Page 1 CUV e: OWNER’S MANUAL...
Page 2 This publication includes the latest production information available before printing. Honda Motor Co., Ltd. reserves the right to make changes at any time without notice and without incurring any obligation.
Page 3 Congratulations on your purchase of a new The illustrations here in are based on the ● Honda vehicle. Your selection of a Honda EVP4 II ED type. makes you part of a worldwide family of satisfied customers who appreciate Honda's...
Page 4 A Few Words About Safety DANGER Your safety, and the safety of others, is very important. Operating this vehicle safely is an You WILL be KILLED or SERIOUSLY important responsibility. HURT if you don’t follow instructions. To help you make informed decisions about WARNING safety, we have provided operating procedures and other information on safety...
Page 5: Table Of Contents
Contents Vehicle Safety P. 2 Operation Guide P. 24 Maintenance P. 140 Troubleshooting P. 169 Information P. 189 Specifications P. 209...
Page 6: Vehicle Safety
Vehicle Safety This section contains important information for safe riding of your vehicle. Please read this section carefully. Safety Operation for Electric Vehicle....P. 3 Safety Guidelines ..........P. 6 Image Labels............P. 10 Safety Precautions..........P. 16 Riding Precautions ..........P. 18 Accessories &...
Page 7: Safety Operation For Electric Vehicle
Safety Operation for Electric Vehicle Safety Operation for A high-voltage battery for motor that drives ● the motor and a 12 V battery that powers Electric Vehicle the lighting unit are built into the electric vehicle. Follow the instruction manual for the Handling of Electric Vehicle battery for motor when handling the battery for motor.
Page 8 Safety Operation for Electric Vehicle Be aware of the following after a crash. ● You may suffer from electric shock if you are involved in a crash that greatly damages or deforms the vehicle. Never touch high-voltage components or their wiring (orange and purple colour).
Page 9 Safety Operation for Electric Vehicle WARNING Since your vehicle uses a high-voltage battery for motor, if you respond incorrectly when an accident occurs, it may cause unexpected problems that result in death or serious injury. If you are involved in a crash, follow the procedures and instructions stated in this manual.
Page 10: Safety Guidelines
Safety Guidelines Safety Guidelines Take Time to Learn & Practice Even if you have ridden other vehicles, practice Follow these guidelines to enhance your safety: riding in a safe area to become familiar with Perform all routine and regular inspections ●...
Page 11 Keep Your Honda in Safe Condition levers, brakes, and wheels. Ride slowly and cautiously. It's important to keep your vehicle properly maintained and in safe riding condition.
Page 12 Safety Guidelines Your vehicle may have suffered damage that is Use a fire extinguisher for an electrical fire. ● not immediately apparent. Have your vehicle Attempting to extinguish an electrical fire thoroughly checked at a qualified service facility with a small quantity of water can be as soon as possible.
Page 13 Safety Guidelines Battery for Motor If an abnormal smell is coming from the batteries for motor, there may be something wrong with them. Immediately stop your vehicle in a safe place outside that is away from anything flammable, turn the power switch to (Off) position, and then contact your authorised dealer.
Page 14: Image Labels
Image Labels Image Labels The following pages describe the label Read instructions contained in Owner's meanings. Some labels warn you of Manual carefully. potential hazards that could cause serious injury. Others provide important safety Read instructions contained in Shop Manual information.
Page 15 Image Labels BATTERY FOR MOTOR DIRECTION CAUTION LABEL • Do not touch or connect the terminals on the battery for motor with metal objects. • Install the battery in same orientation as shown on this label. BATTERY FOR MOTOR INSTALLATION LABEL Install and remove the battery vertically.
Page 16 Image Labels BATTERY LABEL DANGER • Keep flame and spark away from the battery. Battery sample produce explosive gas that can cause explosion. • Wear the eye protection and rubber gloves when handling the battery, or you can get burned or lose your eyesight by the battery electrolyte.
Page 17 Image Labels ACCESSORIES AND LOADING WARNING LABEL WARNING ED, II ED type ACCESSORIES AND LOADING • The safety stability and handling of this vehicle may be affected by the addition of accessories and luggage. • Read carefully the instructions contained in user's manual and installation guide before installing any accessory.
Page 18 Image Labels TYRE INFORMATION & CARGO LIMIT LABEL Tyres must be replaced by your authorised dealer. ED,II ED, PH type Cold tyre pressure: [Driver only] Front 200 kPa (2.00 kgf/cm , 29 psi) Rear 225 kPa (2.25 kgf/cm , 33 psi) [Driver and passenger] Front 200 kPa (2.00 kgf/cm , 29 psi)
Page 19 Image Labels MODIFICATION PREVENTION LABEL CAUTION • Do not open the cover or touch internal components • Improper handling of the motor can cause unexpected accidents, which can result in death or serious disability • Parts inside the cover should only be handled by qualified technicians •...
Page 20: Safety Precautions
Safety Precautions Safety Precautions Helmet Safety-standard certified, high-visibility, correct Ride cautiously and keep your hands on the size for your head ● handlebar and feet on the floor. Must fit comfortably but securely, with the ● Instruct your passenger to keep their hands chin strap fastened.
Page 21 Safety Precautions Gloves Full-finger leather gloves with high abrasion resistance. Boots or Riding Shoes Sturdy boots with non-slip soles and ankle protection. Jacket and Trousers Protective, highly visible, long-sleeved jacket and durable trousers for riding (or a protective suit).
Page 22: Riding Precautions
Riding Precautions Riding Precautions Brakes Observe the following guidelines: Running-in Period Avoid excessively hard braking. ● Sudden braking can reduce the vehicle's During the first 100 km (60 miles) of running, stability. follow these guidelines to ensure your vehicle's Where possible, reduce speed before future reliability and performance.
Page 23 P. 87) and leave your vehicle while taking Exercise extra caution when braking in wet the Honda SMART Key with you. Deactivate conditions. the Honda SMART Key system if necessary. If the brakes get wet, apply the brakes while P.
Page 24 Riding Precautions Parking with the Side Stand or Centre Left handle grip Stand Turn the power switch to the (Off) position. Using the side stand Push the side stand down. Centre stand Slowly lean the vehicle to the left until its weight rests on the side stand.
Page 25 Torque Control may not compensate for rough Honda Selectable Torque Control road conditions or rapid throttle operation. When the Honda Selectable Torque Control Always consider road and weather conditions, (Torque Control) detects rear wheel spin during as well as your skills and condition, when acceleration, the system will limit the amount of applying throttle.
Page 26: Accessories & Modifications
We strongly advise that you do not add any seriously hurt or killed. accessories that were not specifically designed for your vehicle by Honda or make Follow all instructions in this owner's modifications to your vehicle from its original manual regarding accessories and design.
Page 27: Loading
Loading Loading WARNING Overloading or improper loading can Carrying extra weight affects your vehicle's ● cause a crash and you can be seriously handling, braking, and stability. hurt or killed. Always ride at a safe speed for the load you are carrying.
Page 28: Basic Operation Flow
Vehicle (P.124) • Steering Lock (P.79) • Brake lock (P.118) Before pulling away, indicate • Honda SMART Key System your direction with the turn signal switch, and check for (P.80) • Anti-theft Alarm System oncoming traffic. (P.89) • Answer Back System...
