T 758
®
AV Surround Sound Receiver
Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T758 V3i and is the answer not in the manual?

Questions and answers

Summary of Contents for NAD T758 V3i

  • Page 1 T 758 ® AV Surround Sound Receiver Owner’s Manual...
  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS FOR LATER USE. NOTE TO CATV SYSTEM INSTALLER FOLLOW ALL WARNINGS AND INSTRUCTIONS MARKED ON THE AUDIO This reminder is provided to call the CATV system installer’ s attention to Section 820-40 of EQUIPMENT. the NEC which provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.
  • Page 3 Left and Right Panels: 10 cm Rear Panel: 10 cm Top Panel: 10 cm NAD is a trademark of NAD Electronics International, a division of Lenbrook Industries Limited Copyright 2017, NAD Electronics International, a division of Lenbrook Industries Limited...
  • Page 4: Table Of Contents

    NAD SHALL NOT BE HELD LIABLE FOR ANY TECHNICAL OR USER INTERFACE DISCREPANCIES IN THIS MANUAL. THE T 758 OWNER’S MANUAL MAY BE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE. CHECK OUT THE NAD WEBSITE FOR THE LATEST VERSION OF THE T 758 OWNER’S MANUAL.
  • Page 5: Introduction

    INTRODUCTION GETTING STARTED WHAT’S IN THE BOX Packed with your T 758 you will find • Quick Setup Guide • BluOS Kit containing USB Hub, Wi-Fi Dongle, Bluetooth USB Micro Adapter and USB to USB Cable Extender • AVR 4 remote control with 2 AA batteries •...
  • Page 6: Identification Of Controls

    IDENTIFICATION OF CONTROLS FRONT PANEL AV Surround Sound Receiver T 758 © NAD T 758 1 STANDBY BUTTON Toggle [ENTER] button to switch between “Tune” and “Preset” mode. • Press this button to switch ON the T 758 from standby mode. The Select “Preset”...
  • Page 7 IDENTIFICATION OF CONTROLS FRONT PANEL 6 VACUUM FLUORESCENT DISPLAY (VFD) 11 FRONT INPUT PORTS • Displays visual information about the current settings like the • Use these convenience jacks for occasional sources such as a active Source, volume level, listening mode, audio format and other camcorder, video game console, any analog audio or optical digital related indicators.
  • Page 8: Rear Panel

    ZONE 2/HT 1/HT 2 DIGITAL AUDIO IN © NAD T 758 ATTENTION! Please make sure that the T 758 is powered off or unplugged from the mains power source before making any connections. It is also advisable to power down or unplug all associated components while making or breaking any signal or AC power connections.
  • Page 9: Ac Mains Input

    All NAD products with IR IN/IR OUT features are fully compatible Connect the HDMI OUT to a HDTV or projector with HDMI input. with the T 758. For non-NAD models, please check with your other HDMI OUT supports 4K@60 4:4:4 and HDCP 2.2 compliant.
  • Page 10: Avr 4 Remote Control

    NOTE The remote control handset supplied with the T 758 is of a universal NAD type, designed to operate several NAD models. Some buttons are applicable only to specific NAD models. Contact your dealer or NAD audio specialist for assistance.
  • Page 11: Sleep Mode

    Increase or decrease loudness level. Release the button when desired level is reached. • The VFD on the front panel will indicate the level set. For NAD Receivers, the VFD will also show “Volume Up” or “Volume Down” or “Volume: _ _ dB” (_ _ indicates the numerical dB level) while pressing AVR 4’s [VOL 5/6 ] buttons.
  • Page 12 Tuner models; check the owner’s manual of your NAD Receiver or Tuner for control button compatibility. You can also load the applicable NAD code library to this device so that it can be made compatible with your other NAD equipment. Refer to the section below about “LIBRARY” on how to load a NAD code library.
  • Page 13: Library

    Default library for “AMP” page Zone 2 2 SOURCE [ d/f ]: Select the active input of the NAD T 758 that will be sent out to the corresponding rear panel ZONE 2 output port. C 515BEE, C 545BEE, C 565BEE T 535, T 585, M55;...
  • Page 14: Alternate Ir Channel

    SAMPLE SETUP OF TWO NAD PRODUCTS ON THE SAME ZONE NAD T 758 and NAD C 326BEE are both defaulted to IR Channel 0. If [OFF] button is pressed on the AVR 4 remote control (or SR 8 remote control for the C 326BEE), both products will go to standby mode.
  • Page 15: Operation

    OPERATION USING THE T 758 - MAIN MENU ABOUT THE ON-SCREEN DISPLAY (OSD) DSP OPTIONS The T 758 employs a simple, self-explanatory system of on-screen display “menus” that will appear on the connected video monitor/TV. These are required during the setup process (and are useful in day-to-day operation), so be sure to connect the monitor/TV before proceeding with the setup.
  • Page 16: Zone Controls

    OPERATION USING THE T 758 - MAIN MENU ZONE CONTROLS • On the other hand, the secondary Zone 2 at AUDIO PRE-OUT (item “AUDIO PRE-OUT/SURR-B/FRONT-HT/ZONE 2” in the “IDENTIFICATION OF CONTROLS – REAR PANEL” section) also sends zone selected audio source to the corresponding audio input of a separately located additional amplifier or receiver (not supplied) that can power its matching set of speakers.
  • Page 17: Using The T 758 - Setup Menu

