AccurAtAMente e conservArlo bene per consultArlo in Futuro. descrizione del prodotto Gli aspiratori elicoidali della serie AFM sono stati progettati per essere installati in ambienti commerciali o industriali ove necessita una estrazione dell'aria, non polverosa o acida. questi ventilatori sono predisposti per essere installati a muro, a pannello o in condotti di ventilazione ove non siano presenti perdite di carico significative.
ATTENZIONE: L'INSTALLAZIONE DEVE ESSERE EFFETTUATA DA PERSONALE QUALIFICATO. • Gli apparecchi della serie AFM sono adatti ad espellere aria direttamente all'esterno o mediante breve condotto. • Garantire sempre l'immissione d'aria nel locale. • installare l'apparecchio alla parete fissandolo con adeguati tasselli ad espansione facilmente reperibili in commercio.
i t A l i A n o • i ventilatori con ventola sporgente devono essere installati in modo Fig. 3 tale che la distanza minima (dmin) tra la ventola e le parti fisse della macchina su cui vengono montati non deve essere inferiore a 20 mm, Fig.
Page 5
Ap4820 rpe 500 Ap4838 rpe 600 reGolAtori di velocità MonoFAse codice Modello per la regolazione dei modelli della serie AFM Ap2568 rdv 1,5-MF 250/4 MF, 300/4 MF, 350/4 MF, 400/6 MF Ap2600 rdv 3-MF 250/2 MF, 300/2 MF, 400/4 MF, 450/4 MF, 450/6 MF...
Well For Future reFerence description the AFM series axial fans are designed to be installed in domestic and commercial environments, where is required direct outdoor air expulsion. not suitable for acid and dusty air. these fans are designed for installation on walls, panels or ventilation ducts with limited air losses.
CAUTION: THE EQUIPMENT MUST BE INSTALLED BY QUALIFIED TECHNICIANS • AFM models are suitable to expel the air directly to the outside environment or via a short duct. • ensure a constant inflow of air into the room. • Fasten the equipment to the wall by means of suitable expansion blocks of the type commercially available.
e n G l i s H • Fans with prominent impeller shall be mounted so that the minimum Fig. 3 distance (dmin) between the impeller and the other parts of the equipment, where fan is fixed, shall never be less than 20mm, Fig. 3. 3.1 exAMples oF instAllAtion WAll MountinG pAnel MountinG...
Page 9
Ap4820 rpe 500 Ap4838 rpe 600 MonopHAse speed reGulAtors code Model to control all the AFM series models Ap2568 rdv 1,5-MF 250/4 MF, 300/4 MF, 350/4 MF, 400/6 MF Ap2600 rdv 3-MF 250/2 MF, 300/2 MF, 400/4 MF, 450/4 MF, 450/6 MF...
La garanzia si limita alla riparazione o sostituzione gratuita dei componenti risultanti difettosi per cause di fabbricazione accertate dalla ditta Aspira. Non sono coperti da garanzia i prodotti usati in modo non conforme alle indicazioni della Casa o manomessi da personale non autorizzato Aspira, nonché...
Page 12
CONDITIONS OF GUARANTEE All electrical appliances produced by Aspira are guaranteed by the Company for 2 YEARS against faulty materials or workmanship. If any part is found to be defective for the above mentioned reasons within the period of the guarantee from...
