Table of Contents

User Manual
RTKA223011DR0040BU
Demonstration Board
The RTKA223011DR0040BU demonstration board is a high voltage buck converter that demonstrates a low-cost
high performance non-isolated AC/DC conversion from a universal input of 85V
~ 265V
to a 24V output with
AC
AC
output current up to 200mA.
The board has built-in overcurrent, short-circuit, input brownout, and over-temperature protections.
RTKA223011DR0040BU comes with a RAA223011 in TSOT23-5 package.
Key Features
▪ Universal input
▪ Standby power less than 13mW
▪ No audible noise
▪ Low cost external components
Specifications
This board is optimized for the following operating conditions:
▪ Input voltage: 85V
~ 265V
AC
AC
▪ Output voltage: 24V
DC
▪ Output current: 200mA max (at 230V
or higher)
AC
▪ Efficiency: >74% at 100% load; 82% at 50% load
▪ No-load power: 11.3mW at 120V
; 12.4mW at 230V
AC
AC
▪ Load regulation: -2.3%, load range 10% to 100%
▪ Operating temperature: -45°C ~ 70°C
▪ Board dimension: 29mm x 52mm
Ordering Information
Part Number
Description
RTKA223011DR0040BU
RAA223011 TSOT23-5 demonstration board
Related Literature
For a full list of related documents, visit our website:
▪
RAA223011
device page
X0119323 Rev.1.0
Page 1
Feb 11, 2021
© 2021 Renesas Electronics
