- Page 1 SOLAR-POWERED MOTOR PACKAGES KIT XQBPZ616 (6 Nm) KIT XQBPZ1012 (10 Nm) KIT XSBPZ2012 (20 Nm) KIT XQBPZ2016 (20 Nm) KIT XQBPZ309 (30 Nm) KIT XQBPLZ1012 SOLAR STATION (10 Nm) KIT XSBPLZ2012 SOLAR STATION (20 Nm) KIT XQBPLZ2016 SOLAR STATION (20 Nm)
- Page 2 SAFETY GENERAL BATTERY SAFETY MAINTENANCE INSTALLATION COMMISSIONING REPLACING A SOLAR PANEL PROGRAMMING TRANSMITTER ADDING TRANSMITTER CHECKING/CHANGING DIRECTION ERASING TRANSMITTER RESET MOTOR MEMORY LIMIT SWITCH SETUP INTERMEDIATE POSITION...
- Page 3 SAFETY CAREFULLY FOLLOW THESE INSTRUCTIONS. IT IS VERY IMPORTANT FOR THE SAFETY OF PERSONS. SAVE THESE INSTRUCTIONS. IMPORTANT: • Check the shutter/awning in motion and keep persons far from it while in action. • Frequently check if any loss of balance, signs of wear or damaged wires are shown. • Do not use if any repairing or maintenance is needed. • In case of installation in awnings keep a distance of at least 0,4 m from it (completely open) and whatever fixed item in the nearby. • The device is not intended to be used by people (including children) whose physical, sensory or mental capabilities are reduced, or lacking experience or knowledge, unless they have been granted through the intermediary of a person responsible for their safety, supervision or instruction concerning the use of the device. • Children should be supervised to ensure they do not play with the device and / or with fix control devices. • The control devices installed in a fixed manner must be positioned in view. ATTENTION: Damaged electric products and batteries should not be disposed of with normal household waste.
- Page 4 GENERAL 1.1 FIELD OF APPLICATION The XQ solar motor is designed for roller shutters and textile sun protection. The motor has to be installed in accordance with the standards of the country: the installation of the motor in the roller shutter must comply the EN 13659. 1.2 POWER SUPPLY The XQ AUTONOMO is a motor working with solar energy.
-
Page 5: Battery Safety
BATTERY SAFETY • Do not dismantle, open or shred secondary cells or batteries. • Do not expose cells or batteries to heat or fireAvoid storage in di- rect sunlight. • Do not short-circuit a cell or a battery. • Do not subject cells or batteries to mechanical shock. • In the event of a cell leaking, do not allow the liquid to come in contact with the skin or eyesIf contact has been made, wash the affected area with copious amounts of water and seek medical advice. • Do not use any charger other than that specifically provided for use with the package. • Observe the plus (+) and minus (–) marks on the cell, battery and equipment and ensure correct use. • Do not use any cell or battery which is not designed for use with the equipment. • Battery usage by children should be supervised. • Always purchase the battery recommended by GAPOSA for the specific XQ AUTONOMO package. • Keep cells and batteries clean and dry. • Secondary cells and batteries need to be charged before useAl- ways use the correct charger and refer to the manufacturer’s in- structions or equipment manual for proper charging instructions. • Do not leave a battery on prolonged charge when not in use. • After extended periods of storage, it may be necessary to charge and discharge the cells or batteries several times to obtain maxi- mum performance. • Keep the original product literature for future reference. • Use only the cell or battery in the application for which it was in- tended. • Dispose of properly. • Do not use a different battery charger than the one listed among the optionals. • Do not exceed the maximum charging time of 3.5 hours. -
Page 6: Maintenance
MAINTENANCE The service life of the XQ AUTONOMO solar motor is between 3 and 5 years. If the roller shutter/roller screen doesn’t run properly and the mo- tor does not return to normal operation after a sunny period, there has probably been a major discharge from the battery. The battery is required to be charged using a NI-MH battery charger, by a pro- fessional installer. Do not use a different battery charger than the ones supplied by GAPOSA. If this occurs again and after 3 years, the battery needs to be repla- ced by a professional installer. -
Page 7: Installation
INSTALLATION ASSEMBLY • Only operate the motor in a horizontal position for its intended use. • If necessary, screw the star head adaptor on the motor head to conform the motor bracket and insert the crown and drive adap- tors to match the inner profile of the rolling tube then insert the motor assembly into the tube. • Secure the idler on the other side of the tube to prevent axial mo- vement using a screw or a rivet. • Do not drill holes on the rolling tube along the motor area WIRING • Keep 20 cm as minimum distance between 2 solar motors and 30 cm distance between motors and transmitters • Cables which pass through a metal wall must be protected and insulated using a sheath or sleeve • The motor cable cannot be removed. If damaged return the motor to the after sale service • All the cables of the XQ AUTONOMO package are with connectors for a quick and easy plug of the entire system. • The cable and connectors must be protected from the roller shut- ter movement. • It is recommended to properly fix the cables inside the roller shutter box. Better if the connectors are placed behind the metal wall end. ATTENTION: • Any RF device at 434.15 MHz can interfere with a solar motor reducing the RF performances (Hi-FI, radio, headphones) • Always make a loop in the power supply cable to prevent water entering into the motor! • Do not cut wires of the pre wired cables. - Page 8 WIRING KIT XQ/XS BPZ Standard Configuration BNH22/24 SPM18/30 Motor Optional Configurations with FLAXTWCC connector BNH22/24 2x SPM18/30 Motor FLAZTWCC BNH22/24 SPM18/30 Motor BC15NH FLAZTWCC Optional Configuration with BNH22/24 charging kit with magnetic connectors FLAXMC-NI SPM18/30 Motor BC15NH FLAZMC-NI KIT XQ/XS BPLZ SPB18 Motor...