Page 29: Turning Corners
Braking (P.125) Parking (P.19) Close the throttle and apply the front and rear brakes together. Park on a firm level surface. The brakelight will indicate Use the stand, lock the steering. that you have applied the brakes. Stopping If pulling off the road, signal early enough to show traffic that you are pulling over, and pull over smoothly.
Page 30: Parts Location
Parts Location Rear battery for motor (P.130) Front battery for motor (P.130) Throttle grip (P.165) Front brake fluid reservoir (P.158) Front brake lever Document bag/Tool kit (P.136) Fuse box (P.188) 12 V battery (P.156) Data link connector...
Page 31 Rear brake lever (P.160) Rear brake lock lever (P.118) USB socket (P.132) Luggage hook (P.138) Emergency seat opener (P.179) Seat (P.134) Helmet holder (P.135) Front box (P.137) Centre stand (P.20) Side stand (P.164)
Page 32 Instruments ED, PH, TH type You can change the speed and mileage meter unit. (P.42) (P.54) Do not operate the display functions for a long time with the motor inactivated. It may result in a low (or dead) 12 V battery.
Page 33 Battery for motor gauge Status bar (P.31) (bar/number) (P.30) Selectable area (P.38) Speedometer INFO area /Pop-up information (P.34) (P.65) Riding mode indicator (P.119) It displays current riding mode. Continued...
Page 34 Instruments (Continued) Battery for motor gauge (bar/number) The remaining charge for the batteries for motor appears. The remaining charge indicates the charge in whichever of the batteries is lower, either the front battery for motor or the rear battery for motor. How the bar and number in the battery for motor gauge decrease differs depending on the operating environment and how you drive.
Page 35: Maintenance Indicator
Status bar Maintenance indicator You can change the setting of the distance, month or year. High beam indicator PUSH START/READY indicator (P.33) Battery for motor temperature indicator Comes on when the battery for motor is very cold. SPORT mode cannot be used when the battery for motor temperature indicator is on.
Page 36 Instruments (Continued) System fail indicator Comes on when the system is fail. When the indicator comes on (P.173) Clock (12-hour or 24-hour display) To set the clock: (P.42) (P.53) Power limitation indicator When the power limit is about to be applied, the power limitation indicator flashes and comes on when the power is limited.
Page 37 PUSH START/READY indicator indicator PUSH START Flashes if the motor can be activated when the power switch is in the (On) position. When the indicator does PUSH START not flash (P.170) indicator READY Comes on when driving is possible and when you are driving.
Page 38 Instruments (Continued) INFO area TOTAL The INFO area displays various vehicle information. TRIP A TRIP B The following items are displayed by default. • Odometer [TOTAL] AVG SPEED • Tripmeter A [TRIP A] • Tripmeter B [TRIP B] Blank • Average speed [AVG SPEED] Press on the sel switch.
Page 39 The types of information item that can be Odometer [TOTAL] displayed in the INFO area are as follows: Total distance ridden. TOTAL (P.35) TRIP A (P.36) TRIP B (P.36) When “------” is displayed, go to your dealer AVG SPEED (P.37) for service.
Page 40 Instruments (Continued) Tripmeter A [TRIP A] Tripmeter B [TRIP B] Distance ridden since the tripmeter A was Distance ridden since the tripmeter B was reset. reset. When “----.-” is displayed, go to your dealer When “----.-” is displayed, go to your dealer for service.
Page 41 Average speed [AVG SPEED] Blank display Displays the average speed since the motor Display the blank. was activated. Display range: 0 to 199 km/h (0 to 124 mph) Initial display: “---” is displayed. ● When your vehicle has travelled less than ●...
Page 42 Instruments (Continued) Selectable area You can select the following: FAVORITE SWITCH • General menu (P.39) • FAVORITE SWITCH (Trip reset mode) General (P.41) menu Selectable area Press and hold on the sel switch Press on the sel switch...
Page 43 General Menu Status mode You can select the following: The Status mode displays various vehicle information. • Status mode The Status mode has four pages and displays • Trip reset mode two pieces of information on each page. • Setting mode Press on the sel switch while select the Status mode...
Page 44 Instruments (Continued) To switch the information page To change the information page, press on the sel switch. Page 1 Page 2 Page 3 Page 4 Press on the sel switch. Press on the sel switch. To change the information: (P.42) (P.49)
Page 45 Trip reset mode Press and hold on the sel switch. You can reset the tripmeter A or tripmeter B. The tripmeter A or B is reset. Select the trip reset mode. (P.39) Press on the sel switch. Also, the trip meter A is automatically reset when the battery for motor gauge increases Select the A or B by pressing by 35 % or more after recharging and riding...
Page 46 Instruments (Continued) Setting mode To shift to the setting mode Select the general menu. (P.38) Select the setting mode. (P.39) Press on the sel switch, and then display moves to the setting mode. Operation while driving is prohibited. Ordinary display Setting mode To return to the ordinary display •...
Page 47: Setting Flow
Setting flow Ordinary display Setting mode FUNCTION TRIP A AUTO RESET (P.46) BRIGHTNESS (P.47) BACKGROUND (P.48) DISPLAY FAVORITE INFO (P.49) FAVORITE SWITCH (P.52) GENERAL Push/Press Continued...
Page 48 Instruments (Continued) DISPLAY DATE & TIME (P.53) UNIT (P.54) GENERAL LANGUAGE (P.55) RESTORE DEFAULT (P.56) SERVICE Push/Press...
Page 49 GENERAL MAINTENANCE (P.57) SERVICE EQUIPMENT (P.64) (P.64) SYSTEM INFORMATION Push/Press Continued...
Page 50 Instruments (Continued) TRIP A AUTO RESET You can enable or disable the tripmeter A automatic reset mode. Select the (On) or (Off) using on the sel switch. Press on the sel switch to complete the setting. Return to the ordinary display to complete the setting.
Page 51: Automatic Brightness Control
BRIGHTNESS When select the "AUTO" Press on the sel switch to complete You can adjust the backlight brightness to the setting. one of the eight levels or select the auto When select the "MANUAL" adjustment. Press on the sel switch to select the Automatic brightness control: (P.196) backlight brightness using...
Page 52 Instruments (Continued) BACKGROUND You can change the setting of the background to one of the two colours or select the auto adjustment. Select the background colour using on the sel switch. Press on the sel switch to complete the setting. Return to the ordinary display to complete the setting.
Page 53 FAVORITE INFO You can change the information items displayed in the INFO area and STATUS mode. 1 line information You can change the information items displayed in the INFO area. (INFO area: Select the 1 line or 2 line information using (P.34) on the sel switch.
Page 54 Instruments (Continued) 1 line information setting Select the desired information item using on the sel switch. Select the 1 or 2 using on the sel Press on the sel switch, set the switch. information item. Items that have already been set are displayed with a green cursor.
Page 55 2 line information setting Select the upper or lower row using on the sel switch. Upper row Information Page item (Upper) Press on the sel switch to select the information items. Information Select the desired information item using item (Lower) on the sel switch.
