- Page 1 Induction cookers Installation and operating manual * 599A5BQ00 - 82.8235.01- 2021.12 *Original instructions...
- Page 2 Foreword Read the following instructions, including the warranty terms before installing and using the appliance. Visit our website www.electroluxprofessional.com and open the Support section to: Register your product Get hints & tips of your product, service and repair information The installation, use and maintenance manual (hereinafter Manual) provides the user with information necessary for correct and safe use of the appliance.
-
Page 3: Table Of Contents
Contents A WARNING AND SAFETY INFORMATION....................5 General information ........................5 Personal protection equipment ......................6 General safety ..........................6 Induction general safety ......................... 7 Protection devices installed on the appliance ..................8 Safety signs to be placed on the appliance or near its area ..............8 Reasonably foreseeable improper use .................... - Page 4 OPERATING INSTRUCTIONS ....................... 23 Use of induction cookers ......................23 Induction plate main components ....................23 Glass display ..........................23 Temperature control ........................24 First use ........................... 24 Switching on/off.......................... 24 Using the heating zones....................... 24 Choice of pots..........................24 Main switch (optional) ........................
-
Page 5: Awarning And Safety Information
WARNING AND SAFETY INFORMATION General information To ensure safe use of the appliance and a proper understanding of the manual it is necessary to be familiar with the terms and typographical conventions used in the documentation. The following symbols are used in the manual to indicate and identify the various types of hazards: WARNING Danger for the health and safety of operators. -
Page 6: Personal Protection Equipment
Personal protection equipment Summary table of the Personal Protection Equipment (PPE) to be used during the various stages of the appliance's service life. Stage Protective Safety Gloves Glasses Safety garments footwear helmet ● ○ ○ — — Transport — ● ●... -
Page 7: Induction General Safety
Disconnect the appliance from the power supply before carrying out any installation, assembly, cleaning or maintenance procedure. • Do not remove, tamper with or make illegible the marking and safety, danger and instruction signs and labels on the appliance. • The A-weighted emission sound pressure level does not exceed 70 dB(A). •... -
Page 8: Protection Devices Installed On The Appliance
• At the end of cooking always switch off the cooking zones. • It is advisable to use pots specially designed for this induction appliance (refer to I.8 Choice of pots), otherwise the appliance may malfunction or become damaged. • To guarantee continuous operation at maximum power, the room temperature must be below 40℃. -
Page 9: Residual Risks
risks for the safety of operators and damage to the appliance are not allowed. Reasonably foreseeable improper use includes: • lack of appliance maintenance, cleaning and periodical checks; • structural changes or modifications to the operating logic; • tampering with the guards or safety devices; •... -
Page 10: Transport, Handling And Storage
Residual risk Description of hazardous situation Chemical Contact with chemical substances (e.g. detergent, rinse aid, scale remover, etc.) without taking adequate safety precautions. Therefore always refer to the safety cards and labels on the products used. Sudden closing of the door/ The operator for normal appliance use could drawers (if present, depending on suddenly and deliberately close (if present,... -
Page 11: Positioning
Preventive Maintenance In order to ensure the safety and performance of your equipment, it is recommended that service is undertaken by Electrolux Professional authorised engineers every 12 months, in accordance with Electrolux Professional Service Manuals. Please contact your local Electrolux Professional Service Centre for further details. -
Page 12: Appliance Maintenance
– improper or poor: installation, repair, maintenance accordance with Electrolux Professional user and mainte- (including tampering, modifications and repairs carried out nance documentation made available in paper or electronic by third parties not authorized) and modification of safety format. -
Page 13: Ctechnical Data
See the data plate located in the lower right corner to identify the appliance (see fig. below). Electrolux Professional AG - Allmendstrasse 28, CH - 6210 Sursee MW freq... -
Page 14: How To Interpret The Factory Description
Manufacturer Electrolux Professional SpA or any other Testing and inspection service centre authorised by Electrolux Our appliances have been designed and optimized, with Professional SpA. -
Page 15: Responsibility
