INSTALLATION LEAFLET RAZE BOLLARD
UK
DE
CZ
DK
EE
RAZE BOLLARD (RAB)
T30 creux / Hollow
24
LED
63420247 PB
FI
Asennusohje
FR
HU
IT
LT
RAZE
RAW
RAB 400
RAB 700
RAB 700
HF/R or HFX/R
RAB 900
RAB 900
HF/R or HFX/R
CLASS I
CLASS II
LV
NO
PL
SE
RU
RAZE WALL MOUNTED (RAW)
BOLLARD
H
2,770
4,790
400
6,490
700
7,420
7,620
900
8,550
T25
IK10
IP66
03/2019
Advertisement
Related Manuals for Thorn RAZE BOLLARD Series
Summary of Contents for Thorn RAZE BOLLARD Series
- Page 1 INSTALLATION LEAFLET RAZE BOLLARD Asennusohje RAZE BOLLARD (RAB) RAZE WALL MOUNTED (RAW) BOLLARD RAZE 2,770 RAB 400 4,790 RAB 700 6,490 RAB 700 7,420 HF/R or HFX/R RAB 900 7,620 RAB 900 8,550 HF/R or HFX/R T30 creux / Hollow CLASS I CLASS II IK10...
- Page 2 RAZE WALL MOUNTED (RAW) Ø28 Clic ! 3,6 Nm 3,6 Nm RAZE BOLLARD (RAB) ALL VERSIONS 300 mm (x4) 3,6 Nm Clic ! Ø8 Recommended connector (x4) 3,6 Nm 3,6 Nm 3,6 Nm Drainage 63420247 PB 03/2019...
- Page 3 RAZE BOLLARD (RAB) HF/R or HFX/R 1 Nm 300 mm (x6) (x6) LED+(HV) LED- LED2+(LV) NTC Sig NTC COM DA/N DA/L 3 Nm 3,6 Nm 230V AC Clic ! 3,6 Nm 3,6 Nm 200m MAX 20m MAX MASTER 13 x SLAVE MAX MASTER (only CL1) 63420247 PB...
- Page 4 ALL VERSIONS VERSIONS HF / HFX CABLES for RAB or RAW Recommended connectors H07RN-F (HF CL2 version) 2x1 or 2x1.5mm² Ø8 - 12mm HF CL2 H07RN-F Male TECHNO:THB.387.A2A 2x1mm² or 2x1,5mm² Female TECHNO:THB.387.A2B 35mm H07RN-F (HF CL1 or MAS CL2 or SLA/LRT CL2 version) HF CL1 or MAS CL2 or SLA/LRT CL2 3G1 or 3x1 or 3x1,5 / 3G1.5mm²...