Page 56 Instruments (Continued) Press on the sel switch to complete the FAVORITE SWITCH setting. "TRIP RESET" is displayed but not selectable. Return to the ordinary display to complete the setting. (P.42) To continue setting, press on the sel switch to return to the upper hierarchy.
Page 57 DATE & TIME Select the "Day", "Month", "Year", "Hour", "Minute", "24h or 12h" or "AM / PM" using on the sel switch. Select the desired setting using the sel switch. When "24 / 12" is set to 24-hour indication, "AM / PM" cannot be usable. Press on the sel switch to complete the setting.
Page 58 Instruments (Continued) UNIT You can change the speed and mileage units. Select the desired setting using the sel switch. Press on the sel switch to complete the setting. Return to the ordinary display to complete the setting. (P.42) To continue setting, press on the sel switch to return to the upper hierarchy.
Page 59 Press on the sel switch. LANGUAGE Changes the system language. Select the 1 or 2 using on the sel switch. Select the language using on the sel switch. Press on the sel switch to select the language. Items that have already been set are displayed with a green cursor.
Page 60 Instruments (Continued) The following items are restored to their RESTORE DEFAULT default values: The set values can be returned to the default • TRIP A AUTO RESET settings. • BRIGHTNESS Select the “NO” (not restore) or “YES” • BACKGROUND (restore) using on the sel switch.
Page 61 MAINTENANCE PERIODIC MAINTENANCE (P.58) You can select the following: • PERIODIC MAINTENANCE (P.58) BATTERY INFO • BATTERY INFO (P.60) (P.60) • WARNING INFO (P.61) WARNING INFO (P.61) : Press on the sel switch. : Press on the sel switch. : Press on the sel switch.
Page 62 Instruments (Continued) PERIODIC MAINTENANCE Display range: You can check the next periodic inspection Distance: time. ------, 12,000 to -99,999 km (8,000 to You can change the setting of the next 99,999 mile) periodic inspection. Pass 0 km: “-” mark is displayed. Changing the SPEED unit from "mile"...
Page 63 Next inspection setting Select the desired setting using the sel switch. Select the distance, month or year using If you press and hold on the sel on the sel switch. switch while setting the distance, it will move every 1000. Date Available setting range of the distance: ------, 100 to 12,000 km (100 to 8,000...
Page 64 Instruments (Continued) When reaching any of the following, the BATTERY INFO pop-up information is appears in the Displays the current batteries for motor ordinary display. charge. (P.65) “500 km” (“300 mile”) from the next ● periodic inspection. One month before the set month. ●...
Page 65 WARNING INFO Displays a current maintenance information and (or) warning information. Refer to the "Maintenance information": (P.65) Warning information Maintenance information : Rear battery for motor : Front battery for motor Continued...
Page 66 Instruments (Continued) When the warning information displays, refer to following. Indication Explanation Remedy Connection error or Refer to “Installing installation error at and Removing battery for motor. the Batteries for Motor” (P.130) Battery for motor Have your battery health low. for motor inspected by your authorised dealer.
Page 67 Indication Explanation Remedy Battery for motor is Refer to “When the Power hot. limitation indicator Comes On” (P.171) Battery for motor is Refer to “When the Power cold. limitation indicator Comes On” (P.171) Power control unit Refer to “When the Power (PCU) or motor is hot.
Page 68 Instruments (Continued) EQUIPMENT SYSTEM INFORMATION "EQUIPMENT" is displayed but not selectable. Displays the software version and hardware information.
Page 69 Pop-up information In the following cases, pop-up information is displayed at the INFO area. Maintenance information: ● When the inspection time of your vehicle is approaching. Maintenance Information Indication Explanation Remedy When the periodic Have your vehicle inspection time of your inspected by your vehicle is approaching.
Page 70 Instruments (Continued) II ED, II TH, II V type You can change the speed and mileage meter unit. (P.102) Do not operate the display functions for a long time with the motor inactivated. It may result in a low (or dead) 12 V battery. If more than 7 days have passed since the power switch was turned off or if the 12V battery was removed, it will take some time for the display to appear.
Page 71 Indicator (P.68) Odometer [TOTAL] Total distance ridden. When “------” is displayed, go to your dealer for service. Speedometer Honda RoadSync Duo area (P.70) Continued...
Page 72 Instruments (Continued) Indicator READY indicator Comes on when driving is possible and when you are driving. Battery for motor temperature indicator Comes on when the battery for motor is very cold. SPORT mode cannot be used when the battery for motor temperature indicator is on.
Page 73 System fail indicator Comes on when the system is fail. When the indicator comes on (P.173) Power limitation indicator When the power limit is about to be applied, the power limitation indicator flashes and comes on when the power is limited. The power is limited in any of the following cases.
Page 74 Instruments (Continued) Honda RoadSync Duo area Honda RoadSync Duo status PUSH START/READY indicator (P.102) Clock (12-hour or 24-hour display) (Honda RoadSync Duo area) (P.71) To set the clock: (P.102) Battery for motor gauge (bar/number) (P.72) Riding mode indicator (P.119) Multi display...
Page 75 PUSH START/READY indicator Available driving distance (Range) Displays the estimated distance you can indicator travel on the remaining charge for the PUSH START Flashes if the motor can activate when the batteries for motor. The indicated available power switch is in the (On) position. driving distance is calculated based on the When the indicator does...
Page 76 Instruments (Continued) Battery for motor gauge (bar/number) The remaining charge for the batteries for motor appears. The remaining charge indicates the charge in whichever of the batteries is the lowest, either the front battery for motor or the rear battery for motor. How the bar and number in the battery for motor gauge decrease differs depending on the operating environment and how you drive.
Page 77 Pop-up information In the following cases, pop-up information appears. Warning indicator: ● When malfunction is detected. Update: ● When there is update. Other: ● When there is other notice. Press of the 4-way key/ switch to view detailed pop-up information.
Page 78 Indicators If one of these indicators does not come on when it should, have your dealer check for problems. Refer to the "Instruments" about indicators appeared on the display: (P.31) (P.68) II ED, II TH, II V type shown Left turn signal indicator Right turn signal indicator ED,II ED type only Malfunction indicator lamp (MIL)
Page 79 Alarm indicator Anti-theft Alarm system: (P.89) Honda SMART Key Indicator Comes on when vehicle and Honda SMART Key verification is complete, ● and the power switch can be operated. Goes off when the power switch is turned to the (On) position.
Page 80 Switches ECON/STANDARD/SPORT Riding mode switch Changes the riding mode. (P.119) Motor start/reverse button Horn button Turn signal switch Pressing the switch turns the turn signal off. Multi selection switch (P.78) Headlight dimmer/Passing light control switch • : High beam • : Low beam •...
Page 81: Power Switch
Power switch Switches the electrical system on/off and locks the steering. To unlock the power switch (P.85) (Lock) Locks steering. (On) (Off) Turns electrical system Turns electrical on for starting/riding. system off. SEAT Operates the seat opener switch. Continued...
Page 82 Switches (Continued) Multi selection switch ED, PH, TH type II ED, II TH, II V type Sel switch “Menu up” switch Used to operate the display. Used to operate the display. 4-way key/ switch Used to operate the display. “Left action” switch “Up action”...
