OPTICAL AMPLIFIER OAD514
1. Product description
The optical amplifier OAD514 is designed to amplify the optical input signal and distribute through four fiber optic outputs.
Device inside contains Erbium Doped Fiber Amplifier (EDFA) module and optical splitter with four outputs.
Device is equipped with web server. Web server provides diagnostics and control of the amplifier via Ethernet port using
a Web browser.
The product is intended for indoor usage only.
2. Characteristics
• Four optical outputs.
• Device status indication LED.
• Safety warning LED indication when laser diode is powered on.
• Web interface for configuration and monitoring.
• SNMP agent for device monitoring and alarms.
• This device is equipped with the cooling FAN (12 V DC 1.7 W)
• Device has automatic FAN speed adjustment function.
3. Safety instructions
The amplifier must be installed in accordance with IEC 60728-11 and national safety standards.
The amplifier is powered from a 12 V power supply unit. This voltage is not dangerous to life.
The power supply unit must have a short circuit protection.
Any repairs must be made by a skilled personnel.
Do not connect the 12 V power supply unit into the mains socket until all cables of amplifier have been correctly
connected. The mains socket must be easily accessible.
Disconnect the amplifier power supply by removing the power supply cable from the mains socket.
Do not expose this device to moisture or water splashes.
Avoid placing the amplifier near heat sources, e.g. central heating components or in areas of high humidity.
Keep the device away from naked flames.
If the amplifier has been stored in cold conditions for a long time, bringing it into a warm environment may cause
condensation. In such cases let it warm up for at least 2 hours before plugging it into the mains.
IMPORTANT: Mounting of the module is allowed in a vertical direction only and the free flow of air through the unit must
be not restricted. Always leave 10 cm of free space from the top, front and bottom of the unit to allow heat dissipation.
Always leave at least 5 cm free space from fan side (see Figure 5).
Please note, that device laser diode lifetime highly depends on the ambient temperature and device cooling. Therefore
it is important to keep the device temperature in safe operating temperature range.
Vers. 1.07
1
EN
