  • Page 2: Fundamental Safety Rules

    E N G L I S H ASPIRLIGHT HV 1. GENERAL 1.1 INTRODUCTION This manual was prepared with the aim of making the installation and management of your system as simple as possible. By reading and applying the suggestions of this manual, you can achieve the best performance of the purchased product.
  • Page 3 E N G L I S H ASPIRLIGHT HV • It is forbidden to insert objects and substances through the air intake and supply grids. • It is forbidden to open the access doors to the inside of the device, without firstly placing the system’s main switch on ‘off’.
  • Page 4 E N G L I S H ASPIRLIGHT HV 1.4 WARNINGS The unit must be installed by qualified and authorised personnel according to the rules in force in the various countries. If installation is not carried out, this could lead to a situation of danger Avoid installing the unit in very damp rooms or where there are large sources of heat.

  • Page 5: Construction Features

    E N G L I S H ASPIRLIGHT HV 1.5 CONFORMITY The CE marking (applied on each machine) certifies compliance with the following Community standards: • Low Voltage Directive 2014/35/EC • Electromagnetic Compatibility Directive 2014/30/EC • Ecodesign 2009/125/EC 1.6 RANGE...

  • Page 6: Free Cooling

    E N G L I S H ASPIRLIGHT HV FANS Brushless fans with electronic motor and constant flow rate control; Very high efficiency and low noise levels. FILTERS ePM1 70/80% filters with low head loss. Easily removable in either horizontal or vertical positioning.

  • Page 7: Requirements For Start-Up

    E N G L I S H ASPIRLIGHT HV 1.10 STATE OF SUPPLY The supply includes: • recovery unit complete with fans installed inside the unit • polypropylene counter current exchanger pre-inserted inside the unit; • 2 ePm1 80% class filters pre-inserted inside the unit;...

  • Page 8: Installation Conditions

    E N G L I S H ASPIRLIGHT HV 2. INSTALLATION 2.1 INSTALLATION CONDITIONS The unit must be installed based on national and local regulations governing the use of electrical devices and based on the following indications: • install the unit inside residential buildings with room temperature between 0°C and 45°C;...

  • Page 9: Unit Positioning

    E N G L I S H ASPIRLIGHT HV 2.2 UNIT POSITIONING CEILING INSTALLATION To mount the unit on the ceiling, it is necessary to: Position the 2 mounting brackets on the perimeter sides of the unit where the air inlets are;...

  • Page 10: Wall Mounting

    E N G L I S H ASPIRLIGHT HV WALL-MOUNTING To mount the unit on the wall, it is necessary to: Position one of the two supplied brackets on the back of the unit, positioning it as shown here in the figure;...

  • Page 11: Condensate Discharge Connection

    E N G L I S H ASPIRLIGHT HV 2.3 CONDENSATE DISCHARGE CONNECTION Because of the heat recovery system (the exhaust air is cooled by the air supplied into the heat exchanger), the humidity contained in the internal air condenses inside the unit.

  • Page 12: Aeraulic Connections

    E N G L I S H ASPIRLIGHT HV AERAULIC CONNECTIONS 3.1 AERAULIC ORIENTATIONS The unit has 4 circular male connections of different Ø based on the size: for optimal function. To correctly connect the air ducts, refer to the following diagram and stickers on the unit.
  • Page 13 E N G L I S H ASPIRLIGHT HV HORIZONTAL INSTALLATION H OUTDOOR EXHAUST OUTDOOR EXHAUST EXTRACTION FROM EXTRACTION FROM SUPPLY SUPPLY ROOM ROOM DEFAULT CUSTOMISABLE VERSION The units are shown as seen from above VERTICAL INSTALLATION OUTDOOR EXHAUST OUTDOOR...

  • Page 14: Electrical Connections

    E N G L I S H ASPIRLIGHT HV ELECTRICAL CONNECTIONS 4.1 GENERAL - Before starting any operation to perform the electrical connection make sure that the unit is not electrically powered - Perform the necessary electrical connections referring exclusively to the wiring diagram attached to this manual.

  • Page 15: Unit Wiring Diagrams

    E N G L I S H ASPIRLIGHT HV 4.2 UNIT WIRING DIAGRAMS Room air probe Exhaust Probe Outdoor Air Probe POWER SUPPLY 230/1/50 POST VALVE / COIL CONNECTIONS SET UP BY THE CUSTOMER CHILLER Chiller / Generator activation Dry Contact (hot/cold request...
  • Page 16 E N G L I S H ASPIRLIGHT HV 4.3 ELECTRICAL CONNECTIONS CH193VMC REMOTE PANEL CONNECTION The board uses a capacitive touch remote control to manage all of the functions of the unit and is set up for wall or outdoor 503 box installation;...
  • Page 17 E N G L I S H ASPIRLIGHT HV EXTERNAL COIL INSTALLATION 5.1.1 ELECTRIC COILS The unit can feature an electric coil that can be installed as described below. The coil has an internal thermostat that can also be connected to an external thermostat. For details of the electrical connections, follow the instructions provided in the coil manual The CH193VMC remote panel directly controls the electric coil through the Chiller contact, on the board;...

  • Page 18: Maintenance

    E N G L I S H ASPIRLIGHT HV MAINTENANCE To always guarantee correct and optimal unit operation, it is necessary to periodically perform all of the maintenance activities. 6.1 FILTER CLEANING AND REPLACEMENT To replace the filters, or periodically clean them, do the following: cut off the power to the unit;...

  • Page 19: Heat Exchanger Cleaning

    E N G L I S H ASPIRLIGHT HV 6.2 HEAT EXCHANGER CLEANING It is advisable to check the status of the heat exchanger every time the filters are cleaned/changed, and clean it if necessary. This must only be done by qualified personnel (installer).
  • Page 20 E N G L I S H ASPIRLIGHT HV 6.3 GENERAL UNIT CLEANING It is advisable to occasionally check and possibly clean the fans of the condensation discharge and the inside walls of the unit. These activities must only be carried out by qualified personnel (installer).
  • Page 21 E N G L I S H ASPIRLIGHT HV ALARMS In case of any problems or failures, take note of any error code appearing on the remote control screen, take note of the model and the serial number of the unit you possess (data provided on the identification plate attached on the side of the unit) and contact the installer.
  • Page 22 E N G L I S H ASPIRLIGHT HV 7.2 TABLE OF ALARMS REPORTED ON THE CH193VMC DISPLAY Below is the table of unit operating anomalies reported on the remote display. CODE DESCRIPTION CAUSE SOLUTION VMC: AIR Return Probe Alarm...
  • Page 23 ........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
  • Page 24 FANTINI COSMI S.p.A. Via Dell’Osio, 6 - 20090 Caleppio di Settala, Milan, Italy Tel. +39 02 956821 | Fax +39 02 95307006 E-mail: info@aspira.it | supportotecnico@aspira.it www.aspira.it...