Page 83 Steering Lock Locking Turn the handlebar all the way to the left or Lock the steering when parking to help right. prevent theft. Push the power switch down, and turn it to A U-shaped wheel lock or similar device is (Lock) position.
Page 84: Honda Smart Key System
The system runs a two-way authentication between the vehicle and the Honda SMART Key to verify if it is the registered Honda SMART Key. The Honda SMART Key system uses low- intensity radio waves. It may affect medical...
Page 85 ED,II ED type Except ED,II ED type System To switch the Honda SMART Key system to activation or deactivation Press the ON/OFF button until the Honda SMART Key LED changes colour. To check the Honda SMART Key ON/OFF button ON/OFF button system status Lightly press the ON/OFF button.
Page 86: Operating Range
The Honda SMART Key system uses low- intensity radio waves. Therefore, the operating range may be wider or narrower, or the Honda SMART Key system may not work properly in the following situations: When the Honda SMART Key battery is ●...
Page 87 Anyone can unlock the power switch and When the power switch is locked: activate the motor if your Honda SMART Key The system can be operated within the is within operating range of your vehicle, shaded area shown in the illustration.
Page 88 ● You should always keep the Honda SMART time. Key on your person after you get on and off the vehicle or while riding. Do not store the Honda SMART Key in any compartment.
Page 89 Turn the power switch to the (On) position while the Honda SMART Key indicator To Unlock the Power Switch comes on. Make sure that the Honda SMART Key If you do not turn the power switch to system is activated. (P.81)
Page 90 Honda SMART Key System (Continued) If someone without the Honda SMART Key Honda SMART Key tries to turn the power switch, the power switch rotates freely. If you notice the power switch is in a different position, turn the power switch to the original (...
Page 91 (Lock) position. Switch the Honda SMART Key system ● to inactive. (P.81) Make sure that the Honda SMART Key indicator goes off, the turn signals flash once. This indicates that the power switch is locked. Except ED,II ED type The buzzer also rings 1 time at this time.
Page 92 Except ED,II ED type Enable When the power switch is locked in the SEAT Deactivate the Honda SMART Key system. position, the power switch can be turned to (P.81) Lightly press the ON/OFF button. The red (Off) position only once.
Page 93: Anti-Theft Alarm System
Anti-theft Alarm System Except ED,II ED type The anti-theft alarm system is a device to reduce the likelihood of theft. When the sensor detects vibration or movement with the power switch in the (Off) or (Lock) position and the system is set, the alarm is activated.
Page 94: Alarm Indicator
Anti-theft Alarm System (Continued) If the power switch is left the (Off) or Setting the Anti-theft Alarm System (Lock) position for more than 10 days, the Turn the power switch to (Off) or anti-theft alarm system will no longer (Lock) position. operate.
Page 95 (P.85) Press the answer back/alarm button on ● When the power switch is unlocked, the the Honda SMART Key. buzzer rings 2 times and the alarm indicator After stopping the anti-theft alarm activation, the anti-theft alarm system goes off.
Page 96 Make sure that the Honda SMART Key Press the answer back/alarm button on system is active. (P.81) the Honda SMART Key 4 times and the Push the power switch to authenticate the power switch 1 time. Honda SMART Key system.
Page 97 Press and hold the power switch for more power switch is not pressed for 1 minute, than 2 seconds. The sensitivity level is set. the Honda SMART Key indicator flash 3 The Honda SMART Key indicator turn off, times, and then the buzzer sounds and and a buzzer sounds once.
Page 98: Answer Back System
The answer back system is a device to find Answer back button the location of your vehicle. When you press the answer back button on the Honda SMART Key with the power switch is in the (Off) or (Lock) position and the...
Page 99: Operation
Operation Press the answer back button on the Honda SMART Key. The answer back system will not function when the power switch is in the (On) position. If the power switch is left in the (Off) or (Lock) position for more than 10 days, the answer back system will no longer operate.
Page 100 Honda SMART Key system is activated. When you press the answer back/alarm button on the Honda SMART Key with the power switch is in the (Off) or (Lock)
Page 101 Press the answer back/alarm button on the Honda SMART Key. You can select 3 buzzer sound volume levels. The answer back system will not function Make sure that the Honda SMART Key when the power switch is (On) position. system is active. (P.81)
Page 102 Return to Press the answer back/alarm button on do the procedure again. the Honda SMART Key 2 times and the If you press the answer back/alarm power switch 1 time. button the wrong number of times...
Page 103 2 seconds. The sound volume level is Sound Pattern set. You can select 3 buzzer sound patterns. The Honda SMART Key indicator turn off, Make sure that the Honda SMART Key and a buzzer sounds once. system is active.
Page 104 Return to a and Press the answer back/alarm button on do the procedure again. the Honda SMART Key 3 times and the If you press the answer back/alarm button the wrong number of times power switch 1 time.
Page 105 10 seconds, the Honda Press and hold the answer back/alarm button SMART Key indicator flash 3 times, and for about 2 seconds, the Honda SMART Key then the buzzer sounds, and the sound LED changes to red.
Page 106 Honda RoadSync Duo For terms of service and information on how II ED, II TH, II V type By connecting your smartphone to both a to install/operate the dedicated application, Bluetooth headset and the vehicle via ® see the following URL:...
Page 107: Communication Range
The Wi-Fi word mark and logos are version registered trademarks owned by Wi-Fi Bluetooth Wireless Technology alliance and any use of such marks by Honda ® The Bluetooth word mark and logos are Motors Co., Ltd., is under license. ®...
Page 108 Honda RoadSync Duo (Continued) Costs of network communication and The system itself has certain limitations. ● communication equipment necessary for Therefore, you must verify the voice the use of this feature shall be borne by guidance and information in the meter the user.
Page 109 WARNING When operating the navigation system, please stop the vehicle in a safe place. Using the Honda RoadSync Duo while Due to traffic information, road construction riding can take your attention away or closures, detours, or outdated maps, an from the road, causing a crash in which inappropriate route may be suggested.
Page 110 Honda RoadSync Duo application. functionality and services without notice. Only one smartphone can be connected at Honda cannot and does not provide any the same time. warranty or guarantee of operating systems, To connect other smartphone, disconnect hardware, software, and other technology the Bluetooth pairing.
Page 111 Push the “Menu down” switch until Select “Pair new phone” by the 4-way key/ setting mode is displayed. switch. Select the “Bluetooth” by the 4-way key/ switch. Select “I have the app” by the 4-way key/ switch. Continued...
Page 112 Honda RoadSync Duo (Continued) Read the QR code with the smartphone Follow the instruction of the application, application. finish pairing. For operation of the application, follow When pairing is complete, “Paring the instruction of the application. Complete” will be displayed.
Page 113 If you failed to pair, “Couldn't find Disconnecting your smartphone via device” will be displayed, and then the Bluetooth and forgetting pairing ® pairing standby state ends. record Perform again. Make disconnect/forget operation after stopping your vehicle at a safe place. Push the “Menu down”...
Page 114 Honda RoadSync Duo (Continued) Select connected smartphone from Connecting your smartphone via Wi-Fi “Devices” by the 4-way key/ switch. Connect your smartphone after stopping your vehicle at a safe place. If the 12 V battery is low on charge, charge it before connecting.
