- Page 1 PRODUCT GAPID SENSOR Product code GAPID SENSOR GAPID SENSOR ANTI-CLIMB TRIAXIAL ACCELEROMETER SENSOR INSTALLATION AND MOUNTING MANUAL VERSION 2.5...
-
Page 2: Table Of Contents
12. Calibration……………………………………………………………….………………………………………….………………………...21 12.1 Calibration with self-learning functions 12.2 Self-learning function for alarm 12.3 Self-learning function for disqualification 12.4 Self-learning function for spontaneous vibration 13. Technical specifications ……………………….…………………………………………………………….…………………...…23 14. Product disposal ………….………………………………………………………………………………….………………………….24 GAPID SENSOR POLITEC ERNES SRL | INSTALLATION MANUAL - VER.2.1... -
Page 3: Introduction
The system has been designed to detect intrusions and activate the alarm; it is not a device that prevents intrusion.Politec is not responsible for damage, injury or loss caused by accidents, theft, force majeure (including momentary lightning-induced overcurrent), abuse, improper or incorrect use, faulty installation or inadequate maintenance. -
Page 4: General Warnings
• Manufacturer's liability:Politec assumes no liability for failures resulting from incorrect installation; lack of maintenance, incorrect assembly or use. • Politec is also not liable for incorrect or incomplete operation of the product or failure to detect intrusion. •... -
Page 5: List Of Main Components
The box contains the following components and accessories. When opening the package, check that everything has been included. COMPONENTS 3x7 screw Gapid SR cover Circuit board 3x20 screws Base Gapid SR Fixing plate Protection o-ring GAPID SENSOR POLITEC ERNES SRL | INSTALLATION MANUAL - VER.2.1... -
Page 6: Preparation For Installation
• Check that the surface chosen for the installation of the product is sturdy so as to ensure stable fixing and that it is adequately protected against possible impacts or the elements. GAPID SENSOR POLITEC ERNES SRL | INSTALLATION MANUAL - VER.2.1... -
Page 7: Sensor Mounting
O-ring is well positioned inside the appropriate compartment and that the protective cover closes well. WARNING: Product warranty is invalid if there is any hole in the product or any component GAPID SENSOR POLITEC ERNES SRL | INSTALLATION MANUAL - VER.2.1... -
Page 8: Fixing Plate (Click)
2. Apply the GAPID to the bracket with a "click" the sensor is ready. WARNING: Product warranty is invalid if there is any hole in the product or any component GAPID SENSOR POLITEC ERNES SRL | INSTALLATION MANUAL - VER.2.1... -
Page 9: Circuit Board
4 BUZZER 5 ANTI-OPENING TAMPER 6 FUNCTION SELECTOR 7 SENSITIVITY ADJUSTMENT TRIMMER 13,8V/3,6V 8 JUMPER N.B.: connecting 12Volt when 3.6V is selected may compromise the sensor WHITE DOUBLE BALANCING EXAMPLE YELLOW GAPID SENSOR POLITEC ERNES SRL | INSTALLATION MANUAL - VER.2.1... -
Page 10: Component Description
Lightweight mesh panels Rigid\Thick mesh panels Non-welded chain link fencing Rigid welded mesh fencing Anti-intrusion walls/railings Windows/indoor 6.2 SELF-LEARNING Self-learning for alarm Self-learning for disqualification Self-learning for spontaneous vibration 6.3 RESET Reset GAPID SENSOR POLITEC ERNES SRL | INSTALLATION MANUAL - VER.2.1... -
Page 11: Description Of The Functions
Standard applications: Typical action range: 5m diameter. The Gapid sensor has been designed to read all types of VIBRATION and movement on the AXES. It can be applied to any type of structure that generates vibrations. - Page 12 N.B.: sensitivity may vary depending on the type of grill and the anchoring to the ground. Fences: application in the center on 1 Canopies every 2 panels Vending machines Shutters Assembly internal Internal side mounting GAPID SENSOR POLITEC ERNES SRL | INSTALLATION MANUAL - VER.2.1...
- Page 13 Intermediate mounting (less sensitivity and protected Platform mounting exposure due to the risk of (greater sensitivity for shocks during work) walking detection on platforms) Mounting on tube (greater detection for climbing detection) GAPID SENSOR POLITEC ERNES SRL | INSTALLATION MANUAL - VER.2.1...
- Page 14 Typical application 1 for balcony Mounting in the center of the internal side Railings: Downpipes: Typical application on 1 per railing Typical application on the upper part of the downspout Internal side mounting GAPID SENSOR POLITEC ERNES SRL | INSTALLATION MANUAL - VER.2.1...
- Page 15 Photovoltaic panel: Typical application on 1 panel / or in the cable area to protect cables Street lights, poles with cameras, pylons Typical application up to 3m height GAPID SENSOR POLITEC ERNES SRL | INSTALLATION MANUAL - VER.2.1...
- Page 16 One per panel. N.B.: sensitivity may vary depending on the type of grill and the anchoring to the ground. GAPID SENSOR POLITEC ERNES SRL | INSTALLATION MANUAL - VER.2.1...
- Page 17 N.B.: sensitivity may vary depending on the type and thickness of the wall Manholes: Typical application for lifting or breaking detection Internal side mounting Safes – Slot Machines – Parking payment stations – Automatic ticket machines GAPID SENSOR POLITEC ERNES SRL | INSTALLATION MANUAL - VER.2.1...
- Page 18 If the sensor is mounted inside the plasterboard itself we recommend using the wire version. Stained glass windows: Typical application for lifting or breaking detection Skylights: Typical application 1 every 5m Anti-opening – breakthrough GAPID SENSOR POLITEC ERNES SRL | INSTALLATION MANUAL - VER.2.1...
- Page 19 Sheet metal ceiling: Place a sensor every 5m. Ceiling ventilation ducts: Internal application, typical 1 every 5m Fire escape stairs: Application one floor GAPID SENSOR POLITEC ERNES SRL | INSTALLATION MANUAL - VER.2.1...
- Page 20 10. Reset All signals recorded during the self-learning functions are reset. The ignition of the signaling LED confirms that the operation has been performed. GAPID SENSOR POLITEC ERNES SRL | INSTALLATION MANUAL - VER.2.1...
-
Page 21: Calibration
Standby 1sec Standby 1sec Standby 1sec The number of pulses to have an alarm depends on the program selected and the sensitivity set GAPID SENSOR POLITEC ERNES SRL | INSTALLATION MANUAL - VER.2.1... -
Page 22: Calibration With Self-Learning Functions
If after a few attempts you do not obtain two successful detections, it means that the fence has different oscillation frequencies and it is not possible to use this function. Reselect the standard function. Set the DIP to 1. GAPID SENSOR POLITEC ERNES SRL | INSTALLATION MANUAL - VER.2.1... -
Page 23: Technical Specifications
DIMENSIONS (WxHxD) 98 x 66 x 25,5 mm MATERIAL Scratch-resistant, UV-resistant black polycarbonate INGRESS PROTECTION RATING OPERATING -40°C +80°C TEMPERATURE MOUNTING KIT INCLUDED WITH SCREWS AND METAL PLATE 2-YEAR WARRANTY GAPID SENSOR POLITEC ERNES SRL | INSTALLATION MANUAL - VER.2.1... -
Page 24: Product Disposal
Warning!- Local regulations can impose heavy penalties for incorrect disposal of these products. Politec Ernes srl 20882 BELLUSCO MB Via Adda 64 Tel +39 039/6883019 Made in Italy GAPID SENSOR POLITEC ERNES SRL | INSTALLATION MANUAL - VER.2.1...