-
Page 9: Solar Panel Installation
INSTALLATION SOLAR PANEL INSTALLATION The solar panel (C) should be always placed on the shutter housing to be as much exposed as possible to the sun’s rays. Its position is critical and helps significantly the future autonomy of the solar motor system. The solar panel(s), is sized to fit in all shutter boxes and to constantly charge battery for the daily movements. - Page 10 INSTALLATION (SPM18/30) OPTIMAL PLACEMENT IN CASE OF OBSTACLES Limited sight on the sky Roof overhang or similar coverings L < 2 x H Moving the panel to the building front or another wall Obstacle in front of the solar panel H <...
- Page 11 INSTALLATION (SPM18/30) The panel can be fixed on the surface by using the 3M double tape or, for an absolute fixing solution, 2 pop rivets: 1. Drill 1 hole with diameter 15 mm (B) and 2 holes with diameter 5 mm (A) on the front of the casing, as per the diagram opposite.
- Page 12 INSTALLATION (SPB18) The SPB18 Solar station can be fixed to the wall using screws and dowels included in the kit. or in any other surface by using 2 screws max diam. 4,5mm. The SPB18 Solar station in a standard installation is naturally oriented at 25°...
- Page 13 COMMISSIONING IMPORTANT: CHARGE THE BATTERY/SOLAR STATION BEFORE THE INSTALLATION. ONLY USE THE BATTERY CHARGER SUITABLE FOR THE TYPE OF BATTERY. SOLAR MOTOR KIT version: Connect the battery and then the solar panel to the motor cables. SOLAR MOTOR KIT WITH SOLAR STATION version: Connect the solar station to the motor cable.
- Page 14 REPLACING A SOLAR PANEL A solar panel must be replaced by a professional installer, and only with an identical model. Never throw out the solar panel with domestic waste. SPM18 solar panel: 1. Disconnect the motor cable from the battery. 2.
-
Page 15: Programming Transmitter
PROGRAMMING PROGRAMMING TRANSMITTER CAUTION: If more motors with receiver have to be installed, it is important to power up only one motor at time during the first programming session, in order to avoid any interferences with others. Power up the motor to be programmed. - Page 16 PROGRAMMING ADDING TRANSMITTER Press and Hold the PROG-TX but- ton of a transmitter already pai- red until the motor starts moving. Check the rotation of the motor, then release the PROG-TX button (the motor stops). Within 5 seconds press the cor- responding button (i.e.
- Page 17 PROGRAMMING CHECKING/CHANGING DIRECTION IMPORTANT: change direction must be performed before starting limit setting otherwise limits must be reset. Press UP or DOWN the motor should go UP or DOWN, otherwise to change direction: Press and hold the PROG-TX button until the motor starts moving Press STOP: The motor makes a brief jog.
- Page 18 OPTION 2 - Without an already programmed transmitter Switch the motor power supply OFF. Then switch it Within 8 seconds, using any Gaposa transmitter, press and hold both the PROG-TX and STOP buttons until the motor makes a long jog.
-
Page 19: Limit Switch Setup
LIMIT SWITCH LIMIT SWITCH SETUP (Just for motors with electronic limit switch) ATTENTION: ALWAYS SET THE UP LIMIT FIRST Push the PROG-FC button until the motor makes a brief jog. Note: during “programming mode” the operations are in “deadman control” Press and hold the UP button and run the motor to the desired UP limit position. -
Page 20: Setting The Limits
SETTING THE LIMITS INDIVIDUALLY If the limits need to be changed after the initial limit setting procedure, it is possible to change the limit positions individually. One limit can be set without the other limit needing to be set. The motor can be in any postion to initiate the procedure. - Page 21 SETTING THE LIMITS INDIVIDUALLY TO CHANGE THE DOWN LIMIT: From any point between the existing limits, press and hold both the PROG-FC button and the DOWN button until the motor makes a breif jog. Press and hold the DOWN botton until the desired new DOWN limit is reached.
-
Page 22: Intermediate Position
3 seconds. 3” ERASING THE INTERMEDIATE POSITION Press simultaneously, both the UP and DOWN buttons until the motor makes a brief movement in both directions. GAPOSA srl - via Ete, 90 63900 Fermo - Italy T. +39.0734.220701 - info@gaposa.com...
