DOUK AUDIO T3 PRO MM How To Use

T3 PRO MM Phono Stage Vacuum Tube Preamp
How to use
1. Connect the active speakers or an amplifier to the RCA output of T3
PRO.
2. Connect the turntable to the phono input of T3 PRO, or the AUX input
of T3 PRO.(AUX input with priority, please make sure AUX is
disconnected before using PHONO input.)
3. Connect the power adapter to T3 PRO and then plug the power cable
into the socket.
4. Rotate the knob to power on and adjust volume according to your
preference and enjoy music.
5. After use, left rotate the knob to power off and then disconnect the
power adapter.
Parameters
Audio input: MM phono / 3.5mm AUX

Audio output: stereo RCA

Output level: 600mV (3mV 1KHz)

SNR: ≥98dB

Frequency response: RIAA standard

THD: 0.1%

Working voltage: DC12V

