Service Manual_2018-V2.0
Service Manual
Wine Cooler SERIES
Applicable Models
Model Code
Applicable Models
HS-104WEN
UR-JC80GE-DQ
22033010001481
The picture in this service manual is only for reference, and specific appearance
and configuration are subject to the real product.
This manual mainly teaches the method, the specific work skill needs engineer to
accumulate through the daily work.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Midea UR-JC80GE-DQ
Summary of Contents for Midea UR-JC80GE-DQ
- Page 1 Applicable Models Model Code Applicable Models HS-104WEN UR-JC80GE-DQ 22033010001481 The picture in this service manual is only for reference, and specific appearance and configuration are subject to the real product. This manual mainly teaches the method, the specific work skill needs engineer to...
- Page 2 Manufacturers or distributors are not responsible for the content of the Manual and interpretation thereof. Midea Refrigerators Technical Maintenance Manual Copyright @2017 All rights reserved. Replication of all or part of the Manual in any forms shall not be allowed without written approval by the Overseas Sales Corporation of Midea Refrigerators.
-
Page 3: Table Of Contents
Service Manual_2018-V2.0 Contents SIGNIFICANT UPDATE NOTES (NONE) ......................5 2. SAFETY WARNING CODE ............................6 2.1 W ........................... 6 ARNING FOR OPERATION SAFETY ......................... 8 2.2 S AFETY INSTRUCTION FOR REFRIGERANT 3. TRANSPORT ................................9 3.1 H ................................... 9 ANDLING 4. INSTALLATION AND COMMISSIONING ......................10 4.1 D ........................ - Page 4 Service Manual_2018-V2.0 10. FUNCTION AND OPERATION .......................... 34 ..............................34 10.1 O PERATION PANEL 10.2 T ............................34 EMPERATURE CONTROL ..........................35 10.3 F AULT CODE AND SOLUTIONS ............................36 10.4 D EFROSTING FUNCTION 10.5 B (NONE) ......................36 ACKUP DATA FOR POWER FAIL 11.
-
Page 5: Significant Update Notes (None)
Service Manual_2018-V2.0 1. Significant update notes (None) -
Page 6: Safety Warning Code
Service Manual_2018-V2.0 2. Safety Warning Code 2.1 Warning for operation safety Important Safety Instructions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN This symbol indicates that dangerous voltage constituting a risk of electric shock is present within your freezer. This symbol indicates that there are important operating and maintenance instructions in the literature accompanying your freezer. - Page 7 Service Manual_2018-V2.0 CONNECTING ELECTRICITY Electrical Shock Hazard. Failure to follow these instructions can Plug into a grounded 3-prong outlet. result in death, fire, or electrical shock. Do not remove the ground prong. Do not use an adapter. WARNING Electric Shock Hazard Failure to follow these instructions can result in electric shock, fire, or death.
-
Page 8: Safety Instruction For Refrigerant
Service Manual_2018-V2.0 13) Do not store or use gasoline or any flammable liquids inside or in the vicinity of this freezer. 14) Do not use extension cords or ungrounded (two-prong) adapters with this freezer. If the power cord is too short, have a qualified electrician install an outlet near the freezer. Use of an extension cord can negatively affect the freezer’s performance. -
Page 9: Transport
Service Manual_2018-V2.0 3. Transport 3.1 Handling Handling 1)Protect the refrigerator in moving it,Same as shown as lef t photo, please move it by handcart with cushion 2)Remove all packing materials and bottom cushion, the m ove into house for placement 3)After moving it to appropriate location, wait for 2 hours bef ore power on. -
Page 10: Installation And Commissioning
Service Manual_2018-V2.0 4. Installation and commissioning 4.1 Door Disassembly and Assembly The refrigerator door needs to be dismantled, if it cannot enter the room in the whole. 4.2 Installation location Installation location Location that is easy for ventilation shall be chosen to facilitate heat dissipation, enhance its performance and reduce the energy consumption. -
Page 11: Left Or Right Open Door Reversal
Service Manual_2018-V2.0 4.4 Left or right open door reversal Door reversal (Vertical handle) 2）Dismantle the upper right hinge screw①,and remove the door body； 2）Remove the 3 screws ② of the upper right hinge, and the upper right hinge ③, remove the 3 plastic caps ④... - Page 12 Service Manual_2018-V2.0 4） Use a wrench to remove the vertical handle ⑿, remove the upper door shaft sleeve ⒀ and the shaft hole cap ⒁, remove the handle fixing shaft ⒂, remove the handle fixing shaft hole cap, the positions are interchanged; remove the door limit ⒄, screw ⒅...
