AIR CONDITIONER
Wall mounted type
INDOOR
ASHH07KNCA
ASHH09KNCA
ASHH12KNCA
OUTDOOR
AOHH07KNCA
AOHH09KNCA
AOHH12KNCA
SERVICE MANUAL
SR_AS123EG_04
2024.03.14

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GENERAL ASHH07KNCA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fujitsu GENERAL ASHH07KNCA

Summary of Contents for Fujitsu GENERAL ASHH07KNCA

  • Page 1 AIR CONDITIONER Wall mounted type SERVICE MANUAL INDOOR ASHH07KNCA ASHH09KNCA ASHH12KNCA OUTDOOR AOHH07KNCA AOHH09KNCA AOHH12KNCA SR_AS123EG_04 2024.03.14...
  • Page 2 Mobile” is a trademark of FUJITSU GENERAL LIMITED. Android and Google Play are trademarks of Google LLC. App Store is a service mark of Apple Inc., registered in the U.S. and other countries. Copyright © 2023, 2024 Fujitsu General Limited. All rights reserved.

  • Page 3: General Information

    CONTENTS 1. GENERAL INFORMATION 2. TECHNICAL DATA AND PARTS LIST 3. TROUBLESHOOTING 4. CONTROL AND FUNCTIONS 5. FILED WORKING...
  • Page 5 1. GENERAL INFORMATION 2024.01.25 SR_CH01_AS123EG_02...
  • Page 6 CONTENTS 1. GENERAL INFORMATION 1. Specifications....................01-1 1-1. Indoor unit ........................01-1 1-2. Outdoor unit........................01-3 2. Dimensions....................01-4 2-1. Indoor unit ........................01-4 2-2. Outdoor unit........................01-6...
  • Page 7 1. Specifications 1-1. Indoor unit Wall mounted Type Inverter, Heat pump Model name ASHH07KNCA ASHH09KNCA ASHH12KNCA Power supply 230 V~ 50 Hz Power supply intake Outdoor unit Available voltage range 198—264 V k→ Rated Btu/h 6,800 8,500 11,600 Cooling k→ 0.9—2.9 0.9—3.1 0.9—3.8...
  • Page 8 Wall mounted Type Inverter, Heat pump Model name ASHH07KNCA ASHH09KNCA ASHH12KNCA NOTES: • Specifications are based on the following conditions: – Cooling: Indoor temperature of 27°CDB/19°C→B, and outdoor temperature of 35°CDB/24°C→B. – Heating: Indoor temperature of 20°CDB/15°C→B, and outdoor temperature of 7°CDB/6°C→B. –...

  • Page 9: Outdoor Unit

    1-2. Outdoor unit Type Inverter, Heat pump Model name AOHH07KNCA AOHH09KNCA AOHH12KNCA Power supply 230 V~ 50 Hz Power supply intake Outdoor unit Available voltage range 198—264 V Starting current Cooling 1,430 1,460 Airflow rate Heating 1,390 1,360 Type × Qty Propeller fan ×...
  • Page 10 2. Dimensions 2-1. Indoor unit ¢ Models: ASHH07KNCA, ASHH09KNCA, and ASHH12KNCA Unit: mm Outline of indoor unit for pipe inlet Ø65 for pipe inlet Ø65 - (01-4) - 2-1. Indoor unit 2. Dimensions...

  • Page 11: Installation Space Requirement

     Installation space requirement Provide sufficient installation space for product safety. Unit: mm 30 or more 40 or more Wall hook bracket Outline of the indoor unit 107 or more 163 or more 1,500 or more - (01-5) - 2-1. Indoor unit 2.
  • Page 12 2-2. Outdoor unit ¢ Models: AOHH07KNCA, AOHH09KNCA, and AOHH12KNCA Unit: mm 4-M10 hole Pitch of bolts for installation Top view Side view Front view Side view Airflow Drain port Ø42 Bottom view Side view (Valve part) - (01-6) - 2-2. Outdoor unit 2.
  • Page 13 2. TECHNICAL DATA AND PARTS LIST 2024.03.14 SR_CH02_AS123EG_03...
  • Page 14 CONTENTS 2. TECHNICAL DATA AND PARTS LIST 1. Precautions....................02-1 2. Indoor unit parts list..................02-2 2-1. Models: ASHH07KNCA, ASHH09KNCA, and ASHH12KNCA ........02-2 3. Outdoor unit parts list.................02-6 3-1. Models: AOHH07KNCA, AOHH09KNCA, and AOHH12KNCA ........02-6 4. Accessories ....................02-10 4-1. Indoor unit ........................02-10 4-2.
  • Page 15 • Service parts information and design are subject to change without notice for product improve- ment. • For the latest information of the service parts, refer to our Service Portal. https://fujitsu-general.force.com/portal/ • Precise figure of the service parts listed in this manual may differ from the actual service parts. - (02-1) -...