    OPERATION USING THE T 758 – SETUP MENU SETUP MENU CONTROL SETUP The Setup Menu allows one to customize the operation of the T 758 to the ancillary The T 758 supports HDMI Control (CEC) and Audio Return Channel (ARC) equipment used in one’...
  • Page 18: Important Notes

    OPERATION USING THE T 758 – SETUP MENU SOURCE SETUP When devices that support HDMI Control (CEC) are connected, the following modes of operation can be executed via the T 758 or the external device using any of the device’s remote control. Off: Applies to all CEC options below.
  • Page 19: Analog Audio

    OPERATION USING THE T 758 – SETUP MENU ANALOG AUDIO VIDEO INPUT The T 758 has six analog audio inputs including 7.1 input. These analog All three HDMI sources can be assigned as video input to a particular Source. inputs - Stereo 1, Stereo 2, Stereo 3, Stereo Front, Media Player (Front) and Another option is “Off”...
  • Page 20: Speaker Setup

    All the speakers’ low frequency content can be directly adjusted within the range 40Hz to 200Hz. IMPORTANT! Dirac Live and NAD Speaker IQ features are still being finalized and NOTE will eventually be added in future firmware Internet upgrade. The configurations set forth at “Speaker Setup” are carried over whenever it is enabled during A/V Presets setting.
  • Page 21: Speaker Distance

    OPERATION USING THE T 758 – SETUP MENU ADJUSTING THE VOLUME SETTING SPEAKER LEVELS AT TEST MODE While at “Speaker Levels” menu, press the AVR 4 remote’s [TEST] key activating the T 758’s Speaker Levels balancing test signal. You will hear a “surf”...
  • Page 22: Zone 2 Setup

    OPERATION USING THE T 758 – SETUP MENU ZONE 2 SETUP TRIGGER SETUP The Zone 2 feature allows one to simultaneously experience in a different zone of the house selected audio from any of the enabled Sources as well as from Front Input and Media Player. The T 758 features a configurable +12V TRIGGER OUT that can be used to activate a component or system it is fed into.
  • Page 23: Listening Mode Setup

    OPERATION USING THE T 758 – SETUP MENU LISTENING MODE SETUP The Digital Theater System Digital Surround (simply called DTS) is a multi- channel digital signal format that can process higher data rates than with Dolby Digital. Although both Dolby Digital and DTS are 5.1 channel media formats, discs bearing the “DTS”...
  • Page 24: Listening Modes

    Two-channel recordings, whether stereo or surround-encoded, are recording or program material. With a two-channel (Stereo) source, the reproduced with proprietary NAD surround processing with signal output following listening modes can be selected. to the front left/right, center and discrete left/right surround channels, plus subwoofer (assuming these are present in the current “Speaker...
  • Page 25: Dolby Setup

    OPERATION USING THE T 758 – SETUP MENU DOLBY SETUP DTS SETUP Dynamic Range Control: You can select the effective dynamic range Under this menu, the Dynamic Range Control of DTS Digital Surround can (subjective range from soft to loud) for playback of Dolby Digital be adjusted as well as the settings for DTS Neo: 6 Music.
  • Page 26: Front Panel Display Setup

    Details shown include the video resolution with frame rate. For a better number, scroll down to “Save Current Setup to Preset” and press the [ S ] understanding of these video details, consult with your NAD Audio key. If you chose to load instead the default settings, scroll down to “Load Specialist or your distributor’s technical department.
  • Page 27: Recalling Presets

    OPERATION USING THE T 758 – SETUP MENU SAMPLE PROCEDURE FOR SETTING UP A/V PRESETS 6 At “A/V Presets” page, set “Preset: 2” to the following conditions - use 1 Setup first your preferred settings for the following options (access [ D/F ] to select “Yes”...
  • Page 28: Bluos Setup

    Mac desktops. Launch the BluOS Controller App and explore everything from your streaming BluOS is a music management software developed by NAD’s sister brand, music services, internet radio stations, networked music collections and Bluesound. BluOS adds BluOS network and internet music streaming with favorites with quick and easy single-search discovery.
  • Page 29: Reference

    REFERENCE TROUBLESHOOTING CONDITION POSSIBLE CAUSES POSSIBLE SOLUTIONS No sound from all channels . • AC power unplugged. • Check AC cable connection and outlet. • Power not switched on. • Outlet has no power. • Mute function is activated. • Toggle [MUTE] button to deactivate Mute function.
  • Page 30: Specifications

    REFERENCE SPECIFICATIONS GENERAL SPECIFICATIONS Power output Stereo Mode 110W (8 ohms within rated distortion) IHF dynamic power; 8 ohms 137W IHF dynamic power; 4 ohms 243W Power output Surround Mode 7 x 60W Total harmonic distortion at rated power <0.08% IM distortion at rated power <0.08% Damping factor, 8 ohms...
  • Page 32 All rights reserved. NAD and the NAD logo are trademarks of NAD Electronics International, a division of Lenbrook Industries Limited. No part of this publication may be reproduced, stored or transmitted in any form without the written permission of NAD Electronics International.