Page 115 Turn on “Wi-Fi” by the 4-way key/ switch. Select “Connect” by the 4-way key/ Network searching starts. switch. Turn on the personal hotspot on your smartphone. Input password by the displayed keyboard using the 4-way key/ switch. Select network you want to connect by the When you complete inputting, it displays 4-way key/ switch.
Page 116 Honda RoadSync Duo (Continued) When smartphone is connected, it displays Disconnecting from Wi-Fi “Connected.” Make disconnect operation after stopping If it failed to connect, perform your vehicle at a safe place. again. Push the “Menu down” switch until setting mode is displayed.
Page 117 Turn off “Wi-Fi.” Forgetting Wi-Fi connection record Make disconnect/forget operation after stopping your vehicle at a safe place. Push the “Menu down” switch until setting mode is displayed. Select the “Wi-Fi” by the 4-way key/ switch. Continued...
Page 118 Honda RoadSync Duo (Continued) Select connected network from “Networks” Software Updates by the 4-way key/ switch. “1 Update” is displayed in Pop-up area when vehicle receives information about software update. Update software after stopping at a safe place. If the 12 V battery is low on charge, charge it before updating.
Page 119 Connect internet via Wi-Fi. Press the 4-way key/ switch to start (P.110) Activate the motor. download. (P.121) Press “Down action” switch to display detailed Pop-up information. Press the switch to display update contents. If you select “Explore New Features,” it displays detailed Pop-up information.
Page 120 Honda RoadSync Duo (Continued) If you turn the power switch to (Off) Press the 4-way key/ switch to start install. position, download will be interrupted or If you turn the power switch to (Off) cancelled. position, install will be interrupted or Download resume when you turn the cancelled.
Page 121 Press the switch to reboot the vehicle.
Page 122: Rear Brake Lock
Rear Brake Lock Be sure the rear brake lock is applied while Unlocking activating the motor. Squeeze the rear brake lever. Before riding, make sure that the rear brake Locking lock is fully released so there is no drag on Squeeze the rear brake lever and set the rear the rear wheel.
Page 123: Riding Mode
Riding mode You can change the riding mode. mode: SPORT This mode provides an experience powerful Riding modes acceleration and responsiveness of EV. Depending on the capacity, load and temperature of the batteries for motor, the mode: STANDARD mode may be limited. When the This mode provides a balance between SPORT limit is about to be reached, the...
Page 124 Riding mode (Continued) Selecting the riding mode ECON Changing to the mode: ECON Press the on the ECON riding mode ECON/STANDARD/SPORT switch. STANDARD/SPORT Changing to the STANDARD SPORT mode: Each time the on the STANDARD/SPORT riding mode ECON/STANDARD/SPORT switch is pressed, it switches between modes.
Page 125 If the vehicle is over-turned, you must first turn the power switch to the (Off) position and then inspect the vehicle carefully. This vehicle is equipped with a Honda SMART Key system. Always keep Honda SMART Key on you when you ride the vehicle.
Page 126 Activating the Motor (Continued) Check the indicator is flashing. PUSH START ED, PH, TH type If the indicator is not PUSH START flashing, the motor cannot activate. When the indicator PUSH START does not flash (P.170) II ED, II TH, II V type...
Page 127 While the throttle grip is completely closed, ED, PH, TH type press the motor start/reverse button. When the motor activates, the READY indicator comes on. You can now drive your vehicle. (P.124) Release the motor start button as soon as the indicator comes on.
Page 128 Riding Starting the Vehicle Release the rear brake lock. Acceleration and deceleration Make sure that the indicator comes READY To accelerate: Open the throttle slowly. To decelerate: Close the throttle. If the indicator does not come on, READY the vehicle cannot start. Activate the motor. Close Open (P.121)
Page 129: Front Brake Lever
Braking Close the throttle and apply the front and rear brake levers together. Do not apply the brake lock while riding. It may cause the wheel to lock, reducing control of the vehicle. II V type only When squeezing the brake levers, though you open the throttle, the motor output will be stopped.
Page 130 Moving in Reverse The reverse system allows you to back out of Stop the vehicle. Sit astride the vehicle, in your normal a parking space at slow speed. riding position, with both feet on the ground. Before you move the vehicle backward, make Make sure the side stand and centre stand sure there are no people or obstacles in the are up.
Page 131: Ready Indicator
Press the motor start/reverse button. ED, PH, TH type indicator READY "R" While holding the button down, the vehicle is in standby for reversing and will not move forward when the throttle is opened. When the vehicle is in standby for reversing, "R"...
Page 132 Moving in Reverse (Continued) When you are ready to back up, press and ED, PH, TH type hold both the motor start/reverse button and the reverse button (ED, PH, TH type), “Menu down” switch (II ED, II TH, II V type). The vehicle will move in reverse as long as you hold both the buttons down.
Page 133 Guide the vehicle backward cautiously, using your legs to maintain balance. Use extreme care to maintain balance while reversing on loose surfaces (sand, dirt, gravel) or slick pavement. Release either the motor start/reverse button or the reverse button (ED, PH, TH type), “Menu down”...
Page 134 Battery for Motor Please use the batteries for motor specified Installing and Removing the Batteries by Honda for your vehicle. for Motor Do not use the batteries for motor for Do not subject the batteries for motor to anything other than your vehicle.
Page 135 If Use only battery for motor specified by you cannot remove it, do not force it. Honda in your vehicle. Contact your authorised dealer. Do not directly touch the plugs in the boxes of battery for motor with your hands or metal objects, such as tools.
Page 136: Usb Socket
Use USB devices at your own risk. In no event Open the front box lid. (P.137) Open the cover to access the USB socket. shall Honda be liable for any damages to Connect a certified USB cable to the USB your USB device when in use. socket.
Page 137 Make sure the USB cable is not dangling. When the USB socket is used, turn the power switch to the (On) position. To prevent entry of foreign matter into the USB socket, be sure to close the cover when the USB socket is not used. Carefully secure all connected devices, as vibration may cause damage to them or they could shift unexpectedly.
Page 138: Storage Equipment
Close and push down on the rear of the seat until it locks. Make sure that the seat is locked securely by pulling it up lightly. Take care not to lock your Honda SMART Key under the seat. Seat opener switch...
Page 139: Helmet Holder
Helmet Holder WARNING The helmet holders are located under the Riding with a helmet attached to the seat. holder can interfere with your ability to Use the helmet holder only when parked. safely operate the vehicle and could Helmet holders lead to a crash in which you can be seriously hurt or killed.
Page 140 Storage Equipment (Continued) Document Bag Document bag The document bag is stored in the luggage box. Tool kit Except II V type The tool kit is stored in the luggage box. Tool kit Luggage box Opening the seat (P.134)
Page 141: Front Box
Front Box Open Push the front box lid, then open the front box lid. Close Close the front box lid by pressing the front box lid. The maximum allowable load on the front box shall be no more than 1.0 kg (2.2 lb). Make sure that the front box lid is closed securely.
Page 142: Luggage Hook
Storage Equipment (Continued) Luggage hook The maximum allowable load on the luggage The luggage hook is provided below the hook shall be no more than handlebar. 1.5 kg (3.3 lb). Do not attach large luggage to the luggage hook that would hang out from the vehicle and/or interfere with the movement of your feet.