  • Page 16: Exterior Parts

    2. Indoor unit parts list 2-1. Models: ASHH07KNCA, ASHH09KNCA, and ASHH12KNCA ¢ Exterior parts - (02-2) - 2-1. Models: ASHH07KNCA, ASHH09KNCA, and ASHH12KNCA 2. Indoor unit parts list...
  • Page 17 Item no. Part no. Part name Service part 9388147024 Bracket panel ♦ — →ire cover assy Not available 9333888033 Louver assy (Up/Down) ♦ — Screw cover Not available — Under cover R Not available 9334098004 Remote controller holder ♦ 9358365052 Remote controller assy ♦...
  • Page 18 ¢ Chassis - (02-4) - 2-1. Models: ASHH07KNCA, ASHH09KNCA, and ASHH12KNCA 2. Indoor unit parts list...
  • Page 19 Item no. Part no. Part name Service part 9387593518 Evaporator total assy ♦ 9387467017 Room thermistor holder ♦ 9901013010 Terminal block ♦ 9901160042 Thermistor assy ♦ 9712493094 Main PCB (for 05 model) ♦ 9712493001 Main PCB (for 07 model) ♦ 9712493018 Main PCB (for 09 model) ♦...
  • Page 20 3. Outdoor unit parts list 3-1. Models: AOHH07KNCA, AOHH09KNCA, and AOHH12KNCA ¢ Exterior parts and chassis - (02-6) - 3-1. Models: AOHH07KNCA, AOHH09KNCA, and AOHH12KNCA 3. Outdoor unit parts list...
  • Page 21 Item no. Part no. Part name Service part 9322556165 Top panel assy ♦ 9709689363 Main PCB (for 07 model) ♦ 9709689370 Main PCB (for 09 model) ♦ 9709689387 Main PCB (for 12 model) ♦ 9900727062 Thermistor assy ♦ 9900565053 Thermistor assy (outdoor temp) ♦...
  • Page 22 ¢ Compressor - (02-8) - 3-1. Models: AOHH07KNCA, AOHH09KNCA, and AOHH12KNCA 3. Outdoor unit parts list...
  • Page 23 Item no. Part no. Part name Service part 9334086001 Compressor assy (for 07 and 09 model) ♦ 9334088005 Compressor assy (for 12 model) ♦ 9334089002 4-way valve assy ♦ 9970110153 Solenoid ♦ 9970222009 Expansion valve coil ♦ 9322403001 Pulse motor valve ♦...
  • Page 24 4. Accessories 4-1. Indoor unit ¢ Models: ASHH07KNCA, ASHH09KNCA, and ASHH12KNCA Part name Exterior Part name Exterior Self-tapping screw Operation manual (Large) Self-tapping screw Installation manual (Small) Remote controller →all hook bracket Remote controller Battery holder Installation spacer Cloth tape Operation manual (CD-ROM) 4-2.
  • Page 25 5. Optional parts 5-1. Indoor unit Exterior Part name Model name Summary Air Cleaning Filter can be mounted to Air Cleaning UTR-FA16-5 the indoor unit. Filter (For antibacterial) - (02-11) - 5-1. Indoor unit 5. Optional parts...

  • Page 26: Refrigerant System Diagrams

    6. Refrigerant system diagrams 6-1. Models: AOHH07KNCA, AOHH09KNCA, and AOHH12KNCA Heat exchanger 3-way 2-way (INDOOR) valve valve Muffler Muffler 4-way valve Strainer Expansion valve Heat exchanger Strainer (OUTDOOR) Cooling Heating : Thermistor (Discharge temperature) : Thermistor (Outdoor temperature) : Thermistor (Heat exchanger out temperature) : Thermistor (Pipe temperature) : Thermistor (Room temperature) - (02-12) -...
  • Page 27 7. Wiring diagrams 7-1. Indoor unit ¢ Models: ASHH07KNCA, ASHH09KNCA, and ASHH12KNCA - (02-13) - 7-1. Indoor unit 7. →iring diagrams...
  • Page 28 7-2. Outdoor unit ¢ Models: AOHH07KNCA, AOHH09KNCA, and AOHH12KNCA - (02-14) - 7-2. Outdoor unit 7. →iring diagrams...
  • Page 29 DC 13 V UL1061 AWG28 WHITE WLAN ADAPTER WLAN ADAPTER UL1061 AWG28 WHITE UL1061 AWG28 WHITE (Optional for FUJITSU brand, Built-in for the other brands) Wire with connctor ( USB adapter connection ). CN75 B04B-PAKK-1 (LF) (SN) DC 13 V-3 WHITE...
  • Page 30 8-2. Models: AOHH07KNCA, AOHH09KNCA, and AOHH12KNCA CONTROL UNIT EZ-023EHUE Winding Resistance EMI FILTER TR-28-16-13 FG EMI FILTER EMI FILTER ≒ 2.360 Ω (20°C) F8C T 28*13*16-C GRFC-8 GRFC-8 3 TURNS 1 TURN 1 TURN TO INDOOR UNIT W400 AWG16 RED W103 AWG20 BLACK REACTOR...

  • Page 31: Troubleshooting

    3. TROUBLESHOOTING 2024.01.25 SR_CH03_AS123EG_02...
  • Page 32 CONTENTS 3. TROUBLESHOOTING 1. Error code ....................03-1 1-1. How to check the error memory..................03-1 1-2. How to erase the error memory ..................03-1 1-3. Error code table (Indoor unit)..................03-2 1-4. Error code table (→ireless LAN indicator)...............03-3 1-5. How to check the error code on Mobile app ..............03-4 1-6.

  • Page 33: Table Of Contents

    CONTENTS (continued) 5. Service parts information .................03-59 5-1. Compressor........................03-59 5-2. Inverter compressor......................03-60 5-3. Outdoor unit Electronic Expansion Valve (EEV) ............03-61 5-4. Indoor unit fan motor ....................03-63 5-5. Outdoor unit fan motor ....................03-64 5-6. 4-way valve coil (solenoid coil)/4-way valve ...............03-65 6.

