Service Manual
The picture in this service manual is only for reference, and specific appearance
and configuration are subject to the real product.
This manual mainly teaches the method, the specific work skill needs engineer to
accumulate through the daily work.
There are special components used in this equipment which are important for safety. These parts are marked
by
in the Schematic Diagrams, Circuit Board Diagrams, Exploded Views and Replacement Parts List. It is
essential that these critical parts should be replaced with manufacturer's specified parts to prevent shock, fire
or other hazards. Do not modify the original design without permission of manufacturer.
Applicable Models
HS-125W2EN
Important Safety Notice
Service Manual_2018-V2.0
Wine Cooler SERIES
Model Code
Applicable Models
UR-JC96GE-FR
22033010001021
WARNING
1
Advertisement
Table of Contents
Related Manuals for Midea HS-125W2EN
Summary of Contents for Midea HS-125W2EN
- Page 1 Service Manual Wine Cooler SERIES Applicable Models Model Code Applicable Models HS-125W2EN UR-JC96GE-FR 22033010001021 The picture in this service manual is only for reference, and specific appearance and configuration are subject to the real product. This manual mainly teaches the method, the specific work skill needs engineer to accumulate through the daily work.
- Page 2 Manufacturers or distributors are not responsible for the content of the Manual and interpretation thereof. Midea Refrigerators Technical Maintenance Manual Copyright @2017 All rights reserved. Replication of all or part of the Manual in any forms shall not be allowed without written approval by the Overseas Sales Corporation of Midea Refrigerators.
-
Page 3: Table Of Contents
Service Manual_2018-V2.0 Contents SIGNIFICANT UPDATE NOTES(NONE) ......................5 2. SAFETY WARNING CODE ............................6 ........................... 6 2.1 W ARNING FOR OPERATION SAFETY 2.2 S ......................... 8 AFETY INSTRUCTION FOR REFRIGERANT 3. TRANSPORT ................................9 3.1 H ................................... 9 ANDLING 4. INSTALLATION AND COMMISSIONING ......................10 4.1D ) ...................... - Page 4 Service Manual_2018-V2.0 ............................26 10.2T EMPERATURE CONTROL 10.3F ..........................27 AULT CODE AND SOLUTIONS 10.4 D ............................28 EFROSTING FUNCTION (NONE) ......................28 10.5B ACKUP DATA FOR POWER FAILN 11. COMPRESSOR ..............................29 ..................29 11.1C OMPRESSOR ON AND OFF ONTROL SPECIFICATIONS 12.
-
Page 5: Significant Update Notes(None)
Service Manual_2018-V2.0 1. Significant update notes(None) -
Page 6: Safety Warning Code
Service Manual_2018-V2.0 2. Safety Warning Code 2.1 Warning for operation safety Important Safety Instructions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN This symbol indicates that dangerous voltage constituting a risk of electric shock is present within your freezer. This symbol indicates that there are important operating and maintenance instructions in the literature accompanying your freezer. -
Page 7: Connecting Electricity
Service Manual_2018-V2.0 CONNECTING ELECTRICITY Electrical Shock Hazard. Failure to follow these instructions can Plug into a grounded 3-prong outlet. result in death, fire, or electrical shock. Do not remove the ground prong. Do not use an adapter. WARNING Electric Shock Hazard Failure to follow these instructions can result in electric shock, fire, or death. -
Page 8: Grounding Requirement
Service Manual_2018-V2.0 12) This freezer is intended to be used in household and similar environments. 13) Do not store or use gasoline or any flammable liquids inside or in the vicinity of this freezer. 14) Do not use extension cords or ungrounded (two-prong) adapters with this freezer. If the power cord is too short, have a qualified electrician install an outlet near the freezer. -
Page 9: Transport
Service Manual_2018-V2.0 3. Transport 3.1 Handling Handling 1)Protect the refrigerator in moving it,Same as shown as lef t photo, please move it by handcart with cushion 2)Remove all packing materials and bottom cushion, the m ove into house for placement 3)After moving it to appropriate location, wait for 2 hours bef ore power on. -
Page 10: Installation And Commissioning
Service Manual_2018-V2.0 4. Installation and commissioning 4.1Door Disassembly and Assembly (None) The refrigerator door needs to be dismantled if it cannot enter the room in the whole. Disassembly of Freezer door Disassembly of Freezer door None Disassembly of refrigerator door Disassembly of refrigerator door None 4.2 Installation location... -
Page 11: Left Or Right Open Door Reversal（None
Service Manual_2018-V2.0 4.4 Left or right open door reversal（None） 4.5 Installation of handle（None） 4.6 Installation of door lock（None）... -
Page 12: Product Configuration And Dimension
(The picture is only for reference, and specific appearance and configuration are subject to the real product) Freezer chamber Refrigerator chamber 1. glass door 2.Wine shelf 3. Temperature Knob 4.Adjustable foot 5.2 External dimension HS-125W2EN Description Code Size (mm) Height to Top of Case Width Depth w/Cabinet Depth w/Door Depth w/Handle Depth (Door open 90 deg. - Page 13 Service Manual_2018-V2.0 (The picture is only for reference)
-
Page 14: Location Of S/N
Service Manual_2018-V2.0 5.3 Location of S/N Some products also have S/N on the lower part of the right side of the Cabinet. -
Page 15: Product Specification