Page 143: Lid Switch
Rear Carrier ED, II ED, PH type Never exceed the maximum weight limit. Maximum Weight: 3.0 kg (6.6 lb) Rear carrier Lid switch Lid switch is used for optional parts.
Page 144: Maintenance
Tools ..............P. 155 Removing & Installing Body Components ........... P. 156 12 V Battery............P. 156 Brakes..............P. 158 Side Stand ............P. 164 Throttle .............. P. 165 Other Replacement......... P. 166 Replacing the Honda SMART Key Battery .. P. 166...
Page 145: Importance Of Maintenance
Importance of Maintenance Importance of Maintenance Maintenance Safety Keeping your vehicle well-maintained is Always read the maintenance instructions absolutely essential to your safety and to before you begin each task and make sure that protect your investment, obtain maximum you have the tools, parts, and skills required. performance and avoid breakdowns.
Page 146: Maintenance Schedule
Retain all receipts. If you sell the vehicle, these Maintenance work should be performed in receipts should be transferred with the vehicle accordance with Honda's standards and to the new owner. specifications by properly trained and equipped technicians. Your authorised dealer meets all of Honda recommends that your authorised these requirements.
Page 147 : Inspect (clean, adjust, lubricate, or replace, if authorised dealer, unless you have the necessary necessary) tools and are mechanically skilled. Procedures are provided in an official Honda Shop Manual. : Technical. In the interest of safety, have your vehicle serviced by your authorised dealer.
Page 148 Maintenance Schedule Frequency Pre-ride Annual Regular Refer to Items Check × 1,000 km Check Replace page P. 145 × 1,000 mi Suspension – Nuts, Bolts, Fasteners – Wheels/Tyres Steering Head Bearings – Notes: 1 : At higher odometer reading, repeat at the frequency interval established here. 2 : Replacement requires mechanical skill.
Page 149: Maintenance Fundamentals
Maintenance Fundamentals Side stand motor drive cut-off system - Pre-ride Inspection ● Check for proper function. P. 164 To ensure safety, it is your responsibility to Wheels and tyres - Check condition, air ● perform a pre-ride inspection and make sure pressure and adjust if necessary.
Page 150 Maintenance Fundamentals WARNING Replacing Parts Always use Honda Genuine Parts or their Installing non-Honda parts may make equivalents to ensure reliability and safety. your vehicle unsafe and cause a crash in which you can be seriously hurt or ED, II ED type killed.
Page 151 Maintenance Fundamentals WARNING Battery for Motor If you use the batteries for motor for an The batteries for motor contain extended time, their capacitance will steadily combustible organic solvents as an degrade. Therefore, the mileage becomes electrolyte solution. shorter compared to when you started using Mistakenly handling the batteries for your vehicle as when it was new.
Page 152 Maintenance Fundamentals 12 V Battery NOTICE Your 12 V battery is a maintenance-free type and Your vehicle has a maintenance-free type 12 V can be permanently damaged if the cap strip is battery. You do not have to check the 12 V removed.
Page 153 Maintenance Fundamentals WARNING What to do in an emergency If any of the following occur, immediately see The 12 V battery gives off explosive your doctor. hydrogen gas during normal operation. Electrolyte splashes into your eyes: ● Wash your eyes repeatedly with cool water for at least 15 minutes.
Page 154 If the terminals are heavily corroded, clean and polish the terminals with a wire brush or NOTICE sandpaper. Wear safety glasses. Installing non-Honda electrical accessories can overload the electrical system, discharging the 12 V battery and possibly damaging the system.
Page 155 Maintenance Fundamentals If a fuse fails repeatedly, you likely have an Fuses electrical fault. Have your vehicle inspected by Fuses protect the electrical circuits on your your authorised dealer. vehicle. If something electrical on your vehicle stops working, check for and replace any blown fuses.
Page 156: Recommended Brake Fluid
Inspect the tyres for Wipe up spills immediately and wash thoroughly. cuts, slits, or cracks that Recommended brake fluid: expose fabric or cords, Honda DOT 3 or DOT 4 Brake Fluid or or nails or other foreign objects equivalent embedded in the side of the tyre or the tread.
Page 157 Maintenance Fundamentals WARNING Inspecting for Abnormal Wear Inspect the tyres for Riding on tyres that are excessively signs of abnormal wear worn or improperly inflated can cause a on the contact surface. crash in which you can be seriously hurt or killed.
Page 158 Maintenance Fundamentals Have your tyres replaced by your authorised WARNING dealer. Installing improper tyres on your For recommended tyres and air pressure, see vehicle can adversely affect handling “Specifications.” P. 210 and stability, and can cause a crash in Follow these guidelines whenever you replace tyres: which you can be seriously hurt or Use the recommended tyres or their...
Page 159: Tools
Tools Except II V type The tool kit is stored in the luggage box. P. 136 You can perform some roadside repairs, minor adjustments and parts replacement with the provided tools. ED, II ED type 10 × 14 mm Open end wrench ●...
Page 160: Removing & Installing Body Components
Removing & Installing Body Components 12 V Battery Removal Make sure the power switch is in the (Off) Battery lid Bolts position. Remove the battery lid from step floor by removing the bolts. Disconnect the negative - terminal from the 12 V battery. Disconnect the positive + terminal from the 12 V battery.
Page 161 Removing & Installing Body Components 12 V Battery Except ED, II ED type The anti-theft alarm system will be deactivated if the 12 V battery is disconnected. The system will remain off when the 12 V battery is reconnected. To activate the system, “Setting the Anti-theft Alarm System.”...
Page 162: Brakes
Brakes Checking the Front Brake Fluid Place your vehicle in an upright position on a firm, level surface. Check that brake fluid reservoir is Front brake horizontal and that the fluid level is above fluid reservoir the LWR mark. If the brake fluid level in the reservoir is below the LWR mark or the brake lever freeplay becomes excessive, inspect the brake pads for wear.
Page 163 Brakes Inspecting the Front Brake Pads Inspecting the Front Brake Brake pads Pads Check the condition of the brake pad wear indicators. The pads need to be replaced if a brake pad is worn to the indicator. Wear indicators Inspect the brake pads from below the brake Disc caliper.
Page 164 Brakes Inspecting the Rear Brake Lever Freeplay Inspecting the Rear Brake Lever Check the brake cable for kinks or signs of wear. If necessary, have it replaced by your Freeplay authorised dealer. Lubricate the brake cable with a Place the vehicle on its centre stand. commercially available cable lubricant to Measure the distance the rear brake lever prevent premature wear and corrosion.
Page 165: Adjusting The Rear Brake Lever Freeplay
Brakes Adjusting the Rear Brake Lever Freeplay Adjusting the Rear Brake Lever Adjust by turning the rear brake adjusting nut a half-turn at a time. Freeplay Adjust the freeplay of the brake lever with the front wheel pointed straight ahead. Make sure the cut-out on the adjusting nut is Increase seated on the brake arm pin when adjusting...
Page 166 Brakes Adjusting the Rear Brake Lever Freeplay Apply the brake several times and check After adjustment, confirm the freeplay of the for free wheel rotation after the brake brake lever. lever is released. Make sure the brake arm, spring and fastener Push the brake arm to confirm that there are in good condition.
