20G020-00 E5 – 2014-01-21
User Manual
®
G20 – 3U CompactPCI
®
Serial Intel
Core™ i7 CPU
Board

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G20 and is the answer not in the manual?

Questions and answers

Related Manuals for MEN G20

Summary of Contents for MEN G20

  • Page 1 All manuals and user guides at all-guides.com 20G020-00 E5 – 2014-01-21 User Manual ® G20 – 3U CompactPCI ® Serial Intel Core™ i7 CPU Board...
  • Page 2 DIN, EN or IEC industry standards. The G20 is also ready for coating so that it can be used in humid and dusty environments and has a guaranteed minimum standard availability of 7 years.
  • Page 3 Ethernet PCIe x1 USB 2.0 10/100/1000Base‐T USB 2.0 USB 2.0 USB 2.0 DisplayPort/HDMI USB 2.0 QM57 Platform  CPCI‐S.0  USB 2.0 DisplayPort/HDMI Controller Hub Connectors DisplayPort/HDMI mSATA USB‐to‐SATA 5 PCIe x1 MicroSD USB 2.0 SMBus USB 2.0 Board‐to‐Board FPGA Connector USB 2.0 SGPIO SFF‐8485 (for Ethernet  Rear I/O  Card) PCIe x1 MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...

  • Page 4: Technical Data

    • Two DisplayPort® connectors at front panel - Optionally two DVI/HDMI ports via external adapter • One DisplayPort® at CPCI-S.0 rear connector (instead of one interface at the front) - Optionally SDVO or DVI/HDMI port MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...
  • Page 5 • Data rate 250 MB/s (2.5 Gbit/s per lane) Miscellaneous • Real-time clock with GoldCap backup, battery-buffered • Power supervision and watchdog • Temperature measurement • 2 board status LEDs • 2 user LEDs • Reset button MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...
  • Page 6 • Conforming to EN 55022 (radio disturbance), IEC 61000-4-2 (ESD), IEC 61000-4-3 (electromagnetic field immunity), IEC 61000-4-4 (burst), IEC 61000- 4-5 (surge) and IEC 61000-4-6 (conducted disturbances) BIOS • InsydeH2O™ UEFI Framework MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...
  • Page 7 - Detailed matrix of supported interfaces under Ubuntu 10.04 and OpenSuse 11.3 • VxWorks® (on request) • QNX® (on request) • For more information on supported operating system versions and drivers see online data sheet. MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...

  • Page 8: Configuration Options

    • Depends on board configuration (CPU, mezzanines, hard disk...) • Minimum: -40°C (all processors) Cooling Concept • Also available with conduction cooling in MEN CCA frame Please note that some of these options may only be available for large volumes. Please ask our sales staff for more information.

  • Page 9: Product Safety

    • Store the board only in its original ESD-protected packaging. Retain the original packaging in case you need to return the board to MEN for repair. MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...

  • Page 10: About This Document

    Update, removed peripheral slot option, modified 2012-10-26 Chapter 2.3 Intel Active Management, cosmetics Removed 8 GB DRAM option, added Ethernet port 2014-01-21 number for AMT, added RTC accuracy, corrected screw type for mSATA installation MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...
  • Page 11 "in" meaning "to the board or component", "out" meaning "coming from it". Vertical lines on the outer margin signal technical changes to the previous issue of the document. MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...

  • Page 12: Legal Information

    The publication is provided on the terms and understanding that: 1. MEN is not responsible for the results of any actions taken on the basis of information in the publication, nor for any error in or omission from the publication; and 2.
  • Page 13 Since January 2005 the SMD and manual soldering processes at MEN have already been completely lead-free. Between June 2004 and June 30, 2006 MEN’s selected component suppliers have changed delivery to RoHS- compliant parts. During this period any change and status was traceable through the MEN ERP system and the boards gradually became RoHS-compliant.

  • Page 14: Table Of Contents

    2.12.2 Implementation on G20 ......39 2.13 CompactPCI Serial ........40 2.13.1...
  • Page 15 Contents 2.13.2 Implementation on the G20......41 2.13.3 CompactPCI Serial Connectors P1..P5 ....42 2.13.4...
  • Page 16 Figure 5. CompactPCI Serial backplane with filling order ....41 Figure 6. Position of battery on the CompactFlash adapter on the G20 (board versions -00 and -01)....... . . 86 Figure 7.
  • Page 17 Table 1. Processor core options on G20 ....... 26 Table 2.

