- Page 1 NEON_NTU: Turbidity Temperature Hand-held field Turbidity meter for measuring and recording Turbidity (NTU), Turbidity (NTU), Turbidity (mg/l) and temperature values. Operation Manual Version 0.1...
- Page 2 NEON_NTU_Turbidity_Temperature - 2 -...
- Page 3 NOTE: The information contained in this document may be part of patents or patent applications by Aqualabo. Having this document in your possession does not grant any license to these patents. This manual is regularly updated. Updates are included in new issues.
-
Page 4: Table Of Contents
4.2 General description of the product ________________________________________________________ 9 4.3 Main functions of the NEON Turbidity meter. _______________________________________________ 9 5. Specifications ___________________________________________________________________ 10 5.1 NEON NTU assembly data ______________________________________________________________ 10 5.2 Description of NEON housing ____________________________________________________________ 10 5.3 NTU sensor description ________________________________________________________________ 12 6. - Page 5 NEON_NTU_Turbidity_Temperature 6.3.5.5 Language __________________________________________________________________________________ 27 6.3.5.6 Factory configuration ________________________________________________________________________ 28 7. Unloading data __________________________________________________________________ 29 7.1 Activation and connection ______________________________________________________________ 29 7.2 Home screen _________________________________________________________________________ 29 7.3 Logout ______________________________________________________________________________ 30 8. ntu sensor maintenance ___________________________________________________________ 31 8.1 Cleaning _____________________________________________________________________________ 31 8.2 Storage _____________________________________________________________________________ 31 9.
-
Page 6: Warranty
The following are formally excluded, by express agreement, from our warranty: any economic harm, including staff costs, loss of profits, business disruption, etc. The customer is informed that AQUALABO may not, under any circumstances, be held liable for any errors or "bugs" that the software may contain. -
Page 7: Information
If the device is not used immediately, it should be stored in a clean, dry place. Observe storage temperatures ((10 - 35°C). AQUALABO equipment is carefully inspected before packaging. Upon receipt of your device, check the condition of the packaging and if you notice an anomaly, make your reservations known to the carrier within 48 hours. Review the packing list next to check that everything is in order. -
Page 8: Safety
➢ The device must be protected, at all times, from the following influences: - Intensive exposure to light and heat - Vapours that are caustic or have high solvent content. ➢ All operations on the inside the device must be carried out by AQUALABO or by technicians authorized by AQUALABO. 3.4 PACKAGING The NEON_NTU Turbidity meter is shipped in packaging designed to protect it during transport. -
Page 9: Neon_Ntu Turbidity Meter Overview
Turbidity mg/l. 4.3 MAIN FUNCTIONS OF THE NEON TURBIDITY METER. The NEON NTU sensor unit dedicated to Turbidity and temperature measurements offers the following features: Automatic recognition of the NTU sensor; Simultaneous display of 3 parameters (between Temperature, Turbidity NTU, Turbidity FNU, Turbidity in mg/l);... -
Page 10: Specifications
NEON_NTU_Turbidity_Temperature 5. SPECIFICATIONS 5.1 NEON NTU ASSEMBLY DATA NEON_NTU data 5 to 4000 NTU in 5 ranges: 0 to 4500 mg/L ▪ 5 – 50 NTU Calibration: ▪ 5 – 200 NTU Range 0-500 mg/L according to Measurement ranges ▪... - Page 11 NEON_NTU_Turbidity_Temperature ➢ Description of the front panel: ABS housing LCD display Navigation keypad Sensor cable gland ➢ Description of the rear panel: Waterproof battery compartment Locked by a screw (stainless steel 304, M2.5x6) Product information label including the serial number - 11 -...
