4 5 1 2 3 4 5 1 2 3 4 5 1 2 3 4 5 Control zone 1 Control zone 2 Control zone 3... - Page 8 SE1 Vento Eco www.blaubergventilatoren.de The description of functions of the control panel 1 Turning on / off the group of controllers 2 Subsequent speed switching 3 Filter timer reset button 4 Mode switching: “Regeneration” and “Ventilation” 5 Enabling / disabling the timers 6 Enabling / disabling the integrated humidity sensor The ventilation system is swtched on by tapping the button.
-
Page 9: Troubleshooting
www.blaubergventilatoren.de The button enables / disables the integrated humidity sensor. When the integrated humidity sensor is activated with the button, the ventilation system starts operating so that when the sensor is triggered, all the ventilators switch to maximum speed in the Ventilation mode. After the air humidity in the room where the control panel is installed drops below the sensor trigger level, the system automatically returns to the settings that were in place before the sensor was triggered. -
Page 10: Manufacturer's Warranty
SE1 Vento Eco www.blaubergventilatoren.de MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/EU of the European Parliament and of the Council, Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and of the Council and CE-marking Council Directive 93/68/EEC. -
Page 11: Certificate Of Acceptance
www.blaubergventilatoren.de CERTIFICATE OF ACCEPTANCE Unit Type Control panel Model Serial Number Manufacture Date Quality Inspector’s Stamp SELLER INFORMATION Seller Address Phone Number E-mail Purchase Date This is to certify acceptance of the complete unit delivery with the user’s manual. The warranty terms are acknowledged and accepted. - Page 12 www.blaubergventilatoren.de B127-4EN-01...
