Summary of Contents for Weka TK40 ANNA
- Page 1 TK40 ANNA OPERATING INSTRUCTIONS WEKA Elektrowerkzeuge Auf der Höhe 20, D 75387 Neubulach Telephone: +49 7053 96816-0, Telefax: +49 7053 3138 Internet: www.weka-elektrowerkzeuge.de Email: weka@weka-elektrowerkzeuge.de...
- Page 2 S Y M B O L S Auf der Maschine - On the machine Betriebsanleitung vor Inbetriebnahme sorgfältig durchlesen! Please read operators manual carefully before putting the machine into operation! Notice d’utilisation à lire attentivement avant la mise en service de la machine! Leggere la manuale di istruzioni con attenzione prima dell'utilizzo della macchina! ¡Estas instrucciones se deben leer atentamente antes de poner en marcha la máquina! Voor de ingebruikneming gebruiksanwijzing a.u.b.
- Page 4 FU6 D/C...
- Page 5 OPERATING INSTRUCTIONS - DIAMOND CHAIN SAW TK40 Please read these instructions carefully before starting up the machine! In the WEKA diamond disc saw you have an outstanding quality product with which you will be very satisfied, provided you use it properly.
- Page 6 Avoid abnormal posture. Care for safe standing and keep the balance anytime. Do not work on a ladder. Thus you can control the electric tool better in unexpected situations. Wear suitable clothing. Do not wear wide clothing or jewelry. Keep hair, clothing and gloves away from moving parts.
- Page 7 If a disc saw is used for cutting, care must be taken that the thickness of the cutting blade matches to the diamond chain. Never use a disc saw with a conventional cutting disc for cutting. The narrow saw groove produced in this case leads to a jamming of the diamond chain and can lead to dangerous kickback.
- Page 8 Kickback The word kickback is used to describe a sudden reaction that causes the chain saw to be kicked uncontrollable into the direction of the user or away from the user depending on the direction of rotation. Kickback is caused by blocking of the chain. This uncontrollable movement can cause damages on material and personal injury.
- Page 9 Frequency - Input 50 - 60 max. speed output shaft 1/min 5500 Weight - without sawing equipment Recommended minimum water flow l/min Water protection class IP 55 Cutting Equipment Chain max. cutting Drive sprocket Chain speed at depth maximum motor speed 30 cm / 12"...
- Page 10 This can be obtained from a garden center or builders’ merchant made of plastics. A water coupling of brass of high quality can be received directly from WEKA. Use only clean water, as dirty water will considerably disturb the heat exchange on the cooling surface and thereby the motor can be totally damaged.
- Page 11 Attention: Under full load there are at least 1 l of water per minute required. For cooling and cleaning the bar / chain during the operation of the chain saw, we recommend a larger water flow - see section 3.1 Technical data. Open the ball valve after use, so that the cooling gap can empty.
- Page 12 lever can not be closed, or only very difficult to close, slightly turn the eccentric lever back and try to close the eccentric lever again. If the eccentric lever is in an unfavorable position, you can adjust the position of the eccentric lever by turning the knurled nut.
- Page 13 Outstanding new features include the integration of a Bluetooth interface for simple and secure execution of software updates (with the help of the “WEKA Service App”), as well as a display with membrane keyboard for changing settings and indication of operational state und error conditions.
- Page 14 , already downloaded data will be refused and the process will start from the beginning once the user has initiated it again. In case the update process fails please contact WEKA, we can help you to restore the converters firmware.
- Page 15 Playstore: https://play.google.com/store/apps/details?id=de.wekaelektrowerkzeuge.wekaserviceapp When installing the WEKA Service App it is necessary to allow access to the location. Without permission the App will not be able to communicate with the converter. While establishing a connection depending on the operational system of the smartphone there might be a pairing request.
- Page 17 Frequency converter FU6C (Connect) Status and error outputs are showed to the user via an LED attached to the frequency converter. Status output If there is a status change the green LED on the side of the converter flashes/shines. The number of pulses after a longer break allows the assignation of the status according to following chart: Status code Meaning...
- Page 18 After selecting a listed converter the "WEKA Service App" will compare the current firmware version to the available versions on the WEKA server and will prompt if an update is available. If an update is available please confirm by selecting "Yes" to start the process. The converter...
- Page 19 G U A R A N T E E We will guarantee the WEKA chain saw for 12 months from the day of delivery. During this period we will rectify material and production defects free of charge. This warranty does not cover normal wear and tear, overloading, non-compliance with the operating instructions and intervention by unauthorized persons or the use of parts from other companies.