-
Page 13: Installation Of Handle
Service Manual_2018-V2.0 5)Install the door, and fix the upper hinge shaft ①.Thus, the whole door is replaced. Collected unused right upper hinge③. 4.5 Installation of handle Installation of handle 1）Put the handle on glass door through the bolts. 2）Use allen wrench to fix the handle bolts,make sure the screw hole is downward. -
Page 14: Product Configuration And Dimension
Service Manual_2018-V2.0 5. Product configuration and dimension 5.1 Main parts and their names (The picture is only for reference, and specific appearance and configuration are subject to the real product) Freezer chamber Refrigerator chamber None 1. Display control panel 2.Wooden wine shelf 3. -
Page 15: External Dimension
Service Manual_2018-V2.0 5.2 External dimension HS-104WEN Description Code Size (mm) Height to Top of Case Width Depth w/Cabinet Depth w/Door Depth w/Handle Depth (Door open 90 deg. w) Depth (Door open 135 deg. w) Width (Door open 135 deg. w) (The picture is only for reference) -
Page 16: Location Of S/N
Service Manual_2018-V2.0 5.3 Location of S/N Some products also have S/N on the lower part of the right side of the Cabinet. -
Page 17: Product Specification
Service Manual_2018-V2.0 6. Product specification 6.1 Electrical parameters Applicable Models HS-104WEN Product Name UR-JC80GE-DQ Item Specification R600a Refrigerant Compressor FZ35C1M-U Starter(PTC) QP2-4R7 Overload protector(OLP) DRB18T61A1 Integrate PTC+OLP None Capacitor None Power filter None Rmc：13.7±7%Ω Winding resistance of compressor wiring Rsc：13.0±7%Ω... -
Page 18: Circuit Diagram
Service Manual_2018-V2.0 6.3 Circuit diagram... -
Page 19: Refrigerating Piping System And Circulating Route Of Cooling Air
Service Manual_2018-V2.0 7. Refrigerating piping system and circulating route of cooling air 7.1 Refrigerating piping system ❶Compressor→❷Parallel flow condenser→❸Auxiliary condenser→❹Dry filter→❺Capillary tube→❻Evaporator→❶Compressor Circulating route of cooling air... -
Page 20: Dismantling Of Parts
Service Manual_2018-V2.0 8. Dismantling of parts 8.1 Parts on the door Door seal Door seal is installed into door liner groove. 1) Open the wine door； 2) Take the door seal ①out of door liner； Door stopper 1）The door lamp switch stopper is installed in the lower part of the door. - Page 21 Service Manual_2018-V2.0 Splitter plate 2） 1) Use a Phillips screwdriver to remove the Splitter plate that located on the left and right sides of the dividers; 3） 2) Lift up the Splitter plate with a proper force and pull it out towards yourself;...
-
Page 22: Light System
Service Manual_2018-V2.0 8.3 Light system Light Light of the upper refrigerating chamber is located upper chamber. 1) Remove the wine door and two fixed screws from the main control board in refrigerator. 2) Pull out the mounting box horizontally and unplug the wiring terminal on the LED lamp;... -
Page 23: Compressor Case
Service Manual_2018-V2.0 Light of the under refrigerating chamber is is located inside the splitter plate；Remove the splitter plate， method as above. Light switch Light switch None 8.4 Compressor case Rear cover Rear cover None Compressor and the cooling system pipe 1）... - Page 24 Service Manual_2018-V2.0 3） Cut off the compressor pipeline.-❶Cut off the process pipeline.-❷Cut off the low-pressure muffler.-❸Cut off the high-pressure exhaust pipe. 4-1）Remove the screws(for some models) -Two screws outside -One screw inside 4-2）Remove the metal clamp(for some models) -Disassembly the metal clamp that is fix the electric appliance shield 5）Remove the clipping strip Slowly pull it out...
- Page 25 Service Manual_2018-V2.0 7）Remove the starter and protector Unplug the starter and protector (you can use a screwdriver to pry it slowly) 8）Loosen the screw of the compressor bottom plate, remove the floor together with the compressor from the box. 9）Use the wrench to remove the bolts by steps❹❺❻❼, replace the compressor and reverse process can complete installation.
- Page 26 Service Manual_2018-V2.0 11） Replace the compressor and welding the compressor pipeline.-❿Welding the process pipeline.-⓫Welding the low-pressure muffler.-⓬Welding the high-pressure exhaust pipe. 12）Replace the filter, Cu-Fe tubes welding ⓭ used Ag welding rod, Cu-Cu tubes welding ⓮ used Cu welding rod. 13）Vacuum system,The degree of vacuum below 6Pa.