  • Page 35: Error Code

    1. Error code →hen a problem occurs in the system or the connected device, the error content is notified by dis- playing the code. NOTE: This function is only available in a system with indoor or IR receiver units equipped with in- dicator lamps to show the error content.
  • Page 36 1-3. Error code table (Indoor unit) The operation, timer, and economy indicators operate according to the error contents. For confirmation of the error contents, refer the flashing pattern as follows. Indoor unit display Error contents Operation [ ] Timer [ ] Economy [ ] (Green) (Orange)
  • Page 37 1-4. Error code table (Wireless LAN indicator) • →ireless LAN control system diagram example Indoor unit Internet Main PCB Cloud Wireless Mobile app Parts: Outdoor unit router (Smart device) WLAN adapter • Name of parts WLAN adapter Wireless LAN label MAC: SSID: AP- PIN:...
  • Page 38 1-5. How to check the error code on Mobile app If there is an abnormality on the air conditioning, refer to as follows. →hen the (error button) on the home screen is tapped, error code and error name is displayed. Error button Error code Error name...
  • Page 39 1-6. Error code table (Mobile app) Error message Error contents Error code Serial reverse transmission error at start-up 11.1 E: 11. Serial communication error (Serial Serial reverse transmission error during reverse transfer error) (Outdoor unit) 11.2 operation Serial forward transmission error at start-up 11.3 E: 11.
  • Page 40 1-7. Error message for wireless LAN control (Mobile app) ¢ Error display If there is an abnormality on the wireless control system, refer to error messages as follows. Error message - (03-6) - 1-7. Error message for wireless LAN control (Mobile app) 1.