Page 167 The rear brake is equipped with a brake wear the brake, the brake shoes must be replaced. indicator. See your authorised dealer for this service. When brake service is necessary, see your Arrow authorised dealer. Use only Honda Genuine Parts or their equivalent. Reference mark Brake arm...
Page 168: Checking The Side Stand
Side Stand Checking the Side Stand Place your vehicle on its centre stand on a firm, level surface. Check that the side stand operates smoothly. If the side stand is stiff or squeaky, clean the pivot area and lubricate the pivot bolt with clean grease. Check the spring for damage or loss of tension.
Page 169: Throttle
Throttle Checking the Throttle With the power switch is in the (Off) position, check that the throttle rotates smoothly from fully closed to fully open. If the throttle does not move smoothly or close automatically, have the vehicle inspected by your authorised dealer.
Page 170: Other Replacement
Honda SMART Key Battery with a protective cloth into the slit. Wrap a coin or a screwdriver with a If the Honda SMART Key indicator flashes 5 protective cloth to prevent scratching times when the power switch is turned to the the Honda SMART Key.
Page 171 Lower case Replace the old battery with a new battery with the negative - side facing Snap the two halves of the Honda SMART Key back together. Make sure that upper and lower cases are set in the right position.
Page 172 The battery is imported by: an explosion. Honda Motor Europe Ltd - Aalst Office • Do not subject to extremely low air Wijngaardveld 1(Noord V), 9300 Aalst - pressure at high altitude that may result in...
Page 173: Troubleshooting
Other Warning Indications ......P. 176 Battery for Motor Gauge Failure Indication ............P. 176 When the Honda SMART Key System Does Not Operate Properly........... P. 177 Unlock the Seat in an Emergency ....P. 179 Unlock the Power Switch in an...
Page 174: Electric Vehicle Does Not Drive
Electric Vehicle Does Not Drive When the Display Does Not Appear When the Standby Indicator Does Even When You Put the Power Not Flash Switch in the (On) Position Check the following items: Make sure the seat completely closed. Check the following items: ●...
Page 175: Motor Does Not Operate
Electric Vehicle Does Not Drive Motor Does Not Operate When the Power limitation Indicator Comes On Check the following items: Is there any charge remaining for the If an abnormal temperature is detected, ● batteries for motor? P. 28, P. 66 power limitation indicator comes on to Is system fail indicator come on? preserve the PCU or motor.
Page 176 Electric Vehicle Does Not Drive When the Battery for Motor When the Battery for Motor Indicator Comes On Temperature Indicator Comes On This comes on if there is an abnormality with the battery for motor. If the low temperature of the battery for motor is detected, battery for motor temperature indicator comes on to preserve Contact your authorised dealer immediately.
Page 177: Warning Indicators On Or Flashing
Warning Indicators On or Flashing System Fail Indicator Power Limitation Indicator If the indicator comes on while power switch If you are continuously driving up steep is in the (On) position, you may have a slopes, it may become difficult to drive up serious problem.
Page 178: Honda Smart Key Indicator
5 times (Off) or (Lock) position while the Honda Replacing the Honda SMART Key SMART Key indicator is flashing, the Honda Battery P. 166 SMART Key indicator will flash faster for about 20 seconds, automatically go off, and When the Honda SMART Key then the power switch will lock.
Page 179 To stop this flashing, press and hold the power switch for more than 2 seconds. After the flashing stop, the power switch is locked. If you do not have the Honda SMART Key, the power switch can be unlocked in another way.
Page 180: Other Warning Indications
Other Warning Indications Battery for Motor Gauge Failure Indication ED, PH, TH type When the numbers of the battery for motor gauge comes on and goes off repeatedly, such as in the diagram, contact your authorised dealer.
Page 181: When The Honda Smart Key System Does Not Operate Properly
When the Honda SMART Key System Does Not Operate Properly When the Honda SMART Key system does Check that there is no communication ● not work properly, perform the following. failure in the Honda SMART Key system. Check that the Honda SMART Key system The Honda SMART Key system uses low- ●...
Page 182 When the Honda SMART Key System Does Not Operate Properly Check that a registered Honda SMART Check the 12 V battery condition and 12 V ● ● Key is used. battery lead in your vehicle. Use a registered Honda SMART Key.
Page 183: Unlock The Seat In An Emergency
Unlock the Seat in an Emergency The seat lock can be unlocked by using the Open the seat and turn the emergency emergency key. key clockwise. Emergency Open seat opener Pull out the front lid backward while pushing the side of the front lid. Projection Close Front lid...
Page 184 Unlock the Seat in an Emergency Close Install the front lid. Make sure that all tabs are installed Close and push down on the rear of the securely in position. seat until it locks. Make sure that the seat is locked securely by pulling it up lightly. If the seat is not locked, turn the emergency key clockwise to lock the seat catch.
Page 185: Unlock The Power Switch In An Emergency
ID number on the ID tag in order from the flashes. left in turn by pressing the power switch. Press the power switch while the Honda The ID number is authenticated according to SMART Key indicator is flashing. the number of times the power switch is The Honda SMART Key indicator stay pushed.
Page 186 Unlock the Power Switch in an Emergency Example: ID number input success To input “0”, wait for 5 seconds without After the last ID number is input, the Honda ● pushing the power switch when the SMART Key indicator goes off, and when it Honda SMART Key indicator comes on.
Page 187 • Press and hold the power switch until the ID number input failure Honda SMART Key indicator to turn off. After the last ID number is input, the Honda SMART Key indicator flash at 1 second Except ED,II ED type The buzzer also rings at this time.
Page 188: Tyre Puncture
Tyre Puncture WARNING Repairing a puncture or removing a wheel requires special tools and technical expertise. Riding your vehicle with a temporary We recommend you have this type of service tyre repair can be risky. If the temporary performed by your authorised dealer. repair fails, you can crash and be After an emergency repair, always have the seriously injured or killed.
Page 189: Smartphone Pairing Trouble
Smartphone Pairing Trouble Symptom Cause/remedy Some smartphones you use may be incompatible with the vehicle and/or the operable functions may be limited. Check that the vehicle and smartphone are both in pairing mode. P. 106 Check your surroundings to make sure no other device being paired is present before re-pairing.
Page 190 Smartphone Pairing Trouble Symptom Cause/remedy Depending on the smartphone you use, it may take some time for the vehicle to connect to a smartphone and to start using a dedicated application. The connection may be temporarily disconnected when activating the motor, which is normal and not a malfunction. The smartphone will be reconnected after the motor is activated.
Page 191: Electrical Trouble
Electrical Trouble 12 V Battery Goes Dead Burned-out Light Bulb Charge the 12 V battery using a motorcycle All light bulbs on the vehicle are LEDs. If battery charger. there is an LED which is not turned on, see Remove the 12 V battery from the vehicle your authorised dealer for servicing.
Page 192: Blown Fuse
Electrical Trouble Blown Fuse Blown Fuse Remove the battery lid from the step floor. P. 156 Pull the fuses out with the fuse puller in Before handling fuses, see “Inspecting and back side of battery lid one by one check Replacing Fuses.”...