Service Manual_2018-V2.0 6. Product specification 6.1 Electrical parameters Applicable Models HS-125W2EN UR-JC96GE-FR Product Name Product Code 22033010001021 Item Specification Refrigerant R600a FZ35C1M Compressor QP2-4R7 Starter(PTC) DRB18T61A1 Overload protector(OLP) Integrate PTC+OLP None Capacitor None Power filter None Rmc：13.7±7%Ω Winding resistance of compressor wiring Rsc：13±7%Ω... -
Page 16: Circuit Diagram
Service Manual_2018-V2.0 6.3 Circuit diagram... -
Page 17: Refrigerating Piping System And Circulating Route Of Cooling Air
Service Manual_2018-V2.0 7.Refrigerating piping system and circulating route of cooling air 7.1 Refrigerating piping system ❶Compressor→❷Whole condeser→❸Dry filter tube→❹Capillary tube→❺Evaporator→❻Suction tube→❶Compressor 7.2 Special soldering position (NONE) -
Page 18: Dismantling Of Parts
Service Manual_2018-V2.0 8. Dismantling of parts 8.1 Parts on the door Door seal Door seal is installed into door liner groove. 1） Open the wine cabinet door; 2) Take the door seal ①out of door liner. 8.2Parts inside the refrigerator wine rack 1）Lift up the division plate with a proper force and pull it out towards yourself;... -
Page 19: Compressor Case
Service Manual_2018-V2.0 1) Take down the screw on lampshade, Push the lampshade inner and take it down2) Take down the screw on LED light plate then push out the light. Light switch None 8.4 Compressor case Rear cover None Compressor and the cooling system pipe 1）... - Page 20 Service Manual_2018-V2.0 4-1）Remove the screws(for some models) -Two screws outside -One screw inside 4-2）Remove the metal clamp(for some models) -Disassembly the metal clamp that is fix the electric appliance shield 5）Remove the clipping strip Slowly pull it out 6）Remove the protective cover -Pry the protective cover slowly from the upper part, -Pull it out and remove it.
- Page 21 Service Manual_2018-V2.0 8）Loosen the screw of the compressor bottom plate, remove the floor together with the compressor from the box. 9）Use the wrench to remove the bolts by steps❹❺❻❼, replace the compressor and reverse process can complete installation. 10）Use Pipe cutter cut off the condenser tube❽, then Shear off capillary ❾...
- Page 22 Service Manual_2018-V2.0 12）Replace the filter, Cu-Fe tubes welding ⓭ used Ag welding rod, Cu-Cu tubes welding ⓮ used Cu welding rod. 13）Vacuum system,The degree of vacuum below 6Pa. 14）Perfusion refrigerant. 15）Use the vise grip pliers clamp the middle of the process pipe, then seal welding process tube⓯⓰.
- Page 23 Service Manual_2018-V2.0 ❼ Condenser-1(in) ❽drain tray ❾Temperature board box Drain tray 1）Pull out the drain tray 2）Replace the drain tray, the reverse process can complete installation.
-
Page 24: Display Control Board (None)
Service Manual_2018-V2.0 8.5 Display control board (NONE) Display control board None 8.6 Main control board Main control board Take down screws Take out main control panel cover Disconnect the fast connector Take screws on main control panel... -
Page 25: Temperature Sensing System
Service Manual_2018-V2.0 9. temperature sensing system 9.1Sensor in refrigerating chamber Evaporator in refrigerating chamber 1）To remove the sensor cover, you may squeeze it up and down.. 2）Take the sensor out from card slot.. -
Page 26: Function And Operation
Service Manual_2018-V2.0 10. Function and operation 10.1 Operation panel Buttun LED Display area (Locked) Temperature reduction key Temperature rise key 10.2Temperature control has three display modes: store demonstration mode, user's us UR-JC96GE-FR ual bright mode, user's energy saving mode; Mall demonstration mode: long press "lighting button A"... -
Page 27: Fault Code And Solutions
Service Manual_2018-V2.0 when the screen did not light up, have the keystrokes display normal lighting, display lighting rear can effectively key operation; Has a fault code "visible" class fault occurs, the display light, display screen into the locked state, circulation flashing shows fault code (mall demo mode can not display the fault code), trouble-free displayed when set temperature for the cooling compartment Lock and unlock... -
Page 28: Defrosting Function
Service Manual_2018-V2.0 10.4 Defrosting function The defrosting of evaporator is activated when the temperature monitored by defrosting sensor is below setted point., compressor switching off,following the temperature rise, the frost on evaporator becomes water, and the water flow into the evaporating pan via the draining system, the water in evaporating pan evaporate away finally. -
Page 29: Compressor
Service Manual_2018-V2.0 11. Compressor 11.1Compressor on and off Control specifications 1.1 When one of the following conditions is met, the compressor stops: 1) Tr ≤ Trt； 2) The compressor runs continuously for more than 3 hours (Stop 5 minutes); 1.2 When all the following conditions are met, the compressor starts up: 1) Tr ≥Trk;... -
Page 30: Troubleshooting Method
Service Manual_2018-V2.0 12. Troubleshooting Method 12.1Not cooling... -
Page 31: No Working Of Compressor
Service Manual_2018-V2.0 12.2 No working of compressor 12.3 Inside frosting, no defrosting... -
Page 32: Inside Frosting, No Defrosting-Maintenance Guidelines
Service Manual_2018-V2.0 12.4 Inside frosting, no defrosting-Maintenance guidelines... -
Page 33: Light Is Not On
Service Manual_2018-V2.0 12.5 Light is not on 12.6 Noise... -
Page 34: Figures And Details Of Repair Parts
Service Manual_2018-V2.0 13. Figures and details of repair parts See this section in the TSP. - Page 35 MIDEA appliances after sales website tsp.midea.com For more information about Midea appliances after sales, please visit the tsp.midea.com For more information about the service manual, please visit the tsp.midea.com For more information about the EV and SBOM, please visit the...