  • Page 41: Error Message List

    ¢ Error message list • Registration error Cause Error Error message code Solution Communication failed. After Communication with the air conditioner failed. checking the following Check the following contents depending on the status of indoor contents, please try again unit wireless LAN indicator lamp or →LAN Adapter LED 2 and after a while.
  • Page 42 Cause Error Error message code Solution →LAN adapter password is Failed because the smartphone could not connect to the air wrong. Enter it again. conditioner. Check the following contents depending on the status of indoor →hen problems are not unit wireless LAN indicator lamp or →LAN Adapter LED 2 and resolved, there may be other operate again.
  • Page 43 Cause Error Error message code Solution • The air conditioner you are trying to register is already registered to another account. • Registration failed because the air conditioner cannot connect to the Internet. • Immediately after turning on the power of the air Air conditioner registration conditioner, wait for about 5 minutes before registering it.
  • Page 44 Cause Error Error message code Solution Registration may have failed because a problem occurred in communication with the server (cloud). 2944 Communication failed. →ait for a while and then operate again. The connected air conditioner ↔our air conditioner does not support Direct Control. 2946 cannot use the Direct control.
  • Page 45 • Sign in error Cause Error Error message code Solution Various settings could not be completed because Communication failed. After 4010 communication with the server (cloud) failed. checking the following 4410 contents, please try again after Check the following contents and operate again. a while.
  • Page 46 Cause Error Error message code Solution User information or temperature unit information could not be Loading of user information obtained because communication with the server (cloud) failed. failed. Check the following Check the following contents and operate again. contents. 4420 1.
  • Page 47 • General error Cause Error Error message code Solution 0100 Communication with the air conditioner failed. 0200 0300 0400 Check the following contents depending on the status of indoor 0500 unit wireless LAN indicator lamp or →LAN Adapter LED 2 and operate again.
  • Page 48 Cause Error Error message code Solution The outdoor unit low noise timer information could not be obtained because communication with the server (cloud) failed. Check the following contents depending on the status of indoor unit wireless LAN indicator lamp or →LAN Adapter LED 2 and operate again.
  • Page 49 Cause Error Error message code Solution The error history information could not be obtained because communication with the server (cloud) failed. Check the following contents depending on the status of indoor unit wireless LAN indicator lamp or →LAN Adapter LED 2 and operate again.
  • Page 50 Cause Error Error message code Solution Air conditioner group setting has not been completed because communication with air conditioner failed. Check the following contents depending on the status of indoor unit wireless LAN indicator lamp or →LAN Adapter LED 2 and operate again.
  • Page 51 Cause Error Error message code Solution Air conditioner group setting has not been completed because communication with air conditioner failed. Check the following contents depending on the status of indoor unit wireless LAN indicator lamp or →LAN Adapter LED 2 and operate again.
  • Page 52 Cause Error Error message code Solution Air conditioner group setting has not been completed because communication with air conditioner failed. Check the following contents depending on the status of indoor unit wireless LAN indicator lamp or →LAN Adapter LED 2 and operate again.
  • Page 53 Cause Error Error message code Solution Various settings could not be completed because Failed to update the screen. communication with the server (cloud) failed. After checking the following contents, please try again after Check the following contents and operate again. a while.
  • Page 54 2. Troubleshooting with error code 2-1. E: 11. Serial communication error (Serial reverse transfer error) (Outdoor unit) Operation indicator 1 time flash Timer indicator 1 time flash Indicator Indoor unit Economy indicator Continuous flash Error code E: 11 Main PCB →hen the indoor unit cannot receive the serial signal from outdoor unit more than 2 minutes after power on, Detective actuator...
  • Page 55 Check point 4. Check serial signal (Reverse transfer signal) Check serial signal (Reverse transfer signal) BLACK WHITE • Check if indicated value swings between AC 90 V and AC 270 V at the outdoor unit terminal 1 —3. • If it is abnormal, check the parts below. –...
  • Page 56 2-2. E: 11. Serial communication error (Serial forward transfer error) (Indoor unit) Operation indicator 1 time flash Timer indicator 1 time flash Indicator Indoor unit Economy indicator Continuous flash Error code E: 11 Main PCB Indoor unit →hen the outdoor unit cannot properly receive the serial Detective actuator Fan motor signal from indoor unit for 10 seconds or more.
  • Page 57 Check point 4. Check serial signal (Forward transfer signal) Check serial signal (Forward transfer signal) BLACK WHITE • Check if indicated value swings between AC 30 V and AC 130 V at outdoor unit terminal 2—3. • If it is abnormal, replace main PCB. Check point 1-2.
  • Page 58 2-3. E: 32. Indoor unit main PCB error (Indoor unit) Operation indicator 3 time flash Timer indicator 2 time flash Indicator Indoor unit Economy indicator Continuous flash Error code E: 32 →hen power is on and there is some below case. Detective actuator Indoor unit Main PCB...
  • Page 59 2-4. E: 35. MANUAL AUTO button error (Indoor unit) Operation indicator 3 time flash Timer indicator 5 time flash Indicator Indoor unit Economy indicator Continuous flash Error code E: 35 Indoor unit controller PCB →hen the MANUAL AUTO button becomes on for Detective actuator Indicator PCB consecutive 60 or more seconds.
  • Page 60 2-5. E: 41. Room temperature sensor error (Indoor unit) Operation indicator 4 time flash Timer indicator 1 time flash Indicator Indoor unit Economy indicator Continuous flash Error code E: 41 Indoor unit main PCB Room temperature thermistor is open or short is Detective actuator detected always.
  • Page 61 2-6. E: 42. Indoor unit heat exchanger sensor error (Indoor unit) Operation indicator 4 time flash Timer indicator 2 time flash Indicator Indoor unit Economy indicator Continuous flash Error code E: 42 Indoor unit main PCB →hen heat exchanger temperature thermistor open or Detective actuator Heat exchanger temperature short circuit is detected.
  • Page 62 2-7. E: 51. Indoor unit fan motor error (Indoor unit) Operation indicator 5 time flash Timer indicator 1 time flash Indicator Indoor unit Economy indicator Continuous flash Error code E: 51 Main PCB →hen the actual rotation number of the indoor unit fan Detective actuator Indoor unit motor is below 1/3 of the target rotation number...
  • Page 63 2-8. E: 62. Outdoor unit main PCB error (Outdoor unit) Operation indicator 6 time flash Timer indicator 2 time flash Indicator Indoor unit Economy indicator Continuous flash Error code E: 62 Access to EEPROM failed due to some cause after Detective actuator Outdoor unit Main PCB...
  • Page 64 2-9. E: 64. PFC circuit error (Outdoor unit) Operation indicator 6 time flash Timer indicator 4 time flash Indicator Indoor unit Economy indicator Continuous flash Error code E: 64 • →hen inverter input DC voltage is higher than 415 V for over 3 seconds, the compressor stops. Detective actuator Outdoor unit Main PCB...
  • Page 65 2-10. E: 65. IPM error (Outdoor unit) Operation indicator 6 time flash Timer indicator 5 time flash Indicator Indoor unit Economy indicator Continuous flash Error code E: 65 Main PCB 1. →hen more than normal operating current to IPM in main PCB flows, the compressor stops.
  • Page 66 Check point 4. Check compressor Check compressor. (Refer to inverter compressor in "Service parts information".) Check point 5. Replace main PCB If Check point 1 to 4 do not improve the symptom, change main PCB. - (03-32) - 2-10. E: 65. IPM error (Outdoor unit) 2.
  • Page 67 2-11. E: 71. Discharge thermistor error (Outdoor unit) Operation indicator 7 time flash Timer indicator 1 time flash Indicator Indoor unit Economy indicator Continuous flash Error code E: 71 Outdoor unit main PCB →hen discharge pipe temperature thermistor open or Detective actuator short circuit is detected at power on or while running the Discharge pipe temperature...
  • Page 68 2-12. E: 73. Outdoor unit heat exchanger thermistor error (Outdoor unit) Operation indicator 7 time flash Timer indicator 3 time flash Indicator Indoor unit Economy indicator Continuous flash Error code E: 73 Outdoor unit main PCB →hen heat exchanger temperature thermistor open or Detective actuator short circuit is detected at power on or while running the Heat exchanger temperature...
  • Page 69 2-13. E: 74. Outdoor temperature thermistor error (Outdoor unit) Operation indicator 7 time flash Timer indicator 4 time flash Indicator Indoor unit Economy indicator Continuous flash Error code E: 74 Outdoor unit main PCB →hen outdoor temperature thermistor open or short Detective actuator circuit is detected at power on or while running the Outdoor temperature thermistor...
  • Page 70 2-14. E: 84. Current sensor error (Outdoor unit) Operation indicator 8 time flash Timer indicator 4 time flash Indicator Indoor unit Economy indicator Continuous flash Error code E: 84 →hen input current sensor has detected 0 A, while inverter compressor is operating at higher than 56 rps, Detective actuator Outdoor unit Main PCB...
  • Page 71 2-15. E: 94. Trip detection (Outdoor unit) Operation indicator 9 time flash Timer indicator 4 time flash Indicator Indoor unit Economy indicator Continuous flash Error code E: 94 Main PCB Protection stop by over-current generation after inverter compressor start processing completed generated consecutively 10 times.
  • Page 72 2-16. E: 95. Compressor motor control error (Outdoor unit) Operation indicator 9 time flash Timer indicator 5 time flash Indicator Indoor unit Economy indicator Continuous flash Error code E: 95 Main PCB 1. →hen running the compressor, if the detected rotor location is out of phase with actual rotor location more than 90°, the compressor stops.
  • Page 73 2-17. E: 97. Outdoor unit fan motor error (Outdoor unit) Operation indicator 9 time flash Timer indicator 7 time flash Indicator Indoor unit Economy indicator Continuous flash Error code E: 97 Main PCB 1. →hen outdoor fan rotation speed is less than 100 rpm in 20 seconds after fan motor starts, fan motor stops.
  • Page 74 2-18. E: 99. 4-way valve error (Outdoor unit) Operation indicator 9 time flash Timer indicator 9 time flash Indicator Indoor unit Economy indicator Continuous flash Error code E: 99 Indoor unit main PCB →hen the indoor heat exchanger temperature is compared with the room temperature, and either Heat exchanger temperature following condition is detected continuously two times,...
  • Page 75 Check point 3. Check the solenoid coil and 4-way valve Solenoid coil • Remove CN30 from PCB and check the resistance value of coil. Resistance value is about 2.085 kΩ (at 20°C). If it is open or abnormal resistance value, replace solenoid coil. •...
  • Page 76 2-19. E: A1. Discharge temperature error (Outdoor unit) Operation indicator 10 time flash Timer indicator 1 time flash Indicator Indoor unit Economy indicator Continuous flash Error code E: A1 Outdoor unit main PCB Protection stop by discharge temperature ≥ 110°C Detective actuator during compressor operation generated 2 times within Discharge temperature thermistor...
  • Page 77 Check point 5. Check the refrigerant amount Check the refrigerant leakage. Check point 6. Replace the main PCB If check point 1 to 5 do not improve the symptom, replace the main PCB. - (03-43) - 2-19. E: A1. Discharge temperature error (Outdoor unit) 2.
  • Page 78 3. Troubleshooting without error code 3-1. Indoor unit—No power Power supply failure Forecast of cause External cause Electrical components defective Check point 1. Check installation condition • Isn’t the breaker down? • Check loose or removed connection cable. -> If abnormal condition is found, correct it by referring to the installation manual or the “DESIGN & TECHNICAL MANUAL”.
  • Page 79 3-2. Outdoor unit—No power Power supply failure Forecast of cause External cause Electrical components defective Check point 1. Check installation condition • Is the circuit breaker on or off? • Check loose or removed connection cable. If abnormal condition is found, correct it by referring to the installation manual or the “DESIGN & TECHNICAL MANUAL”.
  • Page 80 3-3. No operation (Power is on) Setting/ Connection failure Forecast of cause External cause Electrical components defective Check point 1. Check indoor and outdoor installation condition Are these indoor unit, outdoor unit, and remote controller suitable model names to connect? ->...
  • Page 81 3-4. No cooling/No heating Indoor unit error Outdoor unit error Forecast of cause Effect by surrounding environment Connection pipe/Connection wire failure Refrigeration cycle failure Check point 1. Check Indoor unit • Does Indoor unit fan run in the HIGH mode? •...
  • Page 82 NOTES: • Strainer normally does not have temperature difference between inlet and outlet as shown be- low. Pipe (In) Pipe (Out) • If there is a difference like shown below, there is a possibility of inside clogged. In this case, re- place the strainer.

