Thank you very much for choosing our products!Please read this manual
carefully before using the product.
Surface Instructions：
① ................................. Functional indicator light→
○ 1 Blue
RCA
Input
instructions
② .................................
③ .................................
④ .................................
⑤ .................................
⑥ .................................
⑦ .................................
⑧ .................................
⑨ .................................
○ 2 Red/Blue
○ 3 Red/Blue
Red
U disk input
Red：Optical
Blue：Bluetooth
Blue：Coaxial
USB interface (automatically switch and play when inserting
usb flash drive)
Remote receiving window
Bass knob
Mid knob
Treble knob
Encoder knob (short press to start/short press to cut channel again
/rotate to adjust volume/long press to shut down)
Bluetooth antenna base
Analog RCA input (such as CD player, DAC decoder, mobile phone,
TV,etc., red to right channel, white to left channel)
○ 4
Digital signal
indication
Bright：A signal
Not bright：No signal
Advertisement
Related Manuals for DOUK AUDIO M1 Plus
Summary of Contents for DOUK AUDIO M1 Plus
- Page 1 Thank you very much for choosing our products!Please read this manual carefully before using the product. Surface Instructions： ① …………………………… Functional indicator light→ ○ 4 Digital signal ○ 1 Blue ○ 2 Red/Blue ○ 3 Red/Blue indication Input U disk input Red：Optical Bright：A signal instructions...
- Page 2 ⑪ …………………………… ⑩ …………………………… Coaxial input ⑫ …………………………… Optical input Speaker output (red connection +/ black connection -, ⑬ …………………………… R for right channel /L for left channel) Power interface (DC voltage shall not be higher than 30V) Remote control: ①...
- Page 3 Frequently asked Questions: Q: I have all the wires connected, but no sound output? A: 1. Check whether the POWER indicator is on or not. If it is not on, turn on the key to start the machine.After pressing the power button, the indicator will still not go on. At this point, you can find one with the same voltage output power supply to test again.
