This product is
certified in
accordance with
ECE R 44/04.
ECE R44/04
UNIVERSAL
0–13 kg
E
1
Group
0+
0-12
months
0-13 kg
Instruction Manual
Never place a
reversed car seat
IMPORTANT KEEP FOR FUTURE REFERENCE
on a front seat
Your child may be hurt if you do not follow these instructions. For the proper
with an airbag.
use of this product, be sure to read this User's Manual carefully.
uk
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the first CLASS 0+ and is the answer not in the manual?

Questions and answers

Related Manuals for Emmaljunga first CLASS 0+

Summary of Contents for Emmaljunga first CLASS 0+

  • Page 1 This product is certified in accordance with ECE R 44/04. ECE R44/04 UNIVERSAL 0–13 kg Group 0-12 months 0-13 kg Instruction Manual Never place a reversed car seat IMPORTANT KEEP FOR FUTURE REFERENCE on a front seat Your child may be hurt if you do not follow these instructions. For the proper with an airbag.
  • Page 2 Rev 001...
  • Page 3 In developing Emmaljunga First Class 0+, safety, ease of operation, comfort and design are always our top priorities. Emmaljunga First Class 0+ has been approved under the most recent ECE R 44/04 guidelines (June 2005) of the European safety regulations for car safety seats, and meets the most stringent safety requirements.

  • Page 4: Table Of Contents

    4.6 Storage of the instruction manual ................... 5. Use in the car 5.1 Instruction for use in the car ....................5.2 Install Emmaljunga First Class 0+ in the car ............. 5.3 Remove Emmaljunga First Class 0+ from the car ..........6. Care and maintenance 6.1 Care instructions...

  • Page 5: Important Safety Information

    Please read through the operating instructions carefully. Emmaljunga First Class 0+ is a safety product and is only safe when it is installed and used in accordance with the specifications! For the future use of Emmaljunga First Class 0+ it is important to keep the operating instructions in their place behind the headrest.
  • Page 6 Emmaljunga First Class 0+. Emmaljunga First Class 0+ may be used both on the front seat (WARNING! In this case, a front air bag must not be activated), and on the back seat, albeit exclusively against the direction of travel. Back seats which fold back must be locked.
  • Page 7 Never push or place anything under the Emmaljunga First Class 0+, since it may become unfastened in the event of a collision. Always secure the Emmaljunga First Class 0+ within the vehicle in such a way that it cannot be jammed by a movable seat or vehicle door during everyday use.
  • Page 8 First Class 0+ with a cloth if your vehicle is parked in strong sunlight. The seatbelt buckle of your Emmaljunga First Class 0+ has been developed in such a way that it can be rapidly opened in an emergency. It is thus not childproof and children could learn how to open it themselves.
  • Page 9 Keep the Emmaljunga First Class 0+ away from heating apparatus and other sources of warmth. Do not leave your car keys in the vehicle when you attach the Emmaljunga First Class 0+ inside. Many vehicle models are equipped with automatic locking mechanisms which lock automatically after a given time period if you close the doors from the outside.

  • Page 10: Overview

    3. OVERVIEW Car-Seat shell Harness buckle Shoulder straps Harness buckle pad Carrying handle Button to adjust the carrying handles Belt mover for the car waist seat belt Belt mover for the car shoulder seat belt Strap to adjust the 5-point harness/ To use when you shorten the shoulder straps Button to make First Class 0+ shoulder straps longer Handle lock to attach onto the base and/or to the car-seat adapter Handle to adjust the head protection and the lying curve.
  • Page 11 Rev 001...

  • Page 12: General Functions

    4. GENERAL FUNCTIONS 4.1 Adjusting the head protection/ Length adjustment By pushing the head protection upwards or downwards you can adjust the head protection and the lying curve optimal according to the size of the child. You will therefore always get the best fit and safety. Newborn: Headprotection should be in its lowest position (The lying curve levels automatically) Older babies: Pull the head protection upwards.(The lying curve becomes deeper) The adjustment of the head protection can be done with the child in the seat or out of the seat.