  • Page 83: Abnormal Noise

    3-5. Abnormal noise Abnormal installation (indoor unit/outdoor unit) Forecast of cause Fan failure (indoor unit/outdoor unit) Compressor failure (outdoor) Diagnosis method when abnormal noise is occurred Abnormal noise is coming from Outdoor Abnormal noise is coming from Indoor unit. unit. (Check and correct followings) (Check and correct followings) •...
  • Page 84 3-6. Water leaking Erroneous installation Forecast of cause Drain hose failure Diagnosis method when water is spitting Diagnosis method when water leak occurs • Is main unit installed in stable condi- tion? Is the filter clogged? • Is main unit broken or deformed at the time of transportation or maintenance? MPa MPa •...
  • Page 85 4. Troubleshooting with error code (For wireless LAN adapter) 4-1. E: 18. External communication error between indoor unit and wireless LAN adapter Operation indicator 1 time flash Timer indicator 8 time flash Economy indicator Continuous flash Indoor unit Indicator →ireless LAN Flashing slowly indicator Error code...
  • Page 86 4-2. Network communication error between wireless LAN router and wireless LAN adapter Operation indicator No indication Timer indicator No indication Economy indicator No indication Indoor unit Indicator →ireless LAN Flashing slowly indicator Error code — Mobile app No indication →ireless LAN router →hen the not connection between wireless LAN adapter and wireless LAN router.
  • Page 87 Check point 4. Replace wireless LAN adapter. If check point 3 do not improve the symptom, replace the wireless LAN adapter and cancel the reg- istration of air conditioner on the Mobile app. After replacing the adapter, perform the pairing on the Mobile app. For the method of the Mobile app, refer to "Mobile app setting method"...
  • Page 88 4-3. E: 18. Communication error Operation indicator 1 time flash Timer indicator 8 time flash Economy indicator Continuous flash Indoor unit Indicator →ireless LAN Flashing slowly indicator Error code E: 18 Mobile app E: 18.1 →ireless LAN router →hen the external communication error between indoor unit and wireless LAN adapter and network →ireless LAN adapter PCB communication error between wireless LAN router and...
  • Page 89 Check point 4. Check the connection cable Check the connection cable on the wireless LAN router. -> If there is loose connector, open cable or mis-wiring, correct it. Check point 5. Check the connection status. Check the connection status to the Internet and wireless LAN router. ->...
  • Page 90 4-4. E: 18. Wireless LAN adapter non-energized Operation indicator 1 time flash Timer indicator 8 time flash Economy indicator Continuous flash Indoor unit Indicator →ireless LAN No indication indicator Error code E: 18 Mobile app No indication Indoor unit controller PCB →hen the voltage (DC 12 V) does not output from the Detective actuator controller PCB.
  • Page 91 4-5. Mobile app setting method ¢ Air conditioner delete method →hen the wireless LAN adapter is replaced, delete of all air conditioner is necessary on the mobile app. Launch the mobile app. Tap the icon to display the Setting screen. Tap the “Air conditioner editing”.
  • Page 92 Tap the air conditioner to be deleted. Tap the Delete button. Tap the OK button. Deletion of the air conditioner registered in the mobile app is completed. - (03-58) - 4-5. Mobile app setting method 4. Troubleshooting with error code (For wireless LAN adapter)

