Sealey LED100PTR Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
instructions
1. SAFETY
1.1. GENERAL SAFETY
Ensure the light is fully charged before initial use.
9
DO NOT turn the light on when it is being charged.
8
DO NOT shine directly into your, another person's or an animal's eyes.
8
DO NOT allow children to use the light.
8
DO NOT handle or move the light whilst it is being charged.
8
DO NOT use the light if you suspect that the battery or the light casing is damaged.
8
DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery, subsequently
8
recharge the battery at least once every six months of non-use.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or fire:
‰
DO NOT attempt to open, disassemble, modify or service the battery pack.
8
DO NOT crush, puncture, short external contacts or dispose of in fire or water.
8
DO NOT expose to temperatures above 60°C (140°F).
8
Recycle or dispose of used battery as stipulated by local regulation.
9
If the electrolyte in the cells gets on your skin, thoroughly wash with soap and water. If it gets in your eyes, rinse thoroughly with cool
9
water and seek immediate medical attention.
2. INTRODUCTION
Bright 1W SMD LED light produces 100 lumens to illuminate dark recesses. Light extends to give an extra 34cm of reach and bends in any
direction and holds it position wherever you need it. Features a magnetic ring on the end of the light for picking up nuts, bolts and small parts
up to 1.2kg. Features a rubber covered magnet on the end, along with a belt clip for hands-free operation. 3.7V 180mAh lithium-ion battery for
longer life, no memory effect and a much slower discharge than traditional Ni-MH batteries.
3. SPECIFICATION
Model No: .......................................................... LED100PTR
Battery: .......................................... 3.7V 180mAh Lithium-ion
Charging time:................................................................2.5hr
LED Type: .............................................................. SMD LED
Lumen Output: ........................................High/Low: 100/30lm
Weight: ........................................................................ 0.09kg
Operating Time: ............................................ High/Low: 2/6hr
4. OPERATION
CHARGING
4.1.
Connect a USB lead to the port on the end, near the torch's light.
4.2. On/off switch light pulses green whilst on charge. Solid green denotes full charge.
4.3. CHARGE STATE
On/off switch displays charge state when light is turned on and off: green ok/orange requires charging/red no charge.
4.4. OPERATION
Press On/off once for low power, again for full power, once more for off.
Extend segmented section and position light using flexible section.
Base has a magnet as does ring around the light.
© Jack Sealey Limited
TELESCOPIC FLEXI RECHARGEABLE
MAGNETIC PICK-UP TOOL LIGHT 1W SMD LED
LED100PTR
MODEL NO:
Original Language Version
LED100PTR Issue 1 13/11/24
