Carton Contents
• Amplifier unit
• Mains power cable
• Input connector x 1 or 2
• GPIO socket connector
Connections
DIP
GPIO
MAINTENANCE
3
4
1
2
5
6
7
8
DIP Switch Functions
OFF ↓
SWITCH
Channel 1 in Low-Z mode
1
2
Channel 2 in Low-Z mode
Channel 3 in Low-Z mode*
3
Channel 4 in Low-Z mode*
4
70V Hi-Z mode
5
(for channels in Hi-Z mode)
Input ganging 1: All
6
GPIO standby polarity NO
7
(Normally Open)
Front panel control
8
locked.
* Not applicable to two channel amplifiers.
Installation Notes
• Ensure that rack or other confined installation does not
restrict the airflow required for safe and reliable operation of
the equipment. It is important to ensure that the 40°C maximum
operating temperature for the equipment is not exceeded.
• Amplifiers will not switch on from standby mode unless an input
signal is present or the standby switch is toggled.
QUICK START GUIDE
POWER AMPLIFIERS
PowerZone 252 • PowerZone 504 • PowerZone 1004
• Output connector x 1 or 2
• Adhesive rubber feet x 4
• Document pack
• Rack Ears (PowerZone 1004)
Input
Output
Channel 1 & 2
Channel 1
INPUT
CH1
CH2
CH4
CH3
Input
Output
Channel 3 & 4
Channel 3
ON ↑
Channel 1 in Hi-Z mode
Channel 2 in Hi-Z mode
Channel 3 in Hi-Z mode*
Channel 4 in Hi-Z mode*
100V Hi-Z mode
(for channels in Hi-Z mode)
Input ganging 1:1
GPIO standby polarity NC
(Normally Closed)
Front panel control
unlocked.
Support
• A full user manual that includes information
on installation, mounting accessories and
amplifier operation is available online. Go to
www.blaze-audio.com or scan the QR code.
Output
Channel 2
OUTPUT
CH1
CH2
CLASS 2
WIRING
CLASS 2
WIRING
CH3
CH4
Output
Channel 4
GPIO Functions
• Volume control
Connect Wiper:
to VC34 for Channel 3 & 4
or VC12 for Channel 1 & 2
1
2
3
4
5
• Standby control
and fault indication
1
AC MAINS
~
100 - 240 VAC
50 - 60Hz / 150W
Potentiometer
(>10kΩ)
INPUT
6
7
8
CH1
CH3
Switch open or closed toggles standby
depending on poition of DIP switch 7.
+3V3 = operational
0V = fault
2
3
4
5
6
7
8
CH1
CH3
CH2
CH4
INPUT
CH2
CH4