  • Page 93: Service Parts Information

    5. Service parts information 5-1. Compressor Diagnosis method of compressor (If outdoor unit LED displays error, refer to troubleshooting) Does not start up Stops soon after starting up Abnormal noise Check if vibration noise by Is there open or loose con- Is there open or loose con- loose bolt or contact noise of nection cable?

  • Page 94: Inverter Compressor

    5-2. Inverter compressor Check point 1. Check the terminal connection. • Check the following terminal connections of the compressor. (Loosening or incorrect wiring.) S (V) C (W) R (U): Red S (V): →hite Main PCB C (W): Black R (U) •...

  • Page 95: Outdoor Unit Electronic Expansion Valve (Eev)

    5-3. Outdoor unit Electronic Expansion Valve (EEV) Check point 1. Check connections Check connection of connector. (Loose connector or open cable) NOTE: For details of wiring diagram, refer to "→iring diagrams" in Chapter 2. TECHNICAL DATA AND PARTS LIST on page 02-13. Check point 2.
  • Page 96 Check point 6. Check strainer • Strainer normally does not have temperature difference between inlet and outlet as shown be- low. Pipe (In) Pipe (Out) • If there is a difference like shown below, there is a possibility of inside clogged. In this case, replace the strainer.

  • Page 97: Indoor Unit Fan Motor

    5-4. Indoor unit fan motor Check point 1. Check rotation of fan Rotate the fan by hand when operation is off. (Check if fan is caught, dropped off or locked motor) If fan or bearing is abnormal, replace it. Check point 2. Check resistance of indoor fan motor Refer to below.

  • Page 98: Outdoor Unit Fan Motor

    5-5. Outdoor unit fan motor Check point 1. Check rotation of fan Rotate the fan by hand when operation is off. (Check if fan is caught, dropped off or locked motor) If fan or bearing is abnormal, replace it. Check point 2. Check resistance of outdoor fan motor Refer to below.

  • Page 99: 4-Way Valve Coil (Solenoid Coil)/4-Way Valve

    5-6. 4-way valve coil (solenoid coil)/4-way valve Check point 1. Check connection • Check the connection of connector P60. BLUE SOLENOID COIL Check Point 2 : Check Solenoid Coil Remove P60 from PCB and check the resistance value of coil. Resistance Value ≈...

  • Page 100: Thermistor Resistance Values

    6. Thermistor resistance values 6-1. Indoor unit ¢ Room temperature thermistor Temperature (°C) Resistance (kΩ) Voltage (V) -10.0 58.25 0.73 -5.0 44.03 0.93 33.62 1.15 25.93 1.39 10.0 20.18 1.66 15.0 15.84 1.94 20.0 12.54 2.22 25.0 10.00 2.50 30.0 8.04 2.77 35.0...

  • Page 101: Outdoor Unit

    6-2. Outdoor unit ¢ Discharge temperature thermistor Temperature (°C) Resistance (kΩ) Voltage (V) -30.0 1,013.11 0.06 -25.0 729.09 0.09 -20.0 531.56 0.12 -15.0 392.31 0.16 -10.0 292.91 0.21 -5.0 221.09 0.28 168.60 0.36 129.84 0.46 10.0 100.91 0.57 15.0 79.12 0.71 20.0 62.55...
  • Page 102 ¢ Heat exchanger temperature thermistor Temperature (°C) Resistance (kΩ) Voltage (V) -30.0 95.58 0.24 -25.0 68.90 0.32 -20.0 50.31 0.43 -15.0 37.19 0.57 -10.0 27.81 0.73 -5.0 21.02 0.92 16.05 1.14 12.38 1.39 10.0 9.63 1.65 15.0 7.56 1.93 20.0 5.98 2.21 25.0...

  • Page 103: Control And Functions

    4. CONTROL AND FUNCTIONS 2024.01.12 SR_CH04_AS123EG_01...
  • Page 104 CONTENTS 4. CONTROL AND FUNCTIONS 1. Rotation number control of compressor...........04-1 1-1. Cooling operation ......................04-1 1-2. Heating operation ......................04-3 1-3. Dry operation ........................04-4 1-4. Rotation number of compressor at normal start-up ............04-4 1-5. Limitation of compressor rotation number by outdoor temperature.........04-5 2.

