- Page 1 Instruction Manual USER MANUAL ROOFER KITS RK5PTB50, RK050V50, RK110V50 and RK5PTB25 Meets or exceeds applicable standards Rev. Oct . 2024...
-
Page 2: Table Of Contents
Warning Page 3 1. Limitations for Use Page 4 2. Anchorage Requirements Page 4 3. Connection Compatibility Limitations Page 5 4. Fall Clearance/Clear Fall Charts Page 5-6 5. Donning Page 7 6. Training Page 7 7. Inspection Page 8 8. Cleaning, Maintenance and Storage Page 8 9. -
Page 3: Warning
Never use fall protection equipment for purposes other than those for which it was designed. Environmental hazards should be considered when selecting fall protection equipment. Do not expose the equipment to any hazard which it is not designed to withstand. Consult FRONTLINE in cases of doubt. -
Page 4: Limitations For Use
1.Limitations for Use This equipment is designed to be used in temperatures ranging from -40ºF to +130ºF (-40°C to +54°C). Do not expose this equipment to chemicals or harsh solutions that may have a harmful effect. Contact FRONTLINE with any questions. -
Page 5: Connection Compatibility Limitations
3.Connection Compatibility Limitations All equipment must be coupled to compatible connectors. OSHA 29 CFR 1926.502 prohibits snap hooks from being engaged to certain objects unless two requirements are met: 1. It must be a locking type snap hook. 2. It must be “designed for” making such a connection. a. - Page 6 Using an extended free fall (12 foot) Shock Absorbing Lanyard will require a total fall clearance of approximately 20 feet (6.1 meters) when anchored at foot level and measured from the anchorage point of lanyard to the nearest obstruction below. The total fall clearance combines the sum of the length of the lanyard, free fall distance, the maximum elongation of the lanyard (5 feet or 1.5 meters), the average distance between the worker’s dorsal D-ring, (5 feet or 1.5 meters), and the safety factor (3 feet or 0.9 meters).
-
Page 7: Donning
5.Donning Sewn terminations should be secure, complete, and not visibly damaged. No load indicators shall be deployed. Note: Damaged and other deteriorated and defective components must be immediately removed from service. Fitting an Full Body Harness Follow step from 1 to 7 for wearing harness. Step 1: Hold the harness by the dorsal D-ring and shake to allow any tangled straps to fall into place. -
Page 8: Inspection
7.Inspection Frequency Full Body Harnesses must be inspected prior to each use and every 6 months by a “Competent Person” other than the user. To Inspect Webbing Bend a portion of the webbing 6-8 inches into an upside-down ‘U’ shape. Continue along all webbing inspecting for tears, cuts, fraying, abrasion, discoloration, burns, holes, mold, pulled or broken stitches, or other signs of wear and damage. -
Page 9: Labeling
9.Labeling All labeling must be legible and attached to the full body harness. -
Page 10: Annex A
Where user can find the labels. 10.Annex A Annex A – Normative Note: This information from the ANSI Z359.11 standard is required to be included in the instruction manual for the end user: ANSI/ASSE Z359 Requirements for Proper Use and Maintenance of Full Body Harnesses (note: these are general requirements and information provided by ANSI/ASSE Z359, the manufacturer of this equipment may impose more stringent restrictions on the use of the products they manufacture, see the manufacturer’s instructions.) 1. - Page 11 4. Full Body Harnesses which meet ANSI/ASSE Z359.11 are intended to be used with other components of a Personal fall Arrest system that limit maximum arrest forces to 1800 pounds (8 kn) or less. 5. Suspension intolerance, also called suspension trauma or orthostatic intolerance, is a serious condition that can be controlled with good harness design, prompt rescue and post fall suspension relief devices.
- Page 12 for fall arrest, the competent person evaluating the application should take measures to ensure that a fall can only occur feet frst. This may include limiting the allowable free fall distance. 13. Shoulder – the shoulder attachment elements shall be used as a pair, and are an acceptable attachment for rescue and entry/retrieval.
-
Page 13: Checking Card
User name Inspection Record Date Reason for entry (periodic Competent person name + Comments Next Due date for examination or repair) signature periodic examination Manufacturer: Frontline Fall Protection Inc. Web: www.frontlinefall.com 2111 NW 84 Ave, Miami, Florida 33122, U.S.A. Email info@frontlinefall.com... - Page 14 ®...
- Page 24 ®...
- Page 26 ® USER INSTRUCTIONS ROOF ANCHOR Comply with ANSI Z359.18-2017 THIS INSTRUCTIONS APPLY TO FOLLOWING MODELS: RO01 …...
- Page 27 Table of Contents WARNING ………………………………………………………………………………………………Page 3 1. Limitations for Use ………………………………………………………………………………Page 3 2. Connection Compatibility Limitations……………………………………………………Page 4 3. Performance…………………………………………………………………………………………Page 5 4. Loading Direction Limitation…………………………………………………………………Page 5 5. Installation……………………………………………………………………………………………Page 6 6. Training…………………………………………………………………………………………………Page 7 7. Inspection………………………………………………………………………………………………Page 7 8. Cleaning, Maintenance and Storage………………………………………………………Page 7 9.
-
Page 28: Warning
Do not use this equipment if you are unable to tolerate the impact of a fall arrest. Age and fitness can seriously affect your ability to withstand a fall. Consult with Frontline if in doubt. Minors, pregnant women and anyone with a history of back and/or neck problems must not use this equipment. -
Page 29: Connection Compatibility Limitations
2. Connection Compatibility Limitations All equipment must be coupled only to compatible connectors that are suitable to your application. Ensure all connections are compatible in size, shape and strength. Ensure all connectors are fully closed and locked. Prohibit the use of snap hooks to engage to objects unless the following requirements are met: It must be a locking type snap hook. -
Page 30: Performance
3. Performance The performance of equipment in accordance with the requirements of the ANSI Z359.18-2017. Model/Reference Features Min. Breaking Strength Material of Construction Standard Regulation RO01 Reusable 5000 lbs / 22.2 kN Plate Steel ANSI Z359.18-2017 When installed as an anchor point on a flat surface or on one side of a peaked roof, the connecting fall arrest subsystem must not extend over the peak of the roof to the other side. -
Page 31: Installation
5. Installation Roof Ridge No more than 8’ of spacing between roof anchors installed on Roof Ridges Hip Face At least one roof anchor on each Hip Face Roof Edge No less than 6’ from an exposed Roof Edge When multiple roof anchors are installed, the strength (static load) above must be met at each roof anchor’s installation point independently. -
Page 32: Training
6. Training Employers are responsible for providing training to any employee who may be exposed to fall hazards in order to enable the employee to recognize and reduce fall hazards. Training must be conducted by a Competent or Qualified Person. Trainer and trainees must not be exposed to fall hazards during the training course. -
Page 33: Labeling
Date of first use Inspection Log Date Reason for entry (periodic Competent person name + Comments Next Due date for examination or repair) signature periodic examination Manufacture: Frontline Fall Protection Inc. 2111 NW 84 Ave, Miami, Florida 33122, U.S.A. www.frontlinefall.com Website: info@frontlinefall.com Email:...