Page 193: Information
Information Keys..............P. 190 Instruments, Controls, & Other Features... P. 195 Caring for Your Vehicle........P. 202 Storing Your Vehicle........P. 205 Transporting Your Vehicle ......P. 206 You & the Environment ......... P. 207 Serial Numbers ..........P. 208...
Page 194: Keys
Do not store the emergency key in any ● compartment. The ID number of the Honda SMART Key is on the ID tag. You can also unlock the power switch by inputting the ID number. Always carry both the emergency key and ID tag, but separate from the Honda SMART Key, to avoid losing all of them at the same time.
Page 195 Keys The Honda SMART Key contains electronic If fuel, wax, or grease adhere to the Honda ● circuits. If the circuits are damaged, the Honda SMART Key, wipe it off immediately to avoid SMART Key will not allow you to perform any cracking or warping.
Page 196 Keys To get an additional Honda SMART Key, take ED,II ED type the Honda SMART Key and the vehicle to your authorised dealer. Honda SMART Key ID tag Except ED,II ED type Honda SMART Key ID tag...
Page 197 Keys EU Directive Thailand only This Honda SMART Key system complies with the RE (Radio Equipment) Directive (2014/53/ EU). The declaration of conformity to RE Directive is provided to the owner at the time of purchase. The declaration of conformity should be kept at a safe place.
Page 198 Keys UK only...
Page 199: Instruments, Controls, & Other Features
Instruments, Controls, & Other Features Instruments, Controls, & Document Bag Other Features The owner’s manual, registration, and insurance information can be stored in the plastic Power Switch document bag stored in the luggage box. P. 136 Keeping the power switch at (On) while the batteries for motor removed causes the 12 V battery to die.
Page 200 Instruments, Controls, & Other Features Automatic Brightness Control The backlight brightness of the meter will be controlled automatically when "AUTO" is selected on the brightness setting. Ambient brightness is detected by the photosensor. Do not damage or cover the photosensor. Otherwise, the automatic brightness control may not work properly.
Page 201 The full text of the EU declaration of conformity is available at the following internet address: http://www.alpine.com/e/research/doc/ Importer information Honda Motor Europe Ltd. Cain Road, Bracknell, Berkshire, RG 12 1 HL, United Kingdom The following information shall also be included in the case of radio equipment intentionally emitting radio waves: a.
Page 202 The full text of the EU declaration of conformity is available at the following internet address: http://www.alpine.com/e/research/doc/ Importer information Honda Motor Europe Ltd – Aalst Office Wijngaardveld 1(Noord V) 9300 Aalst Belgium [EN] Hereby, ALPS ALPINE CO., LTD. declares that the radio equipment type AH00EV is in compliance with Directive 2014/53/EU.
Page 203 Instruments, Controls, & Other Features [DK] Hermed erklærer ALPS ALPINE CO., LTD., at radioudstyrstypen AH00EV er i overensstemmelse med direktiv 2014/53/EU. Danish EU-overensstemmelseserklæringens fulde tekst kan findes på følgende internetadresse: http://www.alpine.com/e/research/doc/ [EE] Käesolevaga deklareerib ALPS ALPINE CO., LTD. et käesolev raadioseadme tüüp AH00EV vastab direktiivi 2014/53/EL nõuetele. Estonian ELi vastavusdeklaratsiooni täielik tekst on kättesaadav järgmisel internetiaadressil: http://www.alpine.com/e/research/doc/...
Page 204 Instruments, Controls, & Other Features [MT] B'dan, ALPS ALPINE CO., LTD., niddikjara li dan it-tip ta' tag mir tar-radju AH00EV huwa konformi mad-Direttiva 2014/53/UE. Maltese It-test kollu tad-dikjarazzjoni ta' konformità tal-UE huwa disponibbli f'dan l-indirizz tal-Internet li ej: http://www.alpine.com/e/research/doc/ [NL] Hierbij verklaar ik, ALPS ALPINE CO., LTD., dat het type radioapparatuur AH00EV conform is met Richtlijn 2014/53/EU.
Page 205 Instruments, Controls, & Other Features Thailand only...
Page 206: Caring For Your Vehicle
Frequent cleaning and polishing is important to Clean the headlight lens, panels, and ensure the life of your Honda. A clean vehicle other plastic components with extra care makes it easier to spot potential problems.
Page 207 Caring for Your Vehicle Apply a coat of wax to prevent corrosion. Washing Precautions Avoid products that contain harsh Follow these guidelines when washing: detergents or chemical solvents. These Do not use high-pressure washers: ● can damage the metal, paint, and plastic High-pressure water cleaners can on your vehicle.
Page 208: Aluminium Components
Caring for Your Vehicle Do not direct water near the headlight: Aluminium Components ● The headlight's inside lens may fog Aluminium will corrode from contact with dirt, temporarily after washing or while riding mud, or road salt. Clean aluminium parts in the rain.
Page 209: Storing Your Vehicle
Storing Your Vehicle Storing Your Vehicle When you store your vehicle, check the battery for motor gauge once a month. If it If you store your vehicle outdoors, you should goes down to 10 %, charge your vehicle until consider using a full-body cover. it gets to 30 %.
Page 210: Transporting Your Vehicle
Transporting Your Vehicle Transporting Your Vehicle Remove the 12 V battery ( P. 156) to ● prevent discharge. Fully charge the 12 V If your vehicle needs to be transported, it battery and then place it in a shaded, well- should be carried on a motorcycle trailer or a ventilated area.
Page 211: You & The Environment
You & the Environment You & the Environment Recycle Wastes Put oil and other toxic wastes in approved Owning and riding a vehicle can be enjoyable, containers and take them to a recycling centre. but you must do your part to protect the Call your local or state office of public works or environment.
Page 212: Serial Numbers
Serial Numbers Serial Numbers Except ED,II ED type The frame and motor serial numbers uniquely identify your vehicle and are required in order to register your vehicle. They may also be required when ordering replacement parts. You should record these numbers and keep them in a safe place.
Page 213: Specifications
Specifications Main Components ■ ED, II ED type Total 9 kg (20 lb) ED, II ED, PH 1,970 mm (77.6 in) type Front box 1.0 kg (2.2 lb) Overall length Maximum luggage TH, II TH, II V Luggage hook 1.5 kg (3.3 lb) 1,893 mm (74.5 in) weight type...
Page 214 200 kPa (2.00 kgf/cm , 29 psi) Tyre air pressure Rear 225 kPa (2.25 kgf/cm , 33 psi) Recommended brake Honda DOT 3 or DOT 4 Brake Fluid fluid 0.14 L (0.15 US qt, 0.12 After draining Imp qt) Transmission oil capacity After 0.16 L (0.17 US qt, 0.14...
Page 215 Thailand only HELMET CAUTION LABEL...
Page 216 Online Owner’s Manual https://www.hondamotopub.com/ 32K3NA00 XXX.XXXX.XX.S 00X32-K3N-A000 PRINTED IN XXXXX...

This manual is also suitable for:

Evp4

Honda CUV e 2025 Owner's Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Honda CUV e 2025

Summary of Contents for Honda CUV e 2025

This manual is also suitable for:

Table of Contents