  • Page 18: Getting Started

    This chapter gives an overview of the board and some hints for first installation in a system. Map of the Board Figure 1. Map of the board – front panel ® CompactPCI Serial MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...

  • Page 19: Map Of The Board - Top View With Compactflash (Board Versions 02G020-00 And -01)

    Figure 3. Map of the board – top view with mSATA disk (board versions 02G020-02 and -03) m SATA m icroSD (bottom) Display Port Connectors Heat Sink Connectors Ethernet Connectors Battery M 12 Connector for Ethernet (optional) MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...

  • Page 20: Figure 4. Map Of The Board - Top View With Ethernet Rear I/O Card

    Figure 4. Map of the board – top view with Ethernet rear I/O card CompactPCI Serial Connector P6 Display Port Connectors Heat Sink Connectors Ethernet Connectors microSD Card Slot Bottom side of Ethernet card M12 Connector for Ethernet (optional) MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...

  • Page 21: Configuring The Hardware

    Chapter 2.8.3 mSATA Disk on page 31  Ethernet via rear I/O according to CompactPCI Serial The G20 offers the possibility to realize a different number of Ethernet ports at the rear via a special adapter card. In that case no CompactFlash or mSATA can be used and no battery is available to buffer the real time clock.

  • Page 22: Integrating The Board Into A System

    All manuals and user guides at all-guides.com Getting Started Integrating the Board into a System You can use the following check list when installing the G20 in a system for the first time and with minimum configuration.  Power-down the system.

  • Page 23: Troubleshooting At Start-Up

    All manuals and user guides at all-guides.com Getting Started Troubleshooting at Start-up If you have any problems at start-up of the G20, you can start the board with UEFI default settings for troubleshooting. Please refer to Chapter 3 BIOS on page Configuring BIOS The G20 is equipped with an InsydeH2O UEFI framework.

  • Page 24: Functional Description

    88). Power Supply The G20 board is supplied with +12V only. The voltage range is +9 V up to +16 V (absolute maximum voltage). The voltage is monitored within these borders. The G20 board can optionally be supplied with +5V (+5%/-3%) standby voltage.

  • Page 25: Intel Active Management Technology (Amt)

    Intel chipsets which enables e.g. out-of-band (OOB) diagnostics, remote control, IDE-Redirect, Serial-over-LAN (SOL), agent presence checking and network traffic filtering. AMT is supported on the lower front Ethernet interface (ETH2) of the G20. For information on how to enable the AMT BIOS extension see Chapter 3 BIOS.

  • Page 26: Reset Behavior

    All manuals and user guides at all-guides.com Functional Description Reset Behavior The G20 can be reset using the reset button on the front panel or the PRST# signal on the backplane. (See also Chapter 2.14 Reset Button on page 52.) Real-Time Clock The board includes a real-time clock connected to the chipset.

  • Page 27: Memory

    The memory bus is 2x72 bits wide (dual channel) and operates with up to 1066 MHz. 2.7.2 Boot Flash The G20 has an 64-Mbit SPI Serial Flash implemented as on-board Flash for BIOS data. 2.7.3 EEPROM The board has a 2-kbit serial EEPROM for factory data.

  • Page 28: Mass Storage

    Functional Description Mass Storage The G20 offers the possibility to connect an mSATA disk (CompactFlash on the older board versions 02G020-00 and 02G020-01) and a microSD card on a small adapter card in the heat sink area which is assembled by standard.

  • Page 29: Microsd Card

    Functional Description 2.8.2 microSD Card The G20 provides an onboard microSD card slot on the bottom side of the mSATA adapter card in the heat sink area. The slot is ready-to-use. The G20 is shipped without a microSD card installed.
  • Page 30 The Ethernet rear I/O card (e.g. GM1) also offers a microSD card slot. To install a microSD card, please stick to the following procedure.  Power down your system and remove the G20 from the system.  Put the board on a flat surface.