Protection safety measures consisting of the use of Disposal of packing devices specific technical means (guards and The packing must be disposed of in compliance with the safety devices) for protecting operators current regulations in the country where the appliance is used. against risks. -
Page 16: Handling
Handling Note • The forwarder is responsible for the goods during transport Arrange a suitable area with flat floor for appliance unloading and delivery. and storage operations. • Make a complaint to the forwarder in case of visible or E.2.1 Procedures for handling operations hidden damage. -
Page 17: Accessing The Appliance's Internal Components
Accessing the appliance’s internal components Access to the main power supply INSTALLATION AND ASSEMBLY NOTE! Introduction For information regarding the electrical connection, WARNING refer to “A.11 Electrical connection“. Refer to “Warning and safety Appliance type information“. To ensure correct operation of the appliance and maintain safe conditions during use, carefully follow the instructions given below in this section. -
Page 18: Distances / Walls
Distances / walls (F Installation diagrams). The appliance should be connected to fixed cables. The appliance must not be installed on flammable walls. If an appliance is set up next to or against temperature-sensitive Installation options: furniture or similar, keep a safety-distance of approximately 50 1. -
Page 19: Fastening Multiple Appliances Together
Attaching the unit with screws Attaching the unit by welding The feet have metal plates which may be secured to the floor The metal plate underneath the feet must be welded to the using screws . floor with a continuous weld around the outer edge. Fastening multiple appliances together Remove lower panel A by undoing the screws. -
Page 20: Side Panels And Base Models
Side panels and base models All side panels are available in two different versions: • Side panel with an overhang of 12,5 mm for individual • Side cover without overhang to mount on covered sides. mounting on walls. Mount the faceplates onto the unit cladding when setting up. The faceplates suitable for your type of installation are available as optional accessories. -
Page 21: Fixing The Side Panels
Fixing the side panels G.9.1 Panels with a 12,5 mm overhang Attach connecting rails B and C with the supplied Bring the side panel D into position. screws A. Make sure marking on part B on the rail is Put the 5 hooks of the panel F into the slots E. pointing forwards. -
Page 22: Side Cover Without Overhang
G.9.2 Side cover without overhang The side cover should only be used as a closing off against the wall, against a niche and in between appliances (provided that these have the same dimensions). Standard cover has pre-cuts that you can adapt to the appliances according to the left/right side. Fit the 4 cage nuts A into the dedicated slots on the Attach connecting rails C and D with the supplied frame. -
Page 23: Helectrical Installation
ELECTRICAL INSTALLATION WARNING WARNING Refer to “Warning and safety If the power cable is damaged, it information“. must be replaced by the Cus- tomer Care Service or in any Mains connection case by specialised personnel, Each appliance has a specific wiring diagram. It contains the in order to prevent any risk. -
Page 24: Temperature Control
When the pan is removed, the cooking zone automatically goes into stand-by. Induction cookers have coils for each heating zone, which are switched on/off individually using pot-detection technology. Each coil has a sensor which switches off the appliance if it overheats. -
Page 25: Main Switch (Optional)
NOTE! Use wok pots suggested by Electrolux Professio- nal in order to obtain max performances of your appliance. For further details please contact Electrolux Professional. -
Page 26: Stainless Steel Surfaces
WARNING These do not constitute damage and can be removed by following the instructions given in the paragraph J.3 Stainless When using chemicals, comply steel surfaces. with the safety notes and dosage Ceramic — glass surfaces recommendations printed on the •... -
Page 27: Kmaintenance And Customer Service
MAINTENANCE AND CUSTOMER SERVICE WARNING Periods of non-use Refer to “Warning and safety If the appliance is not going to be used for some time, take the following precautions: information“. • close the water supply tap(s), if present; • disconnect the power supply or remove the plug from the Informations for maintenance power socket, if present;... -
Page 28: Troubleshooting
• If overheating persists, the cooking zone is temporarily • It is advisable to turn the zone off with the control knob and turned off. wait a while. • Cooling is quicker if the pot is taken off the glass-ceramic When cooled, the cooking zone can be switched on again by plate. -
Page 29: Mappliance Disposal
Use a pot of suitable size Pot bottom less than 12 cm wide Switch off the appliance, cool down and Over temperature No heating of cooking zone check if the filters are dirty Use a pot made from appropriate Material of pot unsuitable material APPLIANCE DISPOSAL WARNING... - Page 32 Electrolux Professional AG Allmendstrasse 28 CH - 6210 Sursee www.electroluxprofessional.com...
