- Page 1 3.1.2 Channel B&O Sound Bar with Wireless Subwoofer Q60H User Manual...
- Page 2 Contents 1 Before you begin ................. 4 2 Welcome ..................4 What’s in the box ......................4 Overview ...........................5 Soundbar ..........................5 Subwoofer ........................5 Set up your Soundbar system ..................6 Position your Soundbar and Subwoofer ................6 Mount your Soundbar on the wall ..................6 Mount your Soundbar on moveable floor stand ...............7 3 Connect your Soundbar system ..........
- Page 3 TCL ELECTRONICS AUSTRALIA PTY LTD bears no responsibility for accidents or damages caused by unauthorized changes, modifications or improper use of the product. User Manual can be found at www.tcl.com/au on the specific product page in the “Download” section. CAUTION...
- Page 4 • Unplug this apparatus during lightning storms or when unused for long periods of time. • Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
- Page 5 2 Welcome Congratulations on the purchase of your new TCL Soundbar! After it is set up and connected, you can experience a superb sound quality and state-of-the-art design to best fit your home entertainment system.
- Page 6 Overview Soundbar Subwoofer 1 Input Source LED Indicator 1 PAIR Indicator Wireless ( TV TX ) : Light blue Fast blink: Subwoofer in pairing mode Bluetooth : Blue Solid: Connected / Pairing successful USB : Green Slow blink: Connecting / Standby (On/Off) Button 2 PAIR Button Short press: Power on / sleep...
- Page 7 • Make sure you use screws provided or specified by the authorized manufacturer. • TCL AUSTRALIA bears no responsibility for accidents or damage caused by improper wall mounting and screws installation or insufficient wall strength, etc. • Additional tools (not supplied) are required for installation.
- Page 8 9 Fix and tighten the wall brackets and screws on the Soundbar. 10 Attach the wall brackets (x2) into the back of the unit. 11 Pick up the Soundbar and attach it to the brackets, similar to how you would hang a picture.
- Page 9 You will see the blue light on for 3 seconds. Pairing is successful. • If you cannot find the model name TCL Q60H on your Bluetooth device or if you want to pair another device, press and hold button. You will see blue light flashing. Now the...
- Page 10 Connect your wireless Subwoofer to the Soundbar When the wireless Subwoofer is connected, you can enjoy powerful deep bass sounds and a truly immersive audio experience. Auto pairing Make sure both the Soundbar and wireless Subwoofer areconnected to the power supply and are turned on.
- Page 11 LED on the Soundbar. Operate your TCL A300 PRO TV directly for playback features. • If the Soundbar and TCL A300 PRO TV paired fail, press and hold button. You will see light blue flashing. Now the Soundbar is coming into the pairing mode.
- Page 12 5 Specifications Product Name 3.1.2 Channel Dolby Atmos Sound Bar with Wireless Subwoofer Soundbar • Adapter mode: KA3601A-1802000EU Input: 100-240V~ 50/60Hz, 1.0A (Max) Output: 18.0V 2.0A 36.0W • Power consumption: 30 W • Power consumption at standby mode (after long pressing the power button): ≤ 0.5W •...
- Page 13 6 Notice Disposal of your old product and battery Your product is designed and manufactured with high quality materials and components, which can be recycled and reused. Environmental protection and sustainability We have omitted all unnecessary packaging and make sure it is eco-friendly and sustainable. Trademarks ®...
- Page 14 7 FAQ No power • Make sure the AC power cord and AC input connector are connected properly. • Make sure there is power supply. • Make sure the Soundbar has turned on. No sound • Make sure the audio cable is connected to the Soundbar and your device. •...
- Page 15 TCL support: Please visit www.tcl.com/au WE ARE READY TO HELP contact us first with any questions TAKE CARE WHEN REMOVING THE SOUNDBAR Copyright © 2024 TCL. All rights reserved. Q60H_EN_UM_V08...
- Page 16 Q60H 3.1.2 Channel B&O Sound Bar with Wireless Subwoofer Quick Start Guide English | Albanian | Bulgarian | Croatian | Czech | Danish | Dutch | Estonian | Finnish | French | German | Greek | Hungarian | ltalian | Latvian | Lithuanian | Macedonian | Norwegian | Polish | Portuguese | Romanian | Russian |...
- Page 17 Make sure you read all the safety information before you use this product. Sigurohuni që të lexoni të gjithë informacionin e sigurisë përpara se të përdorni produktin. Преди да използвате продукта, задължително прочетете всички инструкции за безопасност. Obavezno pročitajte sve sigurnosne informacije prije korištenja ovog proizvoda.
- Page 18 1 Input Source LED Indicator (On/Off) Button (Source/pairing) Button Buttons 5 Wall bracket slot 6 USB Type A connector 7 DC input power connector 1 PAIR Indicator 2 PAIR Button 3 AC input power connector...
- Page 19 THE SUBWOOFER WILL PAIR AUTOMATICALLY WITH SOUNDBAR UPON FIRST USE. In case of a problem, take the following steps to manually pair: > 3s > 3s...
- Page 20 > 10s > 10s > 10s > > TV TX : Light Blue Mute On/Off Voice Prompts On/Off Factory Power Off Volume Volume Subwoofer Pairing Bluetooth : Blue Blink White 2 times and then Default Solid White 3 seconds and then Power On Down (Manual pairing only)
- Page 21 > 10s > 10s > 10s > > TV TX : Light Blue Mute On/Off Voice Prompts On/Off Factory Power Off Volume Volume Subwoofer Pairing Bluetooth : Blue Blink White 2 times and then Solid White 3 seconds and then Default Power On Down...
- Page 22 > 10s > 10s > 10s > > TV TX : Light Blue Mute On/Off Voice Prompts On/Off Factory Power Off Volume Volume Subwoofer Pairing Bluetooth : Blue Blink White 2 times and then Solid White 3 seconds and then Default Power On Down...
- Page 23 < 3m 2m - 3.5m...
- Page 24 φ4 x 10 mm φ4 x 10 mm...
- Page 25 600mm / 23.6” > 5cm / 2" φ4 x 10 mm for the wall 600mm / 23.6” ~3mm 0.12” φ4 x 32 mm...
- Page 26 Blue Bluetooth Settings Bluetooth DEVICES TCL Q60H Connected Now Discoverable > 3s...
- Page 27 Light blue TCL A300 PRO TV > 3s...
- Page 28 Notice for US operate normally, or has been dropped. User Manual can be found at www.tcl.com/us on the specific product page in the “Download” section. • The user must maintain a minimum distance of 20CM from the device at all time.
- Page 29 fiche sont endommagés, si un liquide a été renversé ou si des objets sont tombés dans l'appareil, TCL North America décline toute responsabilité en cas d'accidents ou de dommages causés par des si l'appareil a été exposé à la pluie ou à l'humidité, s'il ne fonctionne pas normalement ou s'il est tombé.
- Page 30 Copyright © 2024 TCL. All rights reserved. Q75H-NA_USA_QSG_V0.2...
- Page 31 Green The supported file format is MP3, WMA, FLAC, WAV. Formati i skedarit të suportuar është MP3, WMA, FLAC, WAV. Поддържаният файлов формат е MP3, WMA, FLAC, WAV. Podržava format datoteke je MP3, WMA, FLAC, WAV. Podporovaný formát souboru je MP3, WMA, FLAC, WAV. Det understøttede filformat er MP3, WMA, FLAC, WAV.
- Page 32 Bluetooth SIG, Inc. and any use of such marks by TTE Corporation is under license. Other trademarks and trade names are those of their respective owners. Copyright © 2024 TCL. All rights reserved.