-
Page 12: Ntu Sensor Description
NEON_NTU_Turbidity_Temperature 5.3 NTU SENSOR DESCRIPTION The turbidity measurement according to DIN EN ISO 7027 is a tried and tested method for monitoring waters with low to strong turbidity. The measuring principle of the NTU turbidity sensor is based on an infrared light measurement according to the 90°... - Page 13 NEON_NTU_Turbidity_Temperature Data matrix Serial number CE marking (Contains serial number) - 13 -...
-
Page 14: Getting Started
NEON_NTU_Turbidity_Temperature 6. GETTING STARTED 6.1 POWER SUPPLY 6.1.1 T YPE OF BATTERIES PERMITTED The measuring unit comes with 3 AA alkaline batteries. The user must never mix different types of batteries. Three AA NiMH batteries, 1.2 V (VARTA type) may be used but the battery life of the NEON will be reduced. 6.1.2 C HANGING THE BATTERIES The 3 used alkaline AA batteries must be replaced in a thoroughly clean, dry room so as not to contaminate the... -
Page 15: Setting
NEON_NTU_Turbidity_Temperature 6.3 SETTING 6.3.1 M AIN SCREEN You can view the following in real time on the main screen: - variables measured by the NTU sensor and related units: Temperature (°C), Turbidity (NTU), Turbidity (FNU), Turbidity (mg/l) and Temperature. A ZOOM function shows a parameter in larger format. - A series of icons (at the bottom of the screen) monitor the battery charge status, measurement stability, data recording and activation of WiFi for data transfer to a PC. -
Page 16: General Menu
NEON_NTU_Turbidity_Temperature 6.3.2 G ENERAL MENU The "GENERAL MENU" screen provides access to calibration, recording as well as preference settings (date/time configuration, NEON hand-held device and sensor information, standby delay configuration, language selection, and settings RESET feature). CALIBRATION RECORDING PREFERENCES Move the cursor with the up and down arrows to access the desired menu and confirm the selection with the "OK" key. -
Page 17: Turbidity Main Parameter
NEON_NTU_Turbidity_Temperature 6.3.3.1 T URBIDITY MAIN PARAMETER You can calibrate the conductivity parameter via this menu. Calibration can be performed on 4 ranges [0-50 NTU, 0- 200 NTU, 0-1000 NTU and 0-4000 NTU). Each range can be calibrated independently of each other. Select the range to be calibrated beforehand by moving the cursor to the relevant line (displayed in white). - Page 18 NEON_NTU_Turbidity_Temperature Calibration of the 0-1000 NTU range: Step 2 with a buffer solution. To calibrate the 0-1000 NTU range, repeat the previous steps Step 1 Offset with sensor in distilled water and Step 2 (slope) with a 500 NTU Formazine solution. For the preparation of solutions, take a 200 ml bottle.
-
Page 19: Turbidity In Mg/L
NEON_NTU_Turbidity_Temperature For this measurement range, the acceptance tolerances are: +/- 5 NTU for offset and +/- 30% for slope. Confirm the second calibration step using the OK key. Calibration of the 0.0-200.0 NTU range: Step 2 with a buffer solution. To calibrate the 0-200 NTU range, repeat the previous steps: Step 1 Offset with sensor in distilled water and Step 2 (slope) with a 100 NTU Formazine solution. - Page 20 NEON_NTU_Turbidity_Temperature Offset Calibration: Place the NTU sensor, clean and dry (see cleaning section of the NTU sensor Chapter 8.1), in an opaque container containing distilled water to simulate a 0 mg/l. As soon as the measurement stabilizes at 0 mg/l, validate the calibration step with the OK button. Calibration condition Measure of Temperature Measurement Actual turbidity (mg/l)
- Page 21 NEON_NTU_Turbidity_Temperature Use the up/down arrows to scroll through letters/numbers and the right arrow to change the cursor position. To validate the name of your file, select OK. Step 3: upon receipt of the laboratory measurement result, select again the Turbidity in mg/L calibration menu and enter the DRY WEIGHT menu.
