AIR CONDITIONER

4-unit multi-split type,

5-unit multi-split type

DESIGN & TECHNICAL MANUAL

INDOOR

ASHG07–14KMTB

ASHH07–14KMCG-B

ASHG07–14KMCC

ASHH07–14KMCH-B

ASHG07–14KMCE

ASHG07–14KMCF

ASHH07–14KMCG

ASHH07–14KMCH

ASHG18–24KMTB

ASHG18–24KMTE

AUXG07–22KVLA

ARXG07–14KSLAP

ASHG07–14KETA

ASHG07–14KETA-B

ASHG07–14KETE-B

ASHG07–14KETF-B

ABHG18–22KRTA

AGHG09–14KVCA

ARXG07–14KLLAP

ARXG18KSLAP

ARXG18KLLAP

ASHG07–14KGTB

ASHG07–14KETE

ASHG07–14KGTE

ASHG07–14KETF

ASHG07–14KGTF

ASHH07–14KGTG

ASHH07–14KGTH

OUTDOOR

ARXH12–18KMTAP

ARXH22KMTAP

ARXG22KMLB

ASHH05–12KNCA

ASHH05–12KNCH

AOHG30KBTA4

AOHG36KBTA5

DR_MU025EG_16

2024.12.16