  • Page 31: Msata Disk

    Installing an mSATA disk To install an mSATA disk, please stick to the following procedure.  Power down your system and remove the G20 from the system.  Put the board on a flat surface.  Insert the mSATA disk carefully in a 30° angle.
  • Page 32 All manuals and user guides at all-guides.com Functional Description  Fix the card using two M2.5 x4 screws (highlighted in red). mSATA microSD (bottom) Heat Sink MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...

  • Page 33: Serial Ata (Sata)

    The interface is compliant to the SATA generation 2 (3.0 Gb/s) specification and can be run in AHCI and RAID mode. Chapter 2.13 CompactPCI Serial on page 40 for the rear I/O pin assignment. MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...

  • Page 34: Graphics

    Display Port Two DisplayPort interfaces can be accessed at the front panel. Using adapters two DVI or two HDMI interfaces are also possible. MEN offers a DisplayPort to DVI-D Adapter as an accessory. See MEN’s website for ordering information. In the following table you can find a list of adapters that have also been tested and can be used with the G20.

  • Page 35: Rear I/O

    Power for connector (3.3 V, 500 mA) RETURN PWR Return for Power 2.9.2 Rear I/O The G20 provides a digital display interface on CompactPCI Serial connector P2. Chapter 2.13 CompactPCI Serial on page MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...

  • Page 36: Usb Interfaces

    2.10 USB Interfaces The G20 provides fourteen USB 2.0 ports controlled by the QM57 platform controller hub. Two USB interfaces are routed to standard front-panel connectors, eight can be accessed on the CompactPCI Serial rear I/O connectors and two are led to the board-to-board connector for the Ethernet rear I/O adapter card (e.g.

  • Page 37: Ethernet Interfaces

    0x 00 C0 3A 05 Cx xx - 0x 00 C0 3A 05 Fx xx • LAN2: where "00 C0 3A" is the MEN vendor code, "05" is the MEN product code. The last four digits depend on the interface and the serial number of the product. The serial number is added to the offset, for example for LAN1: 0x xx xx = 0x8000 + 0x002A = 0x 80 2A.

  • Page 38: Rear I/O Connection (Compactpci Serial)

    To achieve more flexibility, these interfaces are not implemented directly on the G20 but on a small adapter card (e.g. the GM1) which is equipped with the CompactPCI Serial connector P6. Two cards with 4 or 8 Ethernet interfaces are already available.

  • Page 39: Pci Express

    2.12.2 Implementation on G20 On G20 the two Gigabit Ethernet channels are permanently connected via two PCIe x1 links. Another five x1 links are available for use via rear I/O. One x1 link is led to the board-to-board connector for the Ethernet rear I/O card. See Chapter 2.13.4...

  • Page 40: Compactpci Serial

    Ethernet ports from the system slot are led to the first peripheral slot, the second to the second etc. and the first SATA interface to the eighth peripheral slot, the second to the seventh etc. See Figure 5, CompactPCI Serial backplane with filling order on page MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...

  • Page 41: Figure 5. Compactpci Serial Backplane With Filling Order

    2.13.2 Implementation on the G20 The G20 supports 6 SATA interfaces, 8 USB 2.0, 1 DisplayPort, five PCI Express x1 links as well as two PEG x8 (PCI Express fat pipe) ports on the backplane. Please note that slot 9 does not support PCI Express and slots 2 and 3 do not support SATA on a standard 9-slot CompactPCI Serial backplane with the G20 in the system slot.

  • Page 42: Compactpci Serial Connectors P1..P5

    PRST# RST# PS_ON# EN#) STND +12V +12V +12V +12V +12V +12V +12V Note: The signals written in gray are specified in the CompactPCI Serial specification but not supported on this board. MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...

  • Page 43: Table 11. Pin Assignment Of Compactpci Serial P2 Connector

    1_PE_ 1_PE_ 1_PE_ 1_PE_ 1_PE_ 1_PE_ 1_PE_ 1_PE_ Rx07- Rx07+ Tx07- Tx07+ Rx06- Rx06+ Tx06- Tx06+ 1_PE_ 1_PE_ 1_PE_ 1_PE_ 1_PE_ 1_PE_ 1_PE_ 1_PE_ Rx05- Rx05+ Tx05- Tx05+ Rx04- Rx04+ Tx04- Tx04+ MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...