-
Page 22: Factory Coefficients
NEON_NTU_Turbidity_Temperature 6.3.3.3 F ACTORY COEFFICIENTS In the event of mishandling during calibration or to check sensor operation, factory calibration coefficients can be used to restore the sensor to its original coefficients. FACTORY COEFF OK key to confirm To validate the setting the factory coefficients in the sensor, confirm with the OK key then press Escape (ESC) to return to the previous screen. -
Page 23: Recording Menu
NEON_NTU_Turbidity_Temperature 6.3.4 R ECORDING MENU This menu allows you to view the data stored in the NEON hand-held device, set the recording frequency, set the file names, and delete recorded data. Note: Please note that the activation of the recording function has an impact on the life of your batteries. Remember to stop recording data before turning off your NEON To select an option, use the up/down arrows and confirm with the OK key. -
Page 24: Recording Frequency
NEON_NTU_Turbidity_Temperature 6.3.4.2 R ECORDING FREQUENCY This menu helps you to set a recording frequency for the Auto Recording mode. The NEON hand-held device can record 30,000 pieces of data in 2 modes: Mode 1: Instant recording. In this case, the user can trigger a single recording by pressing the OK key. The measurement frequency is then set to 0 seconds, Mode 2: Automatic recording (with manual start). -
Page 25: Erasing Data
NEON_NTU_Turbidity_Temperature 6.3.4.4 E RASING DATA To clear all data stored in the NEON hand-held device press the OK key. The writing changes to green and the message “Data erased” appears. CLEAR DATA OK key to confirm To return to the previous screen press Escape (ESC). - 25 -... -
Page 26: Preferences Menu
NEON_NTU_Turbidity_Temperature 6.3.5 P REFERENCES MENU The PREFERENCES menu allows you to configure the date and time of the NEON hardware (useful for the timestamp of the stored data), to view information on the software/electronic versions of the NEON hand-held device and associated sensor, to set the standby mode timeout and then to completely turn off the screen, choose the language and return to the initial hardware configuration. -
Page 27: Sensor
NEON_NTU_Turbidity_Temperature 6.3.5.3 S ENSOR This window shows information about the sensor connected to the NEON housing: its description, serial number, PCB version and software version. SENSOR Sensor description SN-LLLLL-NNNN Sensor Serial No. (e.g. SN-PNEPB-2226) VERSION: NN.NN Electronic version RE VERSION: NN.NN Software version ➢... -
Page 28: Factory Configuration
This action will reset the factory configuration for: Backlight intensity level, standby time-out (2 min), measurement campaign name (LOCAL) and English language. To exit this screen press Escape (ESC). ➢ GX SERVICE: For AQUALABO service ➢ AW SERVICE: For AQUALABO service ➢ PW SERVICE: For AQUALABO service... -
Page 29: Unloading Data
NEON_NTU_Turbidity_Temperature 7. UNLOADING DATA 7.1 ACTIVATION AND CONNECTION Note: Please note that the activation of the WIFI function has an impact on the life of your batteries. To activate the connection to NEON’s on-board web page and retrieve the stored data, enter the overview menu for data stored on the NEON hand-held device: GENERAL MENU>>... -
Page 30: Logout
NEON_NTU_Turbidity_Temperature To activate the data download, click on the “DOWNLOAD CSV” tab. The record file contains: the data measured by the sensor (pH, ORP, & temperature), the temperature and humidity inside the NEON hand-held device. 7.3 LOGOUT To disconnect the NEON device from the computer, click “EXIT” tab. The WiFi icon at the bottom of the “results”... -
Page 31: Ntu Sensor Maintenance
NEON_NTU_Turbidity_Temperature 8. NTU SENSOR MAINTENANCE The maintenance schedule indicates minimum intervals for regular maintenance tasks. Perform more frequent maintenance tasks for applications that cause fouling of the sensor head and optics. 8.1 CLEANING • The sensor should always be kept clean, especially in the area around optical windows. Deposits on the optical windows can cause measurement errors.