  • Page 13: Use Of The 5-Point Harness

    Place the shoulder straps and the crutch strap aside. Close the harness Place the baby in the Emmaljunga First Class 0+. Make sure that the shoulder straps are placed so that they will come out exactly above the baby’s shoulder. Adjust the head protection upwards or downwards, if necessary (see 4.1)
  • Page 14 Tighten the 5-point harness Tighten the 5-point harness by pulling the waist strap (1). Extend the 5-point harness Extend the shoulder straps by pressing the central adjustment button which is placed in between the baby’s legs (2) and pull the shoulder straps at the same time. WARNING! The harness must be fitted tightly during transport or the car journey.

  • Page 15: Carrying Handle/ Button On The Carrying Handle

    4.3 Carrying handle/ Button on the carrying handle You can adjust the carrying handle with one hand by pressing the small blue button on the handle and at the same time moving the carrying handle into the desired position. The carrying handle has 4 functions (+2 safety positions A+B, marked in light grey): Handle position (1): Locking of the cradle function (e.g to feed the baby) Handle position (2): When you place the baby in First Class 0+, or when you use First Class 0+ on the pram.

  • Page 16: Hood

    Adjust the hood: Adjust the hood by gently pulling the hood backward or forward. WARNING! Never carry Emmaljunga First Class 0+ by the hood, only carry it by the handle. Do not place any heavy objects on the hood. Rev 001...

  • Page 17: Nappy Storage

    4.5 Nappy Storage Open the Nappy storage by pressing the plastic handle lightly downwards. To close the storage,push it back into it’s original position. Do not place any heavy objects in the nappy storage. 4.6 Storage of the instruction manual Behind the head protection is the manual.

  • Page 18: Use In The Car

    Emmaljunga First Class 0+ can be used in the front seat (WARNING! a front air bag must not be activated) and in the back seat. However, the car seat can only be used in vehicle seats which are installed in the driving direction.

  • Page 19: Install Emmaljunga First Class 0+ In The Car

    (one on each side) on the Emmaljunga First Class 0+. Picture 3+4. Pull the cars diagonal seat belt over the head protection (3) of First Class 0+ and attach it into the blue clip on the back of the car seat.

  • Page 20: Remove Emmaljunga First Class 0+ From The Car

    Open the seat belt by clicking on the harness buckle. Pull the seat belt through the belt mover and remove the seat belt from the Emmaljunga First Class 0+. Place the carrying handle in carrying mode (upright position) The carrying handle can be adjusted by pressing on the blue button on the carrying handle.

  • Page 21: Care And Maintenance

    6. CARE AND MAINTENANCE 6.1 Care instructions The care of the Emmaljunga First Class 0+ should always take place outside the car. The plastic shell can be washed with luke warm water and mild soap/detergent. Please do not use any aggressive detergents since they can cause damage to the surface.

  • Page 22: Re-Fitting The Fabrics

    Picture 3. Release the rubber loops, which are situated at the lower part by the blue belt movers. Open both press studs which are located next to the blue belt movers. Picture 4. You can now remove the other part of the seat fabrics. 6.3 Re-fitting the fabrics Make sure that the 5-point harness is open.

  • Page 23: Guarantee

    7.1 Procedures in the event of activation of the guarantee In the event of activation of the guarantee, please consult your authorised Emmaljunga First Class 0+ stockist, which where necessary, shall send the child seat to the manufacturer with a description of the complaint and the original purchase receipt with the date of purchase.
  • Page 24 Instruction manual for Emmaljunga First Class 0+ 2007 Emmaljunga Barnvagnsfabrik AB All rights reserved Emmaljunga Barnvagnsfabrik AB Box 2056, SE-280 22 Vittsjö Sweden Internet: www.emmaljunga.se...
