Mytee TREX Instructions Manual

Total rotary extractor
Hide thumbs Also See for TREX:

Advertisement

Quick Links

Download this manual
Instructions for
TREX
TOTAL ROTARY EXTRACTOR
™
Please read before use.
Register your product at
http://www.mytee.com/
support/register
Set up p.2
Parts & pricing p.8
Wiring diagram p.10
General & Maintenance information p.11
TREX™ Accessories p.15
13655 Stowe Dr., Poway, Ca. 92064
1
Model #
Serial #
Form # ADP-TREX
5-14

Advertisement

loading
Need help?

Need help?

Do you have a question about the TREX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mytee TREX

Summary of Contents for Mytee TREX

  • Page 1 Please read before use. Register your product at http://www.mytee.com/ support/register Model # Set up p.2 Parts & pricing p.8 Serial # Wiring diagram p.10 Form # ADP-TREX General & Maintenance information p.11 TREX™ Accessories p.15 5-14 13655 Stowe Dr., Poway, Ca. 92064...
  • Page 2 9. Clear View Cuff-Lynx™ 13. Cleaning Head 5. Motor Elbow 14. Heavy Duty Wheels TREX™ ITEMS INCLUDED A916 - Head Protector G014 - Felt Ring Seal H053 - Head Removal Tool H136 - 2” Male Coupler Swivel H051 - 5/8” Flat Wrench...
  • Page 3 Connect solution hose from your extractor to swivel QD fitting on The handle can be adjusted to any desired working position by TREX™ handle. Also, connect vacuum hose from extractor to simply squeezing the adjustment lever. Move the handle to the vacuum relief inlet on TREX™...
  • Page 4 TREX™ TREX™ SAFETY SWITCH TREX™ ACTIVATION LEVER Squeeze to activate. The handle must be lowered to the operating position before While holding the safety switch lock in disengaged position, switching the machine ON. Disengage the safety switch lock by squeeze the activation lever to operate machine. To stop the pushing it forward with either thumb.
  • Page 5 To attach the head, place the center piece of the head on the To remove, place wrench on rotary union and attach the head threaded piece located underneath, at the center of the TREX™. removal tool and twist clockwise. Once on, twist counter-clockwise.
  • Page 6 Your TREX™ maneuvers much like a floor machine. Slightly lift handle to move to the right. Press the handle down slightly to move to the left. Tilting your TREX™ may result in carpet damage. Remember to always keep TREX™ evenly balanced on the surface.
  • Page 7 TREX™ CORRECT CLEANING PATTERNS To get the best carpet cleaning results, move your TREX™ in an arc pattern or circular motion. To remove stubborn stains, try hovering the TREX™ over the stain.
  • Page 8 TREX™ PARTS & PRICING Order parts at: http://www.mytee.com/products/t-rex/#.UKLKIeOe_-I Part prices are subject to change.
  • Page 9 TREX™ PARTS & PRICING...
  • Page 10 TREX™ WIRING DIAGRAM Color diagram at: http://www.mytee.com/products/t-rex/#.UKLKIeOe_-I...
  • Page 11 You can use the space provided on the front of this manual to note the quality and standard you’d expect out of the Mytee Products Inc. line. down both for future referencing.
  • Page 12 5. Remove protective wrapping from wheels. and soak them in a recommended liquid 6. Attach the cleaning head at the base of the TREX™. First, lean the neutralizer for up to six hours. To remove TREX™ back and rest it on the handle. Second, thread the head onto the spray tip, twist spray tip body counter- exposed shaft in a counterclockwise direction.
  • Page 13 Mytee or a Mytee authorized distributor or service center. Mytee may Q: Is there anything I can do to increase the expected life of my TREX™? make changes in products it manufactures and markets at any time; these A: Regular cleaning and maintenance of the entire unit.
  • Page 14 Distributor will fill out a RMA/Warranty claim form. This form will act as a repair order to replace any defective parts. 2. All defective parts must be returned to Mytee Products, Inc. with the RMA/claim form for evaluation at the customer’s expense. This shipping is non-refundable. All warranty claims are subject to an evaluation by Mytee Products, Inc.
  • Page 15 TREX™ ACCESSORIES A102 - Cleaning Head A103 - TREX™ Brush A916 - Head Protector B183 - TREX™ Jet G014 - Felt Ring Seal G077 - TREX™ Cone Filter ####- Attachable Lead Hose with Cuff-Lynx™ P577 - Docking Station...
  • Page 16 NOTES Mytee Products Inc. 13655 Stowe Dr. Poway, Ca. 92064 www.mytee.com F X 858.679.7814 © 2014 Mytee Products Inc. Printed in the U.S.A.