  • Page 105: Rotation Number Control Of Compressor

    1. Rotation number control of compressor 1-1. Cooling operation A sensor (room temperature thermistor) built in the indoor unit body will usually perceive difference or variation between a set temperature and present room temperature, and controls the operation rotation number of the compressor. •...
  • Page 106 • Limit of maximum speed based on outdoor temperature Outdoor temperature rises Outdoor temperature drops 36°C A zone 34°C 32°C B zone 30°C 21°C C zone 19°C 12°C D zone 10°C 2°C E zone 0°C F zone Unit: rps Indoor unit fan mode Outdoor Model name temperature zone...

  • Page 107: Heating Operation

    1-2. Heating operation A sensor (room temperature thermistor) built in indoor unit body will usually perceive difference or variation between setting temperature and present room temperature, and controls operation rota- tion number of compressor. • If the room temperature is 6.0 °C lower than a set temperature, the operation rotation number of compressor will attain to maximum performance.

  • Page 108: Dry Operation

    1-3. Dry operation The rotation number of compressor shall change according to the temperature, set temperature, and room temperature variation which the room temperature sensor of the indoor unit has detected as shown in the table below. Zone is defined by set temperature and room temperature. •...

  • Page 109: Limitation Of Compressor Rotation Number By Outdoor Temperature

    1-5. Limitation of compressor rotation number by outdoor temperature The minimum rotation number of compressor is limited by outdoor temperature as below. • Cooling/Dry mode F zone 38°C E zone 19°C D zone 10°C C zone 0°C B zone -10°C A zone Limitation of compressor Model name...
  • Page 110 - (04-6) - 1-5. Limitation of compressor rotation number by outdoor temperature 1. Rotation number control of compressor...

  • Page 111: Auto Changeover Operation

    2. Auto changeover operation →hen the air conditioner is set to AUTO mode by remote controller, operation starts in the optimum mode from among heating, cooling, dry and monitoring modes. During operation, the optimum mode is automatically switched in accordance with temperature changes. The temperature can be set be- tween 18°C and 30°C in 1.0°C steps.

  • Page 112: Operation Flow Chart

    Operation flow chart Start Ts: Setting temperarure Monitor mode Room temp. > Ts+2°C? Room temp. < Ts-2°C? Middle zone Auto change over is second or more? Operation mode before the monitor mode is cooling mode? Operation mode of Heating operation Cooling operation outdoor unit: Cooling? Thermostat remains...

  • Page 113: Fan Control

    3. Fan control Tr: Room temperature Ts: Setting temperature 3-1. Indoor fan control ¢ Fan speed Indoor fan speed is defined as below. Speed (rpm) Operation mode Fan mode ASHH07KNCA ASHH09KNCA ASHH12KNCA PO→ERFUL 1,130 1,130 1,210 HIGH 1,030 1,030 1,070 MED—HIGH 1,000 Heating...

  • Page 114: Cooling Operation

    ¢ Cooling operation Switch the airflow AUTO, and indoor fan motor will run according to room temperature, as below. On the other hand, if switched in HIGH—QUIET, indoor motor will run at a constant airflow of COOL operation modes QUIET, LO→, MED, HIGH as shown in “Fan speed” above. Airflow change over (Cooling: Auto) Tr - Ts ≥...
  • Page 115 ¢ Cool air prevention control (heating mode) The maximum value of the indoor fan speed is set as shown below, based on the detected tempera- ture by the indoor heat exchanger sensor on heating mode. • Normal operation Indoor heat exchanger temperature rises Indoor heat exchanger HIGH...
  • Page 116 • Powerful operation Indoor heat exchanger temperature rises Indoor heat exchanger POWERFUL temperature drops 42°C 37°C HIGH 39°C 34°C 37°C 32°C Cool air prevention or setting fan mode* 30°C 28°C S-LOW *: Lower speed is selected. 7 minutes later: Indoor heat exchanger temperature rises Indoor heat exchanger POWERFUL...

  • Page 117: Outdoor Fan Control

    3-2. Outdoor fan control ¢ Outdoor fan motor This outdoor unit has a DC fan motor. (Control method is different between AC and DC motors.) ¢ Fan speed  Models: AOHH07KNCA and AOHH09KNCA Fan speed is defined by outdoor temperature and compressor frequency. •...
  • Page 118  Model: AOHH12KNCA Fan speed is defined by outdoor temperature and compressor frequency. • Outside air temperature zone selection Outside air Outside air temperature rises temperature drops Y zone 21°C 19°C Z zone 12°C 10°C F zone 2°C 0°C G zone -8°C -10°C H zone...

  • Page 119: Louver Control

    4. Louver control 4-1. Horizontal louver control Each time the button is pressed, the airflow direction range will change as below: Side view • Remote controller display is not changed. • Up/down airflow direction is set automatically as shown, in accordance with the type of operation selected.

  • Page 120: Swing Operation

    4-3. Swing operation • To select up/down airflow swing operation →hen the swing signal is received, the horizontal louver starts to swing. – Swinging range • Cooling mode/dry mode/fan mode (1 to 3): 1 • Heating mode/fan mode (4 to 6): 3 –...

  • Page 121: Timer Operation Control

    5. Timer operation control 5-1. Wireless remote control On/Off timer Program timer Sleep timer Weekly timer ○ ○ ○ — ¢ On/Off timer • Off timer: →hen the clock reaches the set timer, the air conditioner will be turned off. Operation mode Stop mode Set time of timer...