  • Page 44: Table 12. Pin Assignment Of Compactpci Serial P3 Connector

    _Tx- _Tx+ _Rx- _Tx- _Tx+ USB2- USB2+ USB2- USB2+ USB2- USB2+ USB2- USB2+ Note: The signals written in gray are specified in the CompactPCI Serial specification but not supported on this board. MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...

  • Page 45: Table 13. Pin Assignment Of Compactpci Serial P4 Connector

    3_PE_ 3_PE_ 3_PE_ 3_PE_ 3_PE_ Rx01- Rx01+ Tx01- Tx01+ Rx00- Rx00+ Tx00- Tx00+ Note: The signals written in gray are specified in the CompactPCI Serial specification but not supported on this board. MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...

  • Page 46: Table 14. Pin Assignment Of Compactpci Serial P5 Connector

    7_PE_ 7_PE_ 7_PE_ 7_PE_ Rx01- Rx01+ Tx01- Tx01+ Rx00- Rx00+ Tx00- Tx00+ Note: The signals written in gray are specified in the CompactPCI Serial specifica- tion but not supported on this board. MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...

  • Page 47: Table 15. Signal Mnemonics Of Compactpci Serial Rear Connectors

    3 for link 3 to link 8 (x = 3 to 8) x_PE_Tx00+..x_PE_Tx03+ x_PE_CLK-, x_PE_CLK+ Differential 100 MHz reference clock for link 1 to 8 (x = 1 to 8) PE_CLKE# Presence Detect MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...

  • Page 48: Ethernet Rear I/O Card

    Ethernet controllers to the heat sink of the G20. Removing the mSATA Adapter Board For installing the rear I/O card (e.g. the GM1) on the G20 you have to remove the adapter board with the mSATA disk and the microSD card. Carry out the following steps: ...
  • Page 49  Press the gap pad onto the Ethernet controller of the GM1 (highlighted in red).  Remove the plastic film on the other side.  Align the board-to-board connectors of the G20 and the rear I/O card and push the card down carefully.
  • Page 50 All manuals and user guides at all-guides.com Functional Description  Fasten the rear I/O card using the three screws included in the delivery of the card. MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...
  • Page 51  Remove the plastic film on the other side of the pads.  Align the board-to-board connectors of the G20 and the rear I/O card and push the card down carefully.  Fasten the rear I/O card using the three screws included in the delivery of the card.

  • Page 52: Reset Button

    All manuals and user guides at all-guides.com Functional Description 2.14 Reset Button The G20 is equipped with a reset button which is recessed within the front panel and requires a tool, e.g. paper clip to be pressed, preventing the button from being inadvertently activated. 2.15...

  • Page 53: Hot-Swap Led

    LED until the hot swap switch is closed. 2.15.3 User LEDs The user LEDs can be switched on and off using the MEN driver for the board controller. See MEN’s website for further information.

  • Page 54: Bios

    All manuals and user guides at all-guides.com BIOS BIOS The G20 is equipped with an InsydeH2O setup utility from Insyde Software. InsydeH2O is Insyde Software's firmware product line designed to replace traditional PC BIOS. It is an implementation of the Intel's Platform Innovation Framework for UEFI /EFI.

  • Page 55: Main

    Enter Select > Sub- F10 Save and Exit menu InsydeH2O Version / MEN Board / Processor Type / System Bus Speed / System Memory Speed / Cache RAM/ Total Memory / Intel ME Version/ MEN EC Version/ SODIMM 0 / SODIMM 1 Description You cannot change any values in these fields.
  • Page 56 Seconds (Valid range from 0 to 59) System Date Description Change the date Options Month (Valid range from 1 to 12) Day (Valid range from 1 to 31) yyyy Year (Valid range from 2000 to 2099) MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...

