CHAMPION LED
UK
Installation instructions
DE
Montageanleitung
CZ
Montážní návod
DK
Monteringsvejledning
EE
Paigaldusjuhend
The luminaire with clear optic should be
positioned so that prolonged staring into
the luminaire at a distance <2m is not expected
CLASS I
1
96403687 03
FI
Asennusohje
FR
Notice de montage
HU
Szerelési útmutató
IT
Istruzioni di montaggio
LT
Montavimo Instrukcijos
Caution, risk of electric shock
Danger, risque de chocs électriques
LED
IP66
IK08
707
LV
Instalacijas instrukcija
NO
Monteringsanvisning
PL
Instrukcja montazu
SE
Installationsanvisning
RU
C
Gear box ALG5
LE 1400W [xxx]
IP66
A
B
IK08
ta -40°
500
152
ta +45°
17
2,5
792
SC
0,196 m
2
x
22,1 kg
C
(kg)
77
5.4
T25
T20
12/2024
Advertisement
Related Manuals for Thorn CHAMPION LED
Summary of Contents for Thorn CHAMPION LED
- Page 1 CHAMPION LED Installation instructions Asennusohje Instalacijas instrukcija Montageanleitung Notice de montage Monteringsanvisning Montážní návod Szerelési útmutató Instrukcja montazu Monteringsvejledning Istruzioni di montaggio Installationsanvisning Paigaldusjuhend Montavimo Instrukcijos The luminaire with clear optic should be Caution, risk of electric shock positioned so that prolonged staring into Danger, risque de chocs électriques...
- Page 2 PRODUCT FIXATION For installation higher >3m Secure product with retaining cable attached to the fork 3xØ22 1xM20 with extra large washer (not provided) 2xM14 with extra large washer (not provided) 2xØ15 96403687 03 12/2024...
-
Page 3: Product Opening
CABLE Recommended H07RN-F 5G1,5 mm² Outdoor compliant PRODUCT OPENING 9-10mm 2,5 Nm Ø min = 1,0 mm Ø max = 1,5 mm Ø6-12 mm 2,5 Nm 96403687 03 12/2024... - Page 4 GEAR BOX ELECTRICAL CONNECTION - DALI 8-9 mm INPUT OUTPUT Floodlight Ø min = 1,0 mm² Ø typ = 1,5 mm² Ventilation Valve CONTROL Ø max = 2,5 mm² 30 / 36 PINOUT Flood Gear Box Description AC INPUT AC INPUT L2 second Line or Neutral L2 / N L1 L2 PE PE 24V DA+ DA-...
- Page 5 GEAR BOX ELECTRICAL CONNECTION - DALI DALI In & Out(Optional) L1 L2 PE PE 24V DA+ DA- V2+ V2- V1+ V1- φ ：5-6.5 mm 2*0.08-1mm² DALI In Wrong Direction DALI Out DALI2 DALI 96403687 03 12/2024...
- Page 6 GEAR BOX ELECTRICAL CONNECTION - RDM-DMX 8-9 mm INPUT OUTPUT Floodlight Ø min = 1,0 mm² Ø typ = 1,5 mm² Ø max = 2,5 mm² CONTROL Ventilation Valve 30 / 36 PINOUT Gear Box Flood Description L1 L2 PE PE 24V DA+ DA- NTC V2+ V2- V1+ V1- AC INPUT AC INPUT L2 second Line or Neutral...
- Page 7 GEAR BOX ELECTRICAL CONNECTION - RDM-DMX « DMX-RDM wiring shall respect ANSI E1.11 and AINSI E1.20 installation rules». DMX is a three-wire system, use all three! DMX is based on RS-485 standard. Always use cable designed for DMX / RS-485 installations Max : 32 GB per line –...
- Page 8 GEAR BOX 5 Nm Plug 1Nm Optional cable 3.5 Nm 5 Nm In case of non-dimming control application, the dimming (DALI or RDM/DMX) gland is still required for water-proof. Fixing centres: 96403687 03 12/2024...
- Page 9 80mm 80mm 80mm Tc reference hotspot To measure ambient temperature inside the cabinet it has to be done between 2 gear boxes 80mm It is highly recommended to select a painted cabinet enclosure with high reflectance ratio to protect from solar radiant energy Position Side 96403687 03...
- Page 10 SETTING 0° V2 (0°) 0° -5° V1 (-5°) 0° +5° V3 (+5°) 0° 96403687 03 12/2024...
- Page 11 Versorgungsspannung abzuschalten. -Jede Änderung an dieser Leuchte ist verboten. Thorn Lighting is constantly developing and improving its products. The right is reserved to change specifications without prior notification or public announcement. © Thorn Lighting 96403687 03...
