- Page 1 DX 5 GR English Printed: 02.08.2018 | Doc-Nr: PUB / 5292646 / 000 / 03...
- Page 2 Printed: 02.08.2018 | Doc-Nr: PUB / 5292646 / 000 / 03...
-
Page 3: Information About The Documentation
Information about the documentation About this documentation • Read this documentation before initial operation or use. This is a prerequisite for safe, trouble-free handling and use of the product. • Observe the safety instructions and warnings in this documentation and on the product. •... - Page 4 This symbol indicates when servicing is due. It appears after 5 years, when 30,000 fasteners have been driven, or when the battery is empty. Our recommendation: Please contact Hilti Service. Product information products are designed for professional users and only trained, authorized personnel are permitted to operate, service and maintain the products.
- Page 5 ▶ Use only Hilti cartridges or cartridges of equivalent quality. ◁ Use of cartridges of inferior quality in Hilti tools may lead to a build-up of unburned powder, which may suddenly explode and cause severe injuries to operators and bystanders. The cartridges must be either verifiably tested by the manufacturer in accordance with EU standard EN 16264 or they must bear the CE conformity marking.
- Page 6 ▶ Do not use the tool in places where there is a risk of fire or explosion unless the tool is specially approved for this type of use. ▶ Never drive fasteners into existing holes unless this is recommended by Hilti (e.g. DX-Kwik). Workstation ▶...
- Page 7 English Printed: 02.08.2018 | Doc-Nr: PUB / 5292646 / 000 / 03...
- Page 8 English Printed: 02.08.2018 | Doc-Nr: PUB / 5292646 / 000 / 03...
- Page 9 Description Overview of the product English Printed: 02.08.2018 | Doc-Nr: PUB / 5292646 / 000 / 03...
-
Page 10: Technical Data
To find out more about the app, to download it and start it, scan the QR code in the case. Information about the field of applications Please refer to the Hilti product page for more information about the field of applications. Technical data... -
Page 11: Operation
the direct fastening tool and its additional equipment or accessories, keeping the operator's hands warm, organization of work procedures. The noise values listed were determined under the following conditions: Noise information conditions Cartridge 6.8/11 caliber, black Power setting Application Fastening 24 mm wood to concrete (C40) with XU47 P8 Noise information in accordance with EN 15895 Sound (power) level (L... - Page 12 1. Press the power regulator release button. 2. Turn the power regulating wheel to set the power level you require. 3. Check the quality of the fastening in accordance with Hilti standards. Select a cartridge power level and power setting to suit the application.
- Page 13 Unloading the single-fastener tool 1. Pull the cartridge out of the tool. 2. Pull the fastener out of the tool. Switching Bluetooth on and off ▶ Press and hold the pushbutton for 1-2 seconds to switch on Bluetooth. Bluetooth switches itself off automatically after 2 minutes. Resetting the cleaning indicator ▶...
- Page 14 X-FCP checker plate fastener 1. Drill or punch the holes in the checker plate. Observe the following minimum dimensions and distances: A = 18-20 mm (0.70''-0.7'') B ≥ 25 mm (≥ 0.98'') 2. Drive the threaded stud through the predrilled or punched hole. Measure the stud stand-off distance by checking the depth of penetration with the gauge.
-
Page 15: Care And Maintenance
This can only be reduced by having the tool taken to Hilti Service for maintenance. ▶ Clean the exterior of the tool with a slightly damp cloth at regular intervals. - Page 16 2. Regularly check all operating controls to ensure that they work properly. 3. Use the tool only with the recommended cartridges and at the recommended power settings. ◁ Use of the wrong cartridges or excessively high power settings may lead to premature failure of the tool.
- Page 17 1. Check the fastener guide for wear and replace it if part of it is damaged (e.g. broken, bent, widened or cracked). 2. Contact Hilti Service if necessary. English Printed: 02.08.2018 | Doc-Nr: PUB / 5292646 / 000 / 03...
- Page 18 5. Clean the exhaust gas piston return unit. 6. Spray the cleaned parts with the supplied Hilti lubricant spray. Use only Hilti lubricant spray or a product of comparable quality. Use of other lubricants may damage the tool. 7. Spray the power regulation wheel with the Hilti spray supplied with the tool.
-
Page 19: Troubleshooting
Rubber dust or debris in the piston ▶ Check the piston and buffer and return unit. replace if necessary. ▶ Contact Hilti Service if the problem persists. The piston jams in the ex- Build-up of combustion residues. ▶ Service the tool. - Page 20 ▶ Change the cartridge strip. The tool has too much built-up dirt ▶ Service the tool. and residues. ▶ If necessary, have the tool checked by Hilti Service. The tool is damaged. ▶ If the problem persists, contact The cartridge strip doesn’t Hilti Service.
-
Page 21: Rohs (Restriction Of Hazardous Substances)
Confirmation of C.I.P. testing The following applies to C.I.P. member states outside the EU and EFTA judicial area: The Hilti DX 5 has been system and type tested. As a result, the tool bears the rectangular PTB approval mark showing approval number S 995. - Page 22 English Printed: 02.08.2018 | Doc-Nr: PUB / 5292646 / 000 / 03...
- Page 23 Printed: 02.08.2018 | Doc-Nr: PUB / 5292646 / 000 / 03...
- Page 24 Printed: 02.08.2018 | Doc-Nr: PUB / 5292646 / 000 / 03...
- Page 25 Printed: 02.08.2018 | Doc-Nr: PUB / 5292646 / 000 / 03...
- Page 26 Hilti = registered trademark of Hilti Corp., Schaan 20180718 Printed: 02.08.2018 | Doc-Nr: PUB / 5292646 / 000 / 03...