- Page 27 Service Manual_2018-V2.0 Piping system in the compressor case Condenser-1(in) Capillary Tube Drier Main control board box Compressor cover Suction conection Pipe Compressor Drain tray Transition pipe 10 Condenser-2 (out) Drain tray 1）Pull out the drain tray...
-
Page 28: Display Control Board
Service Manual_2018-V2.0 2）Replace the drain tray, the reverse process can complete installation. 8.5 Display control board Display control board 1）Remove two screws from the refrigerating air duct with a cross screwdriver 2）Remove the wine door and two fixed screws from the main control board in refrigerator,And pull out the mounting box horizontally；... -
Page 29: Main Control Board
Service Manual_2018-V2.0 5）Remove the Display control panel. 8.6 Main control board Main control board 1） Take down screws 2） Take out main control panel cover 3） Disconnect the fast connector... - Page 30 Service Manual_2018-V2.0 4） Remove the main control panel...
-
Page 31: Temperature Sensing System
Service Manual_2018-V2.0 9. Temperature sensing system 9.1 Position of sensors Position of sensors Have 2 sensors Sensor in upper refrigerating chamber Sensor in under refrigerating chamber 9.2 Replacement of sensors Sensor in refrigerating chamber... -
Page 32: Sensor Replacement
Service Manual_2018-V2.0 Sensor in upper refrigerating chamber Before remove the sensor, the refrigerating duct assembly should be removed The sensor position is on the back of the duct cover.1） Remove the air duct assembly from the refrigerating. 2）Remove the sponge tape on the surface and remove the sensor. - Page 33 3）Take out a new sensor to cut the head of sensor. (Spare parts code：11201007000795) Its technical specifications apply to all MIDEA refrigerators. 4）Strip off the head of the sensor and connect it. 5）Wrap the two wires together with insulation tape.
-
Page 34: Function And Operation
Service Manual_2018-V2.0 10. Function and operation 10.1 Operation panel Icons Button ❻Upper and lower temperature zone control conversion ❶ Standby button ❷ Lighting button ❸ Display area ❹ Temperature increase button ❺ Temperature decrease button 10.2 Temperature control Temperature control: Once the temperature increase button is pressed, the temperature will increase by one degree(℃/℉),Once the temperature decrease button is pressed, the temperature will decrease by one degree(℃/℉). -
Page 35: Fault Code And Solutions
Service Manual_2018-V2.0 Set the upper 10℃ and lower 12℃. If you set the upper 11℃ and the lower will become 13℃(the minimum allowable temperature difference is 2℃). If you set the upper 12℃ and the lower will become 14℃ Set the upper 10℃ and lower 18℃. If you set the upper 9℃ and the lower will become 19℃(the maximal allowable temperature difference is 8℃). -
Page 36: Defrosting Function
Service Manual_2018-V2.0 10.4 Defrosting function The defrosting of evaporator is activated when the temperature monitored by defrosting sensor is below setted point., compressor switching off,following the temperature rise, the frost on evaporator becomes water, and the water flow into the evaporating pan via the draining system, the water in evaporating pan evaporate away finally. -
Page 37: Compressor
Service Manual_2018-V2.0 11. Compressor 11.1 Compressor on and off Control specifications 1.1 When one of the following conditions is met, the compressor stops: 1) Tr ≤ Trt； 2) The compressor runs continuously for more than 3 hours (Stop 5 minutes); 1.2 When all the following conditions are met, the compressor starts up: 1) Tr ≥Trk;... -
Page 38: Troubleshooting Method
Service Manual_2018-V2.0 12. Troubleshooting Method 12.1 Not cooling... -
Page 39: No Working Of Compressor
Service Manual_2018-V2.0 12.2 No working of compressor 12.3 Thermostat malfunction-Undercooling... -
Page 40: Inside Frosting, No Defrosting
Service Manual_2018-V2.0 12.4 Inside frosting, no defrosting 12.5 Inside frosting, no defrosting-Maintenance guidelines... -
Page 41: Light Is Not On
Service Manual_2018-V2.0 12.6 Light is not on... -
Page 42: Noise
Service Manual_2018-V2.0 12.7 Noise... -
Page 43: Figures And Details Of Repair Parts
Service Manual_2018-V2.0 13. Figures and details of repair parts See this section in the TSP. - Page 44 MIDEA appliances after sales website tsp.midea.com For more information about Midea appliances after sales, please visit the tsp.midea.com For more information about the service manual, please visit the For more information about the EV and SBOM, please visit the tsp.midea.com...