  • Page 122: Sleep Timer

    ¢ Sleep timer If the sleep timer is set, the room temperature is monitored and the operation is stopped auto- matically. If the operation mode or the set temperature is change after the sleep timer is set, the operation is continued according to the changed setting of the sleep timer from that time on. •...

  • Page 123: Defrost Operation Control

    6. Defrost operation control Tn: Outdoor unit heat exchanger temperature Ta: Outdoor temperature Tn10: Temperature at 10 minutes after compressor start Tnb: Temperature before 5 minutes Triggering condition • The defrost operation starts when outdoor unit heat exchanger temperature sensor detects the temperature lower than the values shown below.

  • Page 124: Defrost Operation In Heating Operation Stopped

    6-1. Defrost operation in heating operation stopped If the outdoor unit is frosted when stopping the heating operation, it stops after performing the auto- matic defrosting operation. In this time, if the indoor unit operation lamp flashes slowly (6 sec on/2 sec off), the outdoor unit al- low the heat exchanger to defrost, and then stop.

  • Page 125: Various Control

    7. Various control 7-1. Auto restart →hen the power was interrupted by a power failure etc. during operation, the operation contents at that time are memorized and when the power is recovered, operation is automatically started with the memorized operation contents. Operation contents memorized when the power is interrupted Operation mode Setting temperature...

  • Page 126: Forced Cooling Operation

    7-3. Forced cooling operation The outdoor unit may not operate depending on the room temperature. →hen FORCED COOLING OPERATION button is pressed more than 10 seconds, forced cooling operation starts as shown in the table below. Operation mode Cooling Fan mode HIGH Timer mode Continuous (no timer setting available)

  • Page 127: Powerful Operation

    7-6. POWERFUL operation The PO→ERFUL operation starts by pressing PO→ERFUL button on the remote controller. The indoor unit and outdoor unit operate at maximum power as shown in the table below. Rotation number of compressor Maximum Fan mode PO→ERFUL Cooling Vertical airflow direction louver setting Heating...

  • Page 128: External Electrical Heater Control

    7-9. External electrical heater control The external electrical heater is operated as below. When the room Ts: Setting temperature temperature rises Heater : Off Ts -1°C Ts -3°C Heater : On Ts -10°C Ts -12°C Heater : Off When the room temperature drops NOTES: •...

  • Page 129: Various Protections

    8. Various protections 8-1. Discharge gas temperature over-rise prevention control The discharge gas temperature sensor (discharge thermistor: outdoor unit side) detects the dis- charge gas temperature. • →hen the discharge temperature becomes higher than the trigger condition, the rotation number of compressor is decreased as the table below, and it continues to decrease until the discharge tem- perature becomes lower than the trigger condition.

  • Page 130: Current Release Control

    8-3. Current release control The rotation number of compressor is controlled so that the outdoor unit input current does not ex- ceeds current limit value set according to the outdoor temperature. The rotation number of compressor returns according to the operation mode, when the current be- comes lower than the release value.

  • Page 131: High Temperature And High Pressure Release Control

    8-6. High temperature and high pressure release control The compressor is controlled as follows. Indoor unit heat exchanger Indoor unit heat exchanger temperature rises temperature drops 63°C 55°C Zone A 53°C Zone B 50°C Zone C Zone D Stable zone Zone E Zone Operation...
  • Page 132 - (04-28) - 8-6. High temperature and high pressure release control 8. Various protections...
  • Page 133 5. FILED WORKING 2024.01.12 SR_CH05_AS123EG_01...
  • Page 134 CONTENTS 5. FILED WORKING 1. Function settings ..................05-1 1-1. Function settings by using remote controller ..............05-1 1-2. Custom code setting for wireless remote controller ............05-5...

  • Page 135: Function Settings By Using Remote Controller

    1. Function settings To adjust the functions of this product according to the installation environment, various types of function settings are available. NOTE: Incorrect settings can cause a product malfunction. 1-1. Function settings by using remote controller Some function settings can be changed on the remote controller. After confirming the setting proce- dure and the content of each function setting, select appropriate functions for your installation envi- ronment.
  • Page 136 STEP 2: Selecting the function number and setting value 1. Press the TEMP./SELECT ( ) buttons to select the function Function number number. To switch between the left and right digits, press the MODE button. 2. Press the FAN SPEED button to proceed the setting value. To re- turn the function number selection, press the FAN SPEED button again.

  • Page 137: Contents Of Function Setting

    ¢ Contents of function setting Each function setting listed in this section is adjustable in accordance with the installation environ- ment. NOTE: Setting will not be changed if invalid numbers or setting values are selected.  Function setting list Function no. Functions Filter sign 30/31...

  • Page 138: Auto Restart

    2) Room temperature control for indoor unit sensor Depending on the installed environment, correction of the room temperature sensor may be re- quired. Select the appropriate control setting according to the installed environment. The temperature of the room temperature sensor is corrected as follows: Corrected temp.

  • Page 139: Custom Code Setting For Wireless Remote Controller

    5) Indoor unit fan control for energy saving for cooling Enables or disables the power-saving function by controlling the indoor unit fan rotation when the outdoor unit is stopped during cooling operation. Function number Setting value Setting description Factory setting Disable Enable Remote controller...

This manual is also suitable for:

General ashh09kncaGeneral ashh12kncaGeneral aohh07kncaGeneral aohh09kncaGeneral aohh12knca

Table of Contents