  • Page 57: Advanced

    Extra Bus Reserved [Disabled] >Active Management Technology Support >PCI Express Configuration Select Item F1 Help F5/F6 Change Values F9 Setup Defaults Select Menu Esc Exit Enter Select > Sub- F10 Save and Exit menu MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...
  • Page 58 External PS Control Description Controls the external Power Supply Options Always on Switched Platform Reset Management Description Enables or blocks the RESET_IN signal of the board. Options RESET_IN is RESET_IN is blocked enabled MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...
  • Page 59 All manuals and user guides at all-guides.com BIOS Spread Spectrum Control Description Enable or disable Spread Spectrum Options Spread Spectrum enabled Spread Spectrum disabled MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...
  • Page 60 LAN-1/LAN-2 Description Enables or disables the LAN interfaces. Options Enabled Disabled Wake on LAN Enable Description Enable or disable integrated LAN to wake the system. Options Enabled Disabled MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...
  • Page 61 (SALP) in AHCI Host Capability Register Bit 26. Options Enabled Disabled SGPIO Interface Description Switch for starting (on) or stopping (off) the SGPIO interface Options SATA Port 0/1/2/3/4/5 Hot Plug Description Enable/disable Hot Plug Options Enabled Disabled MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...
  • Page 62 Description On an edge detect from 0 to 1, the PCH starts a COMRESET ini- tialization sequence to the device Options Enabled Disabled Serial ATA Port 0/1/2/3/4/5 Description Not installed. You can make no changes here. MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...
  • Page 63 Description Thermal constant TC1 for the ACPI Passive Cooling (CPU Throt- tle On) Formula. Cannot be changed. Description It represents in 10th of a second how often the OS will read the temperature when Passive Cooling is enabled. Cannot be changed. MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...
  • Page 64 Description Intelligent Power Sharing configuration menu. Note: DTS must be enabled for Power Sharing to function. Options Disabled Enabled CPU Turbo Description Enable or disable CPU Turbo. Options Disabled Enabled MCH Turbo Description Enable or disable MCH Turbo. Options Disabled Enabled MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...
  • Page 65 96 MB 160 MB 224 MB 352 MB IGD - DVMT Total Gfx Mem Description Select the size of DVMT 5.0 that the Internal Graphics Device will use. Options 128 MB 256 MB MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...
  • Page 66 Description Enable/Disable EHCI 1/2. Options Enabled Disabled Pre-Port Control Description Enable/Disable the per port disable control override Options Enabled Disabled USB RMH Mode Description Enable/Disable the PCH USB Rate Matching Hubs Mode. Options Enabled Disabled MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...
  • Page 67 PCI Latency Timer [32] VT-d [Enabled] PCI Latency Timer Description Value to be programmed into PCI Latency Timer Register Options 224, VT-d Description Check to enable VT-d function on MCH Options Enabled Disabled MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...
  • Page 68 OS Timer BIOS Timer Intel AMT Support Description Enable/disable Intel Active Management Technology BIOS exten- sion. Note: iAMT H/W is always enabled. This option just controls the BIOS extension execution. Options Enabled Disabled MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...
  • Page 69 Description User can enable or disable PET events progress to receive PET events or not. Options Enabled Disabled Me Local FW Update Enable Description Enable or disable Me Local FW Update Enable function Options Enabled Disabled MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...
  • Page 70 >PCI Express Root Port 5 >PCI Express Root Port 6 >PCI Express Root Port 7 >PCI Express Root Port 8 PCI Express Clock Gating Description Options Enabled Disabled DMI Link ASPM Control Description Options L0sL1 Disabled MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...
  • Page 71 SEFE Description Enable or disable Root PCI Express System Error on Fatal Error. Options Enabled Disabled SENFE Description Enable or disable Root PCI Express System Error on Non-Fatal Error. Options Enabled Disabled MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...
  • Page 72 Description Enable or disable Root PCI Express PME Interrupt. Options Enabled Disabled PME SCI Description Enable or disable PCI Express Hot Plug SCI. Options Enabled Disabled Hot Plug Description Enable or disable PCI Express Hot Plug. Options Enabled Disabled MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...

  • Page 73: Security

    User Password Description Shows whether a user password has been entered. Set Supervisor Password Description Enter and confirm the supervisor password under this menu item. To delete the password enter an empty password. MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...
  • Page 74 Description Enter and confirm the user password under this menu item. Clear User Password Description Clear the user password. Only possible for a supervisor or user in the access levels full or limited. MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...

  • Page 75: Power

    Boot Performance Mode [Max Performance] CMP Support [Auto] HT Support [Auto] Use XD Capability [Enabled] VT Support [Disabled] C-States [Enabled] Enhanced C-States [Enabled] Enable C6 [Enabled] Interrupt Filtering [Disabled] Turbo Mode [Enabled] MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...
  • Page 76 Enhanced C-States Description Enable P-State transitions to occur in combination with C-States. Options Enabled Disabled Enable C6 Description Enables or disables the C6 state (Deep Power Down Technol- ogy). Options Enabled Disabled MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...
  • Page 77 C3/C6 will be notified to transition to C0, regardless of interrupt destination. Options Enabled Disabled Turbo Mode Description Enable processor Turbo Mode (requires EMTTM enabled too). Options Enabled Disabled MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...
  • Page 78 C3/C4. Options Enabled Disabled HDA Break Event Description If Enabled, Intel High Definition Audio master activity will cause BM_STS to be set and will cause a break from C3/C4. Options Enabled Disabled MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...
  • Page 79 PCI Power Management Enable wake up event occurs. Options Enabled Disabled Auto Wake on S5 Description Auto wake on S5, By Day of Month or Fixed time of every day Options Disabled By every day By day of month MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...

  • Page 80: Boot

    Description Allows InsydeH2O to skip certain tests while booting. This will decrease the time needed to boot the system. Options Enabled Disabled Quiet Boot Description Disables or enables booting in Text Mode Options Enabled Disabled MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...
  • Page 81 EFI – Sub-Menu ACPI(PNP0A03,0)/Pci(1D|0)/Usb(0, 0)/Usb(1, 0)/HD(Part1, SigD808A4A4) EFI Boot Menu Description Selects the boot order for (U)EFI boot media. In the example a USB memory device was detected as (U)EFI boot medium. MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...
  • Page 82 USB-HDD before SATA- Advance Under this menu option there are no device groups. The single devices are listed and can be moved to select the boot order, e.g.: SATA-HDD1 USB-Floppy USB-DVD-DRIVE SATA-HDD2 MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...

  • Page 83: Exit

    Load Optimal Defaults If this option is selected, a verified factory setup is loaded. On the first BIOS setup configuration, this loads safe values for setup, which make the board boot up. MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...

  • Page 84: Load Custom Defaults

    If this option is selected the custom defaults that have been saved in a former session with Save Custom Defaults (see Chapter 3.6.6 Save Custom Defaults) are loaded. 3.6.6 Save Custom Defaults Save custom defaults. 3.6.7 Discard Changes Discard changes. MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...

  • Page 85: Organization Of The Board

    INTA# INTB# INTC# INTD# INTB# INTC# INTD# INTA# INTC# INTD# INTA# INTB# INTD# INTA# INTB# INTC# INTA# INTB# INTC# INTD# INTB# INTC# INTD# INTA# INTC# INTD# INTA# INTB# INTD# INTA# INTB# INTC# MEN Mikro Elektronik GmbH 20G020-00 E5 – 2014-01-21...

  • Page 86: Maintenance

    The battery has to be UL listed. Used batteries have to be disposed of according to the local regulations concerning the disposal of hazardous waste. Figure 6. Position of battery on the CompactFlash adapter on the G20 (board versions -00 and -01) CompactFlash...

  • Page 87: Figure 7. Position Of Battery On The Msata Adapter On The G20

    All manuals and user guides at all-guides.com Maintenance Figure 7. Position of battery on the mSATA adapter on the G20 (board versions -02 and -03 mSATA microSD (bottom) Display Port Connectors Heat Sink Connectors Ethernet Connectors Battery M12 Connector for Ethernet (optional) MEN Mikro Elektronik GmbH 20G020-00 E5 –...

  • Page 88: Appendix

    All manuals and user guides at all-guides.com Appendix Appendix Literature and Web Resources • G20 data sheet with up-to-date information and documentation: www.men.de/products/02G020-.html • GM1 data sheet with up-to-date information and documentation: www.men.de/products/08GM01-.html • GM2 data sheet with up-to-date information and documentation: www.men.de/products/08GM02-.html...

  • Page 89: Finding Out The Product's Article Number, Revision And Serial Number

    Serial Number MEN user documentation may describe several different models and/or design revisions of the G20. You can find information on the article number, the design revision and the serial number on two labels attached to the board. • Article number: Gives the product’s family and model. This is also MEN’s ordering number.
